Polarstart PS-3025 SH Installation Manual

Multi-channel remote starter system
Hide thumbs
Table of Contents

Advertisement

Quick Links

TABLE OF CONTENTS..................................................1
INTRODUCTION ............................................................2
WHAT'S INCLUDED .....................................................2
BEFORE YOU GET STARTED... ...................................2
PS-3025 SH - FEATURES LIST .....................................3
HARNESS DESCRIPTION .............................................4
WIRING DIAGRAM .......................................................6
TRANSMITTER FUNCTIONS .......................................7
LEARNING A TRANSMITTER .....................................7
VALET OPERATION......................................................7
To get into Valet Mode:................................................7
To get out of Valet Mode:.............................................8
MULTI-SPEED TACH LEARNING ...............................8
PROGRAMMING OPTIONS ..........................................8
2
PROGRAMMABLE FEATURES..................................10
Lock Pulse Duration ...................................................10
Vehicle Type - Gas or Diesel .....................................10
Horn Confirmation......................................................10
SAFE START.............................................................11
Idle Mode....................................................................11
To activate the Idle Mode: ..........................................11
Cold Weather Mode....................................................11
Ignition-Controlled Door Locks .................................11
Smart Ignition Locks ..................................................11
NOTICE:
DUE TO THE POTENTIAL FOR DAMAGE TO THE VEHICLE, THE MANUFACTURER IS NOT RESPONSIBLE FOR
ANY ELECTRICAL DAMAGE TO THE VEHICLE OR TO THE UNIT THAT HAS CAUSED VEHICLE DAMAGE
DUE TO IMPROPER INSTALLATION OF THE PRODUCT. THIS UNIT MUST BE INSTALLED BY A CERTIFIED
POLARSTART TRAINED TECHNICIAN USING ALL SAFETY DEVICES SUPPLIED.
Please review the Installation Guide carefully before beginning any work.
WARNING
THIS UNIT IS DESIGNED FOR VEHICLES WITH AN AUTOMATIC TRANSMISSION ONLY. BEFORE
INSTALLING THE UNIT, TEST THAT THE VEHICLE WILL NOT START IF THE GEAR SELECT LEVER IS IN
DRIVE POSITION. IF IT STARTS IN GEAR, INSTALL A MANUAL TRANSMISSION CAR STARTER.
Rev: 1.10 TlGpLp Jan/08/02 - Manufactured in Canada by POLARSTART
POLARSTART
PS-3025 SH
Multi-Channel Remote Starter System
for AUTOMATIC Transmissions
Installation Guide

TABLE OF CONTENTS

Engine Running Confirmation....................................11
Smart Rearm...............................................................11
Secure Lock ................................................................11
Smart Secure Lock......................................................12
Key Sense ...................................................................12
Starter Disable ............................................................12
Priority Door Access ..................................................12
AUX 2 -Timed Output ...............................................13
Headlight Illumination............................................13
Horn Chirp Timing .....................................................14
AUX 3 - TRUNK or Sunroof control ........................14
Programmable External Trigger .................................14
HOME VALET .......................................................15
GROUND OUTPUT ......................................................15
be programmed)..............................................................15
QUICK LOCKOUT ....................................................15
MULTI-CAR OPERATION ..........................................15
RESETTING THE MODULE........................................16
EVENTS LOGGING and PLAYBACK.........................16
Events playback:.........................................................16
DIAGNOSTICS - PARKING LIGHTS .........................17
TESTING .......................................................................17
CLOSING UP.................................................................17
