- Page 1 VC-AC09 USB Capture box User Manual-English [Important] To download the latest version of Quick Start Guide, multilingual user manual, software, or driver, etc., please visit Lumens http://www.MyLumens.com/support.php...
-
Page 2: Table Of Contents
Table of Contents Copyright Information ..................2 Chapter 1 Safety Instructions ................3 Precautions ....................4 Chapter 2 Preface ....................5 Chapter 3 System Requirements ..............6 Minimum Hardware Configuration ............6 ... -
Page 3: Copyright Information
Inc. Copying, reproducing or transmitting this file is not allowed if a license is not provided by Lumens Digital Optics Inc. unless copying this file is for the purpose of backup after purchasing this product. In order to keep improving the product, Lumens Digital Optics Inc. hereby reserves the right to make changes to product specifications without prior notice. -
Page 4: Chapter 1 Safety Instructions
Chapter 1 Safety Instructions Please use the product following the safety instructions below: 1 Operation 1.1 Please use the product in the recommended operating environment. 1.2 Do not use this product near water or source of heat. 1.3 Use attachments only as recommended. 1.4 Use the type of power source indicated on the HD Camera. -
Page 5: Precautions
Precautions Warning: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. Note Risk of Electric Shock Please do not open it by yourself. Caution: To reduce the risk of electric shock, do not remove cover (or back). No user-serviceable parts inside. -
Page 6: Chapter 2 Preface
Chapter 2 Preface Thank you for purchasing VC-AC09 USB Catpure Box！ VC-AC09 is easy to carry, has a superior performance, superior compatibility, simple installation and many other features. It can capture one HDMI 1080p60 input and output signal; compatible with Windows, Linux, Mac OS X and USB 2.0 interface, compatible with... -
Page 7: Chapter 3 System Requirements
Chapter 3 System Requirements 3.1 Minimum Hardware Configuration Intel Core Solo 1G of RAM Available USB3.0 interface 3.2 Recommended Hardware Configuration Intel Core i5 2G of RAM Available USB3.0 interface 3.3 System Requirements System should be one of the following systems (x86 version or x64 version): ... -
Page 8: Chapter 4 Hardware And Driver Installation
Chapter 4 Hardware and Driver Installation VC-AC09 supports hot-plugging/swap. Insert the USB3.0 cable head to USB3.0 interface, the other side of the cable into your computer's USB3.0 interface. It’s PnP devices, without having to install drivers, if POWER and ACTION lights lit, which means it working properly. -
Page 9: Chapter 5 Components And Connection
Chapter 5 Components and Connection 5.1 Components Video input interface 1. HDMI Capture output 2. USB 3.0 Power indicator 3. Power Working lights 4. Action 5.2 Connection Capture Box DVI-HDMI USB 3.0 Computer PTZ Video Camera English - 8... -
Page 10: Chapter 6 Video Capture Device Instruction
Chapter 6 Video Capture Device Instruction VC-AC09 is based on UVC (USB video class), UAC（USB audio class） STANDARD, without having to install drivers and settings. Different types of operating systems compatible with the corresponding interface: Windows: DirectShow, DirectSound Linux: V4L2 / ALSA …... -
Page 11: Display " Filter Output Pin " In Common Software
In the " Proc Amp" panel, you can set the brightness, contrast, hue, saturation, and other relevant parameters 6.2 Display " Filter output pin " In Common Software AMCAP：Double click "AmCap.exe", choose HD video device " XI100DUSB-HDMI Video "... - Page 12 Frame Rate: Set the output frame rate, currently supports 25/29.97/30/50/59.94/60 fps Color Space / Compression: currently offers two kinds of color spaces, YUY2 and RGB 24 Output: Set the screen output size, resolution is currently supported 640x480/768x576 / 800x600/1024x768/1280x720/1280x800/1280x960/ 1280x1024/1368x768/1440x900/1600x1200/1680x1050/1920x1080/ 1920x1200, the default output is 1920 * 1080.
-
Page 13: Chapter 7 Audio Capture Device Instruction
Chapter 7 Audio Capture Device Instruction For Windows as an example, VC-AC09 is based on the Microsoft DirectShow interface. After installation in operating system, the relevant audio devices will be added on. Any software which is compatible with DirectSound, DirectShow can use the recording device for capturing sound. - Page 14 English - 13...
-
Page 15: Chapter 8 Compatible Software Instruction
Chapter 8 Compatible Software Instruction VC-AC09 is currently compatible with the following capture software (tested): Windows Media Encoder (Windows) Adobe Flash Media Live Encoder (Windows, OS X) Real Producer Plus (Windows) VLC (Windows, OS X, Linux) ... -
Page 16: Chapter 9 Troubleshooting
Chapter 9 Troubleshooting This chapter describes problems you may encounter while using VC-AC09. If you have questions, please refer to related chapters and follow all the suggested solutions. If the problem still occurred, please contact your distributor or the service center.
