Your new tool has been engineered and manufactured to WEN's highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years
of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings,
and cautions. If you use your tool properly and for intended purpose, you will enjoy years of safe,
reliable service.
6-Ton Electric Log
IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
techsupport@wenproducts.com
WENPRODUCTS.COM
Splitter
Model # 4225
bit.ly/WENvideo
(M-F 8AM-5PM CST)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4225 and is the answer not in the manual?

Questions and answers

Related Manuals for Wen 4225

Summary of Contents for Wen 4225

  • Page 1 IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Product Specifications Safety Information General Safety Rules Log Splitter Safety Electrical Information Know Your Log Splitter Package Contents Assembly Operation Maintenance and Troubleshooting Exploded View and Parts List Warranty Product Specifications Model Number: 56206 Splitting Force: 6 Tons Cycle Time: 25 Seconds Motor:...

  • Page 3: Safety Information

    SAFETY INFORMATION SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. These safety instructions are not meant to cover every possible condition that could occur. If you have any questions regarding the product please call customer service at 1-800-232-1195, 8:00 a.m.-5:00 p.m., CST, Monday-Friday.

  • Page 4: General Safety Rules

    GENERAL SAFETY RULES Safety is a combination of common sense, staying alert and knowing how your item works. SAVE THESE SAFETY INSTRUCTIONS. WARNING: To avoid mistakes and serious injury, do not plug in your tool until the following steps have been read and understood. 1.

  • Page 5: Log Splitter Safety

    GENERAL SAFETY RULES 14. NEVER STAND ON A TOOL. Serious injury could result if the tool tips or is accidentally hit. DO NOT store anything above or near the tool. 15. DO NOT OVERREACH. Keep proper footing and balance at all times. Wear oil-resistant rubber-soled foot- wear.

  • Page 6: Electrical Information

    LOG SPLITTER SAFETY 7. MAKE all adjustments with the switch in the “OFF” position and the Log Splitter disconnected from the power source. 8. Never use the log splitter for any purpose other than splitting wood. Any other use can result in injury. Use ex- treme caution at all times.

  • Page 7: Grounding Instructions

    ELECTRICAL INFORMATION GROUNDING INSTRUCTIONS IN THE EVENT OF A MALFUNCTION OR BREAKDOWN, grounding FIGURE A provides the path of least resistance for an electric current and reduces the risk of electric shock. This tool is equipped with an electric cord that has an equip- ment grounding conductor and a grounding plug.
  • Page 8 Ampere Rating Total Length of Cord in feet More Than Not More Than Not Recommended Protect your extension cords from sharp objects, excessive heat and damp/wet areas. Use a separate electrical circuit for your tools. This circuit must not be less than a #12 wire and should be protected with a 15 A time-delayed fuse.

  • Page 9: Know Your Log Splitter

    KNOW YOUR LOG SPLITTER COMPONENTS Motor Handle Fluid Drain/Dipstick Bleed Screw Wedge Work Table Guards Hydraulic Control Lever Wheel Circuit Breaker ON/OFF Power Switch Beam...
  • Page 10 ASSEMBLY UNPACKING This Log Splitter requires the wheel assembly to be attached to the base. See wheel assembly directions below. NOTE: Do not discard box or any packing material until all parts are examined and accounted for. This Log Splitter has been filled with AW32 oil during the manufacturing process. Refer to the photo below and the parts list should it be necessary to disassemble the unit for repair or replacement of parts.

  • Page 11: Assembly

    ASSEMBLY WHEEL ASSEMBLY 1. Insert the wheel shaft into the motor end of the log splitter and secure with the cotter pin. 2. Secure the wheels to the wheel shaft using the nut and washer on the outside end of both wheels.

  • Page 12: Operation

    OPERATION WARNING: Read and thoroughly understand all instructions and safety information before op- erating this log splitter. Failure to do so may cause serious injury or death. Do not allow anyone to operate this log splitter who has not read this manual. As with all power equipment, a log splitter can be dangerous if assembled or used improperly.
  • Page 13 OPERATION WARNING: Always loosen the bleed screw prior to operation. This will remove any air trapped in the hydraulic system. Failure to release air from the hydraulic system may damage the hydraulic seals, permanently damaging the Log Splitter. To loosen the bleed screw: 1.
  • Page 14 OPERATION 5. Loosen the bleed screw one or two turns. 6. Two controls must be activated to operate the log splitter. The hy- draulic control lever (1) and the ON/OFF push button (2) must be held during the splitting process. If either control is released, the log splitter will stop operating.
  • Page 15 MAINTENANCE 6. Add fluid if needed. Replace dipstick and tighten the fluid drain knob. Remember to use AW32 fluid for operation at temperatures above 40 degrees Faren- heit, and Dexron® automatic transmission fluid for operation below 40 degrees Farenheit. The Log Splitter is pre-loaded with AW32 fluid dur- ing the manufacturing process.

  • Page 16: Troubleshooting

    TROUBLESHOOTING Problem Cause Action Logs will not Extension cord is too long or Check extension cord to ensure the gauge split gauge is too low of the cord is 12or 14 AWG and that the cord length does not exceed 25 ft. Incorrect positioning of the log.
  • Page 17 EXPLODED VIEW AND PARTS LIST...

  • Page 18: Exploded View And Parts List

    EXPLODED VIEW AND PARTS LIST Item Stock # Description Item Stock # Description 56206-001 Motor 56206-031 Bracket 56206-002 Nut M6 56206-032 Bolt 56206-003 Rubber foot 56206-033 Rubber sleeve 56206-004 Right rubber foot 34 56206-034 Hydraulic control lever 56206-005 bolt M6×12 56206-035 Nut M10 56206-006 Left rubber foot 56206-036 Nut M10...
  • Page 19 EXPLODED VIEW AND PARTS LIST Item Stock # Description Item Stock # Description 56206-061 Washer 6 56206-079 Bolt M8×50 56206-062 Washer 56206-080 Cylinder 56206-063 Oil seal 48.7×3.55G 81 56206-081 Ring58×52.5×4 56206-064 Nut M6 56206-082 Oil seal43.7×3.55G 56206-065 Front bracket 56206-083 Piston 56206-066 Upper pad...

  • Page 20: Warranty
