Installation
Proceed to Step 2 only after the software has been correctly installed.
If correctly installed, a Utility icon (four vertical bars) should appear next to your
computer's time display. An "X" indicates that software installation was successful,
but the wireless adapter is not yet activated.
Install software BEFORE installing the adapter (see Step 1 on previous page).
CAUTION: Turn OFF and UNPLUG your computer before opening it.
STEP 2: Install the Wireless USB Adapter
Plug the adapter into a configured USB port in your computer (or use the supplied cable to connect it as
shown below).
Grasp end cap on sides
and pull to remove

STEP 3: Recognize the Hardware

Depending on the Windows
may appear to inform you that the computer recognizes new hardware. Choose to install the software
automatically and click Next.
Depending on your Windows
Not Found message. Click Continue Anyway or Yes to complete the installation.
Depending on your Windows
installation. If a Windows
Finally, some versions may display the message Systems Settings Change. Click Yes.
Check the indicator light to verify that the adapter is working: The light will remain on when receiving
power and connected to the network. It will blink during data transfer.
AT&T Plug&Share Wireless USB Adapter 54 Mbps 6602G
™
Connect to port
with this symbol
Press button to release antenna
and raise to fully upright position
operating system version running on your computer, one of several screens
®
version, you may see a Hardware Alert message or a Digital Signature
®
version, you may have to restart your computer to complete the
®
message prompts you to restart your computer, do so.
®
USB cable
Connect USB adapter to
cable (or computer)
