Onkyo HT-R560 Service Manual
  1. Manuals
  2. Brands
  3. Onkyo Manuals
  4. Home Cinema speakers
  5. HT-R560
  6. Service manual

Onkyo HT-R560 Service Manual

7.1-h home theater receiver
Hide thumbs Also See for HT-R560:

Advertisement

Quick Links

See also: Instruction Manual
SERVICE MANUAL
SERVICE MANUAL
7.1-CH HOME THEATER RECEIVER
MODEL
ON/STANDBY
STANDBY
DOCK
MULTI CH
DVD
VCR/DVR
CBL/SAT
PHONES
A
SPEAKERS
B
TONE
MOVIE/TV
HT-R560 for HT-S5100 Black and Silver models
(HT-S5100 : 7.1ch Home Theater System)
B MDD
120V AC, 60Hz
B MDC, S MDC
120V AC, 60Hz
B MPP
230V AC, 50Hz
HT-R560 for AVX-760LD Black model
(AVX-760LD : 5.1ch Home Theater System)
B MDD
120V AC, 60Hz
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
HT-R560
TUNING
PRESET
ENTER
AUX
TAPE
TUNER
CD
SETUP
RETURN
SETUP MIC
VIDEO
MUSIC
GAME
DISPLAY DIGITAL INPUT
DIMMER
MEMORY
TUNING MODE
CLEAR
ON THE
HT-R560
Ref. No. 4066
042008
DISPLAY
MULTI CH
RECEIVER
MASTER VOLUME
AUDIO
LISTENING MODE
MOVIE/TV
MUSIC
AUX INPUT
L
AUDIO
R
DIMMER
HT-R560
AV RECEIVER
RC-707M

Advertisement

loading
Need help?

Need help?

Do you have a question about the HT-R560 and is the answer not in the manual?

Questions and answers

Related Manuals for Onkyo HT-R560

Summary of Contents for Onkyo HT-R560

  • Page 1 DIMMER MEMORY TUNING MODE DIMMER CLEAR HT-R560 AV RECEIVER RC-707M HT-R560 for HT-S5100 Black and Silver models (HT-S5100 : 7.1ch Home Theater System) B MDD 120V AC, 60Hz B MDC, S MDC 120V AC, 60Hz B MPP 230V AC, 50Hz HT-R560 for AVX-760LD Black model (AVX-760LD : 5.1ch Home Theater System)

  • Page 2: Exploded Views

    HT-R560 EXPLODED VIEWS-1 A061 x 6 pcs. A102 P901 A096 A037 MDD, MDC Type : 7 pcs. MPP Type : 6 pcs. MPP Type only A052 A103 P6601A x 14 pcs. A060 A109 MDD, MDC Type only A104 A013 x 8 pcs.
  • Page 3 HT-R560 EXPLODED VIEWS-2 Q6050B x 6 pcs. A049 x 14 pcs. Q6056 Q6066 Q6055 Q6065 Q6054 Q6064 Q6053 Q6063 Q6052 Q6062 Q6051 Q6050A Q6061 x 2 pcs. Q6050 Q6060...

  • Page 4: Block Diagrams - Audio Section

    HT-R560 BLOCK DIAGRAMS-1 AUDIO SECTION AUDIO ANALOG Q5501 FRONT L R2S15211FP TUNER UNIT SELECTOR / TONE / VOLUME FRONT R DOCK PHONES AUDIO DIGITAL MDD. MDC Type only POWER AMPLIFIER SIRIUS RL6600 TONE +29dB MIC AMP. SETUP MIC FRONT SPEAKERS A...

  • Page 5: Navd

    HT-R560 BLOCK DIAGRAMS-2 VIDEO / HDMI SECTION NAHDM-9475 HDMI TMDS3 TMDS DDC3 IN 3 RPWR3 HPD3 HP DET HDMI TMDS2 TMDS TMDS TMDS Q8001 TMDS341A DDC2 RPWR IN 2 HDMI SWITCH RPWR2 HPD2 +5V Reg HP DET HP DET TMDS1...
  • Page 6 HT-R560 SCHEMATIC DIAGRAMS-1 (SD-1) AUDIO INPUT SECTION SIRIUS / DOCK TERMINAL PCB MICROPROCESSOR PCB MICROPROCESSOR PCB MICROPROCESSOR PCB To NARF-9458 To NADG-9457 To NADG-9457 To NADG- SD-8 : E1 SD-3 : A3 SD-3 : A2 9457 SD-3 : A3 JL5502A...

  • Page 7: To Natrm

    HT-R560 SCHEMATIC DIAGRAMS-2 (SD-2) NAAF-9419 (2/2) AMPLIFIER PC BOARD POWER AMPLIFIER SECTION P6901B BLUE P6902B Q6000 - 6010 : 2SC1740S-S R5180 R5183 Q6003, 6013 : 2SC1740S-S +61.0V +62.0V +61.0V +62.0V R6020 WHITE (1/4W) To P6901A (1/4W) (1/4W) +1.1V Q6030 +1.1V...

  • Page 8: To Nahdm

    HT-R560 SCHEMATIC DIAGRAMS-3 (SD-3) VIDEO PCB NADG-9457 SIRIUS/ DOCK TERMINAL PCB MICROPROCESSOR PC BOARD To NAVD-9467 MICROPROCESSOR SECTION DISPLAY PCB To NARF-9458 To NADIS-9430 SD-4 : H4 To TUNER UNIT SD-8 : E3 SD-6 : H1 L131, 132 : LBC2518T2R2M...
  • Page 9 HT-R560 SCHEMATIC DIAGRAMS-4 (SD-4) VIDEO SECTION P3007A NAVD-9467 Refer to following table about the parts displayed by mark " LIST ". LIST +12V MODEL No. ---> TX-SR506 HT-R518 HT-R560 TX-SR576 HT-R667 HT-R960 TX-SR606 TX-SA606X Q9101 2SA950 FAN DRIVE R9102 1.2K...
  • Page 10 HT-R560 SCHEMATIC DIAGRAMS-5 (SD-5) LIST NATRM-9428 SPEAKER TERMINAL / POWER SUPPLY SECTION ZONE 2 SPEAKER NAETC-9435 TERMINAL PC BOARD HEADPHONE JACK NAPS-9432 <Note> PC BOARD 1. NC = No mount of parts. 2. SD-x : XY is short for Schematic Diagrams-x and each...
  • Page 11 HT-R560 SCHEMATIC DIAGRAMS-6 (SD-6) NADIS-9430 DISPLAY SECTION Q7001 DISPLAY PC BOARD 16BT138GNK FL TUBE REMIN FLDRST FLDCS FLDCLK FLDSDO R7022 KEY0 10K R7023 NOTE R7021 KEY1 C7011 KEY2 THE COMPONENTS IDENTIFIED BY MARK ARE CRITICAL FOR SAFETY 223Z KEY3 C7012 223Z +3.3VMPU...
  • Page 12 HT-R560 SCHEMATIC DIAGRAMS-7 (SD-7) DSP / HDMI SECTION NAHDM-9475 AGND GND_S C8019 DSP / HDMI PC BOARD 103Z R8001 HPD_SINK HP DET HP DET +5VIN1HD +5VOUT TP20 R8022 TP21 DDC DATA DDC DATA DDC CLK DDC CLK CERemote CERemote HDMI...
  • Page 13 HT-R560 SCHEMATIC DIAGRAMS-8 <Note> 1. NC = No mount of parts. SIRIUS / DOCK TERMINAL SECTION 2. SD-x : XY is short for Schematic Diagrams-x and each sockets location, X = A to H, Y = 1 to 5. NADG-9458...
  • Page 14 HT-R560 SCHEMATIC DIAGRAMS-9 WAVEFORM SECTION-1/3 Digital Audio Waveform Part <Notes> 1. WF01 is short for Waveform-01 . 2. Refer to SD-3 (SCHEMATIC DIAGRAMS-3) for the location of each waveform on circuit. 3. SD-x : XY is short for Schematic Diagrams-x and each socket's location, X=A to H, Y=1 to 5.
  • Page 15 HT-R560 SCHEMATIC DIAGRAMS-10 WAVEFORM SECTION-2/3 Video Waveform Part Video source color and pattern <Notes> 1. WF21 is short for Waveform-21 . 2. Refer to SD-4 (SCHEMATIC DIAGRAMS-4) for the location of each waveform on circuit. 3. SD-x : XY is short for Schematic Diagrams-x and each socket's location, X=A to H, Y=1 to 5.
  • Page 16 HT-R560 SCHEMATIC DIAGRAMS-11 WAVEFORM SECTION-3/3 FL Driver IC Control Waveform Part <Notes> 1. WF61 is short for Waveform-61 . 2. Refer to SD-6 (SCHEMATIC DIAGRAMS-6) for the location of each waveform on circuit. 3. SD-x : XY is short for Schematic Diagrams-x and each socket's location, X=A to H, Y=1 to 5.

  • Page 17: Printed Circuit Board Views

    TX-SR506 PRINTED CIRCUIT BOARD VIEWS-1 AMPLIFIER PC BOARD (NAAF-9419) Component side C6087 C6086 P6991 P5505 P6602 P7902 JL6604A P7908 P7907 P7904 P7906 P7905 P7901 R5686 P7900 R5670 C5503 SPK HOLDER J5004 C5520 R5688 C6076 C6077 J5006 C5524 J5001 C5504 AGND J5002 J5050 AGND...
  • Page 18 TX-SR506 PRINTED CIRCUIT BOARD VIEWS-2 AMPLIFIER PC BOARD (NAAF-9419) Soldering side C5708 D5708 D5718 C5533 C5534 C5501 C5502 R5550 C5515 C5516 R5549 C5517 C5518 C5527 C5528 C5531 C5532 C5529 C5530 R5580 R5577 R5581 C5507 C5508 C5523 C5521 C5522 C5513 C5514 C5525 C5526 R5619...
  • Page 19 TX-SR506 PRINTED CIRCUIT BOARD VIEWS-3 TRANS. SEC. TERMINAL PC BOARD (NAPS-9420) Component side Soldering side THERMAL SENSOR PC BOARD (NAETC-9421) Component side Soldering side JL6402A...
  • Page 20 TX-SR506 PRINTED CIRCUIT BOARD VIEWS-4 DISPLAY PC BOARD (NADIS-9430) Component side 01.OPEN 04.V4V 14.MICDET 22.KEYINT0 S7002 02.LEDSTBY 05.GNDV4 15.GNDDG 23.+3.3VMPU Q7002 03.GNDV4V 06.V4_L 16.VOLB 24.KEY3 JL7101A 9.LEDZONE2 07.GNDV4 17.VOLA 8.LEDSTBY J7191 7.OPEN 08.V4_R 18.-VP J7145 09.+15VA 19.FLAC2 6.GNDDG 10.MICOUT 20.KEYINT1 5.+5VDIS R7046 J7089...
  • Page 21 TX-SR506 PRINTED CIRCUIT BOARD VIEWS-5 POWER SUPPLY PC BOARD (NAPS-9432) Component side NCPS-9432 25139432 S902 C911 C921 C930 J910 C902 J907 D925 J908 C922 J903 R932 P922A C931 J909 R930 R931 C933 R934 C901 D934 F901B F901D F901C F901A F901 8A 125V D935 D933...
  • Page 22 TX-SR506 PRINTED CIRCUIT BOARD VIEWS-6 MICROPROCESSOR PC BOARD (NADG-9457) Q101 Side-A P751A U131 U132 P131 R102 C145 R103 D105 C322 C324 R418 R438 R428 R408 C103 R427 R407 R437 R417 R436 R416 R426 R406 R425 R405 R435 R415 C325 C326 R326 R325 R311...
  • Page 23 TX-SR506 PRINTED CIRCUIT BOARD VIEWS-7 MICROPROCESSOR PC BOARD (NADG-9457) Side-B L133 R140 R640 C140 R613 C142 R142 R135 C141 R141 L131 R139 C133 Q131 R478 R352 C342 03.CX_SD1 R458 04.CX_SD2 Q341 05.CX_ SD3 C341 06.CX_SD4 C418 R351 07.SAI_SCK R341 R448 08.SAI_LRCK 15.VDSWS1 R447...
  • Page 24 TX-SR506 PRINTED CIRCUIT BOARD VIEWS-8 SIRIUS / DOCK TERMINAL PC BOARD (NARF-9458) <Note> HT-R560 Only Side-A 01.GND_XM 06.XMLNK JL8002B 02.+12V_XM 03.IPOD_V 07.XMANT JL5502B C2091 L2082 R2122 R2051 R2120 R2050 R2123 R2053 R2021 R2121 C2025 R2027 C2023 D2086 R2047 R2025 R2071...
  • Page 25 TX-SR506 PRINTED CIRCUIT BOARD VIEWS-9 VIDEO PC BOARD (NAVD-9467) Component side J3054 J3083 J3068 J3055 J3057 J3067 J3059 J3081 +5VDSP J3058 J3060 C9023 J3061 Q9001 C9025 J3074 J3065 GND_HD +12V_HD J3062 GND_HD C3046 J3092 R9001 +12V_HD C9032 GND_HD J3091 J3052 C3047 J3087 J3051...
  • Page 26 TX-SR506 PRINTED CIRCUIT BOARD VIEWS-10 VIDEO PC BOARD (NAVD-9467) Soldering side C9006 D9016 R3029 C3072 R9004 R3063 R3050 D9005 R3062 R3031 R3026 R3030 C3073 D9023 R3028 R3027 R3041 R9024 C3070 R3045 R9025 C3069 R3074 Q9021 R3052 R3086 R3010 R9111 C3083 R3064 R3083 R9103...
  • Page 27 TX-SR506 PRINTED CIRCUIT BOARD VIEWS-11 SPEAKER TERMINAL PC BOARD (NATRM-9468) Component side J6670 J6671 P6604 P6603 P6602 C6600 C6652 J6669 C6645 L6600 J6665 RL6600 RL6603 J6666 C6643 RL6605 C6602 J6600 J6636 J6637 J6620 J6626 RL6607 J6638 L6604 J6639 JL6603B J6656 J6657 L6605 JL6604B...
  • Page 28 TX-SR506 PRINTED CIRCUIT BOARD VIEWS-12 HDMI PC BOARD (NAHDM-9475) Side-A TP40 P704B TP38 P202 TP01 R269 R260 R8027 R259 R257 R8929 R256 L204 R255 R254 R252 R251 R250 R209 R253 Q202 R8003 R207 C203 Q201 C204 R221 L203 C242 C223 C207 C222 R8002...
  • Page 29 TX-SR506 PRINTED CIRCUIT BOARD VIEWS-13 HDMI PC BOARD (NAHDM-9475) Side-B R258 R208 R273 R282 C201 R201 C231 R202 C230 R283 R203 C213 R284 R204 C221 R205 C229 R206 R285 C212 C211 R287 R281 C228 C205 Q8008 C282 C8067 C219 TP34 C291 C290 C284...
  • Page 30 TX-SR506 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-1 Q201 : D788E001BRFP266 (Floating-Point Digital Signal Processor)-1/5 BLOCK DIAGRAM Program/Data JTAG EMU 256K Bytes McASP0 Data 16 Serializers Program/Data ROM Page1 C67x + CPU 256K Bytes Memory Data Controller Program/Data McASP1 ROM Page2 6 Serializers 256K Bytes Program...
  • Page 31 TX-SR506 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-2 Q201 : D788E001BRFP266 (Floating-Point Digital Signal Processor)-2/5 PIN LAYOUT SPI0_SIMO EM_CKE SPI0_SOMI/I2C0_SDA EM_CLK DVDD AXR0[0] DVDD EM_WE_DQM[1] AXR0[1] EM_D[8] AXR0[2] CVDD AXR0[3] EM_D[9] EM_D[10] AXR0[4] AXR0[5]/SPI1_SCS EM_D[11] AXR0[6]/SPI1_ENA DVDD AXR0[7]/SPI1_CLK EM_D[12] CVDD EM_D[13] CVDD DVDD EM_D[14]...
  • Page 32 TX-SR506 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-3 Q201 : D788E001BRFP266 (Floating-Point Digital Signal Processor)-3/5 TERMINAL DESCRIPTION External Memory Interface (EMIF) Address and Control Pin Name Pin No. Type Description EM_A[0] EMIF Address Bus EM_A[1] EM_A[2] EM_A[3] EM_A[4] EM_A[5] EM_A[6] EM_A[7] EM_A[8] EM_A[9] EM_A[10]...
  • Page 33 TX-SR506 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-4 Q201 : D788E001BRFP266 (Floating-Point Digital Signal Processor)-4/5 TERMINAL DESCRIPTION McASP0, McASP1, McASP2, and SPI1 Serial Ports Pin Name Pin No. Type Description AHCLKR0/AHCLKR1 McASP0 and McASP1 Receive Master Clock ACLKR0 McASP0 Receive Bit Clock AFSR0 McASP0 Receive Frame Sync (L/R Clock) AHCLKX0/AHCLKX2...
  • Page 34 TX-SR506 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-5 Q201 : D788E001BRFP266 (Floating-Point Digital Signal Processor)-5/5 TERMINAL DESCRIPTION Clocks Pin Name Pin No. Type Description OSCIN 1.2-V Oscillator Input OSCOUT 1.2-V Oscillator Output OSCVDD Oscillator 1.2-V VDD tap point (for filter only) OSCVSS Oscillator VSS tap point (for filter only) CLKIN...
  • Page 35 TX-SR506 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-6 Q281 : M12L64164A-7TG ( 1M x 16 Bit x 4 Banks Synchronous DRAM ) BLOCK DIAGRAM PIN LAYOUT TOP VIEW Clock Generator DQ15 Bank D VDDQ VSSQ Bank C DQ14 Bank B DQ13 Address VSSQ VDDQ...
  • Page 36 TX-SR506 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-7 Q282 : ES29LV160ET-70TG ( 16Mbit CMOS 3.0 Volt-only, Boot Sector Flash Memory ) BLOCK DIAGRAM RY/BY# Timer/ Vcc Detector Counter DQ0-DQ15(A-1) Analog Bias Generator Input/Output Buffers Write Command State Register Machine RESET# Data Latch/ Sense Amps Sector Switches Y-Decoder...
  • Page 37 TX-SR506 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-8 Q301 CS42518 (8-Ch Codec with S/PDIF Receiver)-1/4 BLOCK DIAGRAM VARX AGND LPFLT DGND DGND VD RXP0 RXP1/GPO1 RXP2/GPO2 C&U Bit Control RXP3/GPO3 Data Buffer AD0/CS S/P DIF Clock/Data Port RXP4/GPO4 AD1/CDIN Recovery Decoder RXP5/GPO5 SDA/CDOUT Format...
  • Page 38 TX-SR506 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-9 Q301 : CS42518 (8-Ch Codec with S/PDIF Receiver)-2/4 PIN LAYOUT CX_SDIN1 RXP1/GP01 CX_SCLK RXP1/GP01 CX_LRCK RXP1/GP01 RXP1/GP01 DGND RXP1/GP01 RXP1/GP01 SCL/CCLK RXP1/GP01 SDA/CDOUT VARX CS42518 AD1/CDIN AGND AD0/CS LPFLT MUTEC AOUTA1- AINR- AOUTA1+ AINR+ AOUTB1+ AINL+...
  • Page 39 TX-SR506 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-10 Q301 : CS42518 (8-Ch Codec with S/PDIF Receiver)-3/4 TERMINAL DESCRIPTION Name Pin No. Function AD0/CS Address Bit 0 (I2C)/Control Port Chip Select (SPI) (INput) - AD0 is a chip address pin in I2C mode; CS is the chip select signal in SPI mode.
  • Page 40 TX-SR506 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-11 Q301 : CS42518 (8-Ch Codec with S/PDIF Receiver)-4/4 TERMINAL DESCRIPTION Name Pin No. Function CL_SDOUT CODEC Serial Data Output (Output) - Output for two's complement serial audio data the internal and external ADCs. ADCIN1 External ADC Serial Input (Input) - The CS42518 provides for up two external stereo analog to digital ADCIN2...
  • Page 41 TX-SR506 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-12 Q3001 : AN15880A (Video SW for Receiver with Multi-signal)-1/3 BLOCK DIAGRAM VOUT1 4/6dB VOUT3 VOUT2 YPUT2 4/6dB YOUT3 YOUT1 COUT2 4/6dB COUT3 COUT1 CYOUT1 CYOUT2 PBOUT1 PBOUT2 PROUT1 BIAS PROUT2 S1 S2 S3 S4 S5 S6 S7 S8 S9 MUTE PIN CONFIGURATION...
  • Page 42 TX-SR506 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-13 Q3001 : AN15880A (Video SW for Receiver with Multi-signal)-2/3 TERMINAL DESCRIPTION (1/2) Pin No. Pin name Type Descripion Input Luminance signal input 1 Input Luminance signal input 2 Input Luminance signal input 3 Input Luminance signal input 4 Input...
  • Page 43 TX-SR506 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-14 Q3001 : AN15880A (Video SW for Receiver with Multi-signal)-3/3 TERMINAL DESCRIPTION (2/2) Pin No. Pin name Type Description No connection CYOUT1 signal output CYOUT1 Output Ground GND4 Ground COUT3 signal output COUT3 Output COUT2 signal output COUT2 Output...
  • Page 44 TX-SR506 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-15 Q5501 : R2S15211FP (8 ch Electronic Volume and 11 Input Selector and Tone Control)-1/3 SYSTEM BLOCK DIAGRAM Multi Multi Rch Tone Lch Tone CLOCK DATA MCU I/F Tone Bass & Volume Volume Treble Lout Volume Volume...
  • Page 45 TX-SR506 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-16 Q5501 : R2S15211FP (8 ch Electronic Volume and 11 Input Selector and Tone Control)-2/3 BLOCK DIAGRAM AND PIN CONFIGURATION 40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 AVCC DGND AVCC...
  • Page 46 TX-SR506 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-17 Q5501 : R2S15211FP (8 ch Electronic Volume and 11 Input Selector and Tone Control)-3/3 TERMINAL DESCRIPTION PIN No. Name Function 19,17, FROUT,FLOUT, 14,12, 6-OUT,5-OUT, Output pin of FL/FR/C/SW/SL/SR/SBL/SBR channel 4-OUT, 3-OUT, 9,7, 2-OUT,1-OUT 20,16, FRC,FLC, Connects capacitor for reducing click noise of...
  • Page 47 TX-SR506 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-18 Q7003 : M66005-0001AHP (FL Tube Driver) BLOCK DIAGRAM Display code RAM SEG00 CG ROM Bank 1 : 8bit x 16 (35bit x 160) Bank 2 : 8bit x 64 SEG26 Segment output SEG27 code circuit write...
  • Page 48 TX-SR506 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-19 Q8001 : TMDS341APFCR ( HDMI Switch)-1/2 BLOCK DIAGRAM VSADJ V CC (3.3 V) R INT TMDS 3-to-1 MUX Drive V CC R INT V CC TMDS R INT Drive Rx w/ V CC R INT TMDS Rx w/...
  • Page 49 TX-SR506 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-20 Q8001 : TMDS341APFCR ( HDMI Switch)-2/2 PIN LAYOUT HPD_SINK HPD2 SDA_SINK SDA2 SCL_SINK SCL2 (TOP VIEW) HPD1 TERMINAL DESCRIPTION PIN NAME PIN NO. DESCRIPTION A11, A12, A13, A14 6, 9, 12, 15 Port 1 TMDS positive inputs A21, A22, A23, A24 68, 71, 74, 77 Port 2 TMDS positive inputs...
  • Page 50 HT-R560 MICROPROCESSOR TERMINAL DESCRIPTIONS-1 Q701 : M30624MHP-456FP (Main Microprocessor) Pin No. Pin Name Act. Description HDMISEL3 HDMI switch IC (TMDS341A) control. HDMISEL2 HDMI switch IC (TMDS341A) control. ROMCLK EEPROM IC (R1EX25064) clock output. FANCTRL MWT type : Cooling fan control. Other type : Not used.
  • Page 51 HT-R560 MICROPROCESSOR TERMINAL DESCRIPTIONS-2 Q701 : M30624MHP-456FP (Main Microprocessor) Pin No. Pin Name Act. Description SPRLF Front Speaker relay control output. ROMSDO EEPROM IC (R1EX25064) data transmitter output. VOLDAT Volume/ selector IC (R2S15211) data output. VOLCLK Volume/ selector IC (R2S15211) clock output.
  • Page 52 HT-R560 SERVICE PROCEDURE-1 1. Replacing the fuses This symbol located near the fuse indicates that the fuse used is show operating type, For continued protection against fire hazard, replace with same type fuse, For fuse rating, refer to the marking adjacent to the symbol.
  • Page 53 HT-R560 SERVICE PROCEDURE-2 5. To check version of Main microprocessor and DSP 1. Press and hold down DISPLAY button, then press ON/STANDBY button when the unit is power on. The main microprocessor version will be displayed on Front Display for about 3 seconds.
  • Page 54 TX-SR506 OPERATION CHECK-1 SPEAKER PROTECT-1 Circuit configuration The unit go into protect mode when either of thermal detection, dc voltage detection or current detection circuit operates. Power amplifier VPRO : DC voltage detection IPRO : Current detection Q6071 Q6072 Thermal sensor Q6070 RL901 Q6380...
  • Page 55 TX-SR506 OPERATION CHECK-2 SPEAKER PROTECT-2 DC Voltage detection check [When] 1. Exchange power transistors (Q6050 - Q6056, Q6060 - Q6066). 2. Exchange amplifier PC board ass'y (NAAF-9419). [Procedure] Note : No load. No input. 1. Press and hold down CD button, then press ON/STANDBY button while the unit is powered on. "...
  • Page 56 TX-SR506 OPERATION CHECK-3 SPEAKER PROTECT-3 Current detection check [When] 1. Exchange power transistors (Q6050 - Q6056, Q6060 - Q6066). 2. Exchange amplifier PC board ass'y (NAAF-9419). [Procedure] Notes : No input. Do not check two or more channels at the same time. Do not connect a dummy load to speaker terminal longer than 2 seconds.
  • Page 57 TX-SR506 OPERATION CHECK-4 POWER SUPPLY CONTROL Configuration The power supply voltage of +/-B1 for power amplifier is changed by the relays (RL6901, 6902). Power amplifier Output sensor RL6901 S1H+ +22V S1H- Thermal sensor Q6380 RL6902 D6901 To Power amp. S1L+ section S1L- THERMAL...
  • Page 58 TX-SR506 OPERATION CHECK-5 COOLING FAN Note : MWT, MWO, MWF type only Circuit configuration Power amplifier Output sensor Cooling fan Thermal sensor Fan drive Q6380 Q9101, 9102 THERMAL FANCTRL Q701 Main Microprocessor VOLH Q9111, 9112 Condition to operate The cooling fan will stop or rotate at high speed or low speed under the following condition. Operation of Cooling Fan VOLH (V) VOLH port of MPU...
  • Page 59 TX-SR506 DEBUG MODE-1 DSP DEBUG MODE-1 The operations of DSP and DIR etc are able to checked by the information displayed on FL in this debug mode. This information will help to analysing digital audio no sound trouble. To set in Debug mode 1.
  • Page 60 TX-SR506 DEBUG MODE-2 DSP DEBUG MODE-2 Content of Display (Continued) DSP Port DSP Decode This figure is displayed in hexadecimal form. o = Decode OK If this is transformed to binary form, each bit indicates x = Decode NG the following DSP port status. Refeo to <Fig-1>. Mute output device (Normal state) bit 0 = NIC...
  • Page 61 TX-SR506 DEBUG MODE-3 DSP DEBUG MODE-3 Trouble Shooting by DSP DEBUG MODE (Continued) Symptom on FL display Cause of trouble Remedy Digit No. on FL Continue to display "1" Interface between DSP and MPU is no good. The same remedy as 10 -b. Continue to display "2"...
  • Page 62 TX-SR506 DEBUG MODE-4 SERVICE INFORMATION MODE Trouble Shooting by Displaying Service information This service information display system is helpful in analyze the status when the unit goes into Protect mode and is powered off. Pay attention that the status will change if a button is pushed. 1.

  • Page 63: Adjustment Procedure

    HT-R560 ADJUSTMENT PROCEDURE-1 IDLING CURRENT ADJUSTMENT [When] 1. Exchange Power transistor (Q6050 - Q6056, Q6060 - Q6066). 2. Amplifier PC board (NAAF-9419). [Procedure] Refer to "ADJUSTMENT PROCEDURE-2 " for the adjustment points and the test points. <Note> No load and No signal 1.
  • Page 64 HT-R560 ADJUSTMENT PROCEDURE-2 IDLING CURRENT ADJUSTMENT Adjustment point Test point (Trimming resistor) Adjustment points and the test points R6046 Front side P6086 Surround Back Right ch R6045 P6086 P6085 Surround Back Left ch P6085 R6045 R6044 P6084 Surround R6044 Right ch...
  • Page 65 1/69 PAGE HT-R560 <Note> Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. NOTE : THE COMPONENTS IDENTIFIED BY THE MARK ! ARE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK. REPLACE ONLY WITH PART NUMBER SPECIFIED.
  • Page 66 2/69 PAGE A031 SPACER 27270439 EXPLODED A033 LABEL (PT) 29363379-1 EXPLODED A035 HOLDER KGLS-14RT 27190524 EXPLODED A037 BUSHING S-RELIEF #2271 27300750 EXPLODED A039 TAPE TAPE(CLOTH-16U) 29110083 EXPLODED A040 HEAT SINK (AS) 27160602A EXPLODED A041 BRACKET (HT-L) 27131016B EXPLODED A042 BRACKET (HT-R) 27131017A EXPLODED...
  • Page 67 (STNBY)/B 28326621 EXPLODED A076 KNOB (STNBY)/S 28326622 EXPLODED A077 BADGE 28135244 EXPLODED A077 BADGE 28135298 EXPLODED A083 CLEAR PLT HT-R560(B)DD 28192189 EXPLODED A089 SCREW 3TTB+8B(3BC) 838430088GR EXPLODED A093 REAR PANEL HT-R560MDD/MDC 27123793A <MDD, MDC> EXPLODED A093 REAR PANEL HT-R560MPP 27123794B <MPP>...
  • Page 68 4/69 PAGE Q6055 or 2SC5242-R 2202842 EXPLODED Q6056 2SC5242-O 2202843 EXPLODED Q6056 or 2SC5242-R 2202842 EXPLODED Q6060 2SA1962-O 2202833 EXPLODED Q6060 or 2SA1962-R 2202832 EXPLODED Q6061 2SA1962-O 2202833 EXPLODED Q6061 or 2SA1962-R 2202832 EXPLODED Q6062 2SA1962-O 2202833 EXPLODED Q6062 or 2SA1962-R 2202832 EXPLODED...
  • Page 69 5/69 PAGE F901 FUSE 4A-SE-EAK 252077GR !, <MPP> EXPLODED F901 or FUSE 4A-SE-TL250V 252277GR EXPLODED !, <MPP> F901C LABEL T4AL250V 29361732A EXPLODED <MPP> F6901 FUSE 10A-UL/T-233 252330GR EXPLODED F6901 or FUSE 10A-T/UL-ST2 252333GR EXPLODED F6902 FUSE 10A-UL/T-233 252330GR EXPLODED F6902 or FUSE 10A-T/UL-ST2 252333GR...
  • Page 70 <MPP> EXPLODED U45 or TUNER UNIT FAE485-E11EU 240154 EXPLODED <MPP> HT-R560 PC BOARD PARTS LIST AMPLIFIER PC BOARD (NAAF-9419-1C / 1D) PCB1 TRANS. SEC. TERMINAL PC BOARD (NAPS-9420-1C / 1D) PCB1 THERMAL SENSOR PC BOARD (NAETC-9421-1C / 1D) PCB1 PCB1...
  • Page 71 7/69 PAGE Q5041 2SC2229-Y(TPE6_F) 2211634T PCB1 Q5042 2SC2229-Y(TPE6_F) 2211634T PCB1 Q5043 2SC2229-Y(TPE6_F) 2211634T PCB1 Q5044 2SC2229-Y(TPE6_F) 2211634T PCB1 Q5045 2SC2229-Y(TPE6_F) 2211634T PCB1 Q5046 2SC2229-Y(TPE6_F) 2211634T PCB1 Q5050 2SC2240-BL(TPE2_F) 2211406T PCB1 Q5051 2SC2240-BL(TPE2_F) 2211406T PCB1 Q5052 2SC2240-BL(TPE2_F) 2211406T PCB1 Q5053 2SC2240-BL(TPE2_F) 2211406T PCB1 Q5054...
  • Page 72 8/69 PAGE Q6000 2SC1740S-S 2213285T PCB1 Q6001 2SC1740S-S 2213285T PCB1 Q6002 2SC1740S-S 2213285T PCB1 Q6003 2SC1740S-S 2213285T PCB1 Q6004 2SC1740S-S 2213285T PCB1 Q6005 2SC1740S-S 2213285T PCB1 Q6006 2SC1740S-S 2213285T PCB1 Q6010 2SC1740S-S 2213285T PCB1 Q6011 2SC1740S-S 2213285T PCB1 Q6012 2SC1740S-S 2213285T PCB1 Q6013...
  • Page 73 9/69 PAGE Q6042 or 2SA2140-Q_P 2217151 PCB1 Q6043 2SA1930(ONK_Q) 2203000 PCB1 Q6043 or 2SA2140-Q_P 2217151 PCB1 Q6044 2SA1930(ONK_Q) 2203000 PCB1 Q6044 or 2SA2140-Q_P 2217151 PCB1 Q6045 2SA1930(ONK_Q) 2203000 PCB1 Q6045 or 2SA2140-Q_P 2217151 PCB1 Q6046 2SA1930(ONK_Q) 2203000 PCB1 Q6046 or 2SA2140-Q_P 2217151 PCB1...
  • Page 74 10/69 PAGE D5001 ZENER D MTZJ5.6B 224470562T PCB1 D5002 ZENER D MTZJ5.6B 224470562T PCB1 D5003 ZENER D MTZJ5.6B 224470562T PCB1 D5004 ZENER D MTZJ5.6B 224470562T PCB1 D5005 ZENER D MTZJ5.6B 224470562T PCB1 D5006 ZENER D MTZJ5.6B 224470562T PCB1 D5671 ZENER D MTZJ6.2B 224470622T PCB1...
  • Page 75 11/69 PAGE D5718 or C-DIODE 1SS352 223234R2 PCB1 D5718 or C-DIODE MA2J111 223279R2 PCB1 D5719 DIODE RL1N4003 22380260T PCB1 D6000 C-DIODE KDS4148U 223283R2 PCB1 D6000 or C-DIODE 1SS352 223234R2 PCB1 D6000 or C-DIODE MA2J111 223279R2 PCB1 D6001 C-DIODE KDS4148U 223283R2 PCB1 D6001 or C-DIODE...
  • Page 76 12/69 PAGE D6013 C-DIODE KDS4148U 223283R2 PCB1 D6013 or C-DIODE 1SS352 223234R2 PCB1 D6013 or C-DIODE MA2J111 223279R2 PCB1 D6014 C-DIODE KDS4148U 223283R2 PCB1 D6014 or C-DIODE 1SS352 223234R2 PCB1 D6014 or C-DIODE MA2J111 223279R2 PCB1 D6015 C-DIODE KDS4148U 223283R2 PCB1 D6015 or C-DIODE...
  • Page 77 13/69 PAGE C5000 TF C ECQ-B50V-221K 374722215T PCB1 C5001 TF C ECQ-B50V-221K 374722215T PCB1 C5002 TF C ECQ-B50V-221K 374722215T PCB1 C5003 TF C ECQ-B50V-221K 374722215T PCB1 C5004 TF C ECQ-B50V-221K 374722215T PCB1 C5005 TF C ECQ-B50V-221K 374722215T PCB1 C5006 TF C ECQ-B50V-221K 374722215T PCB1...
  • Page 78 14/69 PAGE C5055 UTSP C CE04W50V 47M(UTSP) 397584707T PCB1 C5056 UTSP C CE04W50V 47M(UTSP) 397584707T PCB1 C5080 CERA C CC45SL50V-040C 345020401T PCB1 C5081 CERA C CC45SL50V-040C 345020401T PCB1 C5082 CERA C CC45SL50V-040C 345020401T PCB1 C5083 CERA C CC45SL50V-040C 345020401T PCB1 C5084 CERA C CC45SL50V-040C...
  • Page 79 15/69 PAGE C5508 C-CERA C CC725CH1H-221J1 342102214R1 PCB1 C5513 C-CERA C CC725CH1H-221J1 342102214R1 PCB1 C5514 C-CERA C CC725CH1H-221J1 342102214R1 PCB1 C5517 C-CERA C CC725CH1H-221J1 342102214R1 PCB1 C5518 C-CERA C CC725CH1H-221J1 342102214R1 PCB1 C5519 TF C ECQ-B50V-221K 374722215T PCB1 C5520 TF C ECQ-B50V-221K 374722215T PCB1...
  • Page 80 16/69 PAGE C5572 UTSP C CE04W25V-47M(UTSP) 397554707T PCB1 C5573 UTSP C CE04W25V-47M(UTSP) 397554707T PCB1 C5574 UTSP C CE04W25V-47M(UTSP) 397554707T PCB1 C5575 UTSP C CE04W25V-47M(UTSP) 397554707T PCB1 C5576 UTSP C CE04W25V-47M(UTSP) 397554707T PCB1 C5590 C-CERA C CC725CH1H-330J1 342103304R1 PCB1 C5591 C-CERA C CC725CH1H-330J1 342103304R1 PCB1...
  • Page 81 17/69 PAGE C6031 TF C ECQ-V50V-473J 374724734T PCB1 C6032 TF C ECQ-V50V-473J 374724734T PCB1 C6033 TF C ECQ-V50V-473J 374724734T PCB1 C6034 TF C ECQ-V50V-473J 374724734T PCB1 C6035 TF C ECQ-V50V-473J 374724734T PCB1 C6036 TF C ECQ-V50V-473J 374724734T PCB1 C6040 UTSP C CE04W50V 47M(UTSP) 397584707T PCB1...
  • Page 82 18/69 PAGE C6911 C-CERA C CC725CH1H-102J1 342101024R1 PCB1 C6912 TF C ECQ-V50V-334J 374723344T PCB1 C6913 TF C ECQ-V50V-334J 374723344T PCB1 C6915 TF C ECQ-V50V-104J 374721044T PCB1 C6916 TF C ECQ-V50V-104J 374721044T PCB1 C9001 MMT C MMT50V-334J 375523344T PCB1 C9003 VR C CE04W35V-1000M(VR) 394661027S PCB1...
  • Page 83 19/69 PAGE R5034 CARBON R R16J-120K 417341244T PCB1 R5035 CARBON R R16J-120K 417341244T PCB1 R5036 CARBON R R16J-120K 417341244T PCB1 R5040 CARBON R R16J-2.2K 417342224T PCB1 R5041 CARBON R R16J-2.2K 417342224T PCB1 R5042 CARBON R R16J-2.2K 417342224T PCB1 R5043 CARBON R R16J-2.2K 417342224T PCB1...
  • Page 84 20/69 PAGE R5092 CARBON R R16J-100K 417341044T PCB1 R5093 CARBON R R16J-100K 417341044T PCB1 R5094 CARBON R R16J-100K 417341044T PCB1 R5095 CARBON R R16J-100K 417341044T PCB1 R5096 CARBON R R16J-100K 417341044T PCB1 R5100 CARBON R R16J-100K 417341044T PCB1 R5101 CARBON R R16J-100K 417341044T PCB1...
  • Page 85 21/69 PAGE R5170 NF CARBON R R25J-150 415471514T PCB1 R5171 NF CARBON R R25J-150 415471514T PCB1 R5172 NF CARBON R R25J-150 415471514T PCB1 R5173 NF CARBON R R25J-150 415471514T PCB1 R5174 NF CARBON R R25J-150 415471514T PCB1 R5175 NF CARBON R R25J-150 415471514T PCB1...
  • Page 86 22/69 PAGE R5235 CARBON R R16J-120K 417341244T PCB1 R5236 CARBON R R16J-120K 417341244T PCB1 R5500 C-CARBON R RN72K1J-331JE 435033314R1 PCB1 R5503 C-CARBON R RN72K1J-331JE 435033314R1 PCB1 R5504 C-CARBON R RN72K1J-331JE 435033314R1 PCB1 R5505 C-CARBON R RN72K1J-222JE 435032224R1 PCB1 R5506 C-CARBON R RN72K1J-222JE 435032224R1 PCB1...
  • Page 87 23/69 PAGE R5550 C-CARBON R RN72K1J-224JE 435032244R1 PCB1 R5553 C-CARBON R RN72K1J-224JE 435032244R1 PCB1 R5554 C-CARBON R RN72K1J-224JE 435032244R1 PCB1 R5555 C-CARBON R RN72K1J-224JE 435032244R1 PCB1 R5556 C-CARBON R RN72K1J-224JE 435032244R1 PCB1 R5557 C-CARBON R RN72K1J-224JE 435032244R1 PCB1 R5558 C-CARBON R RN72K1J-224JE 435032244R1 PCB1...
  • Page 88 24/69 PAGE R5595 C-CARBON R RN72K1J-103JE 435031034R1 PCB1 R5596 C-CARBON R RN72K1J-471JE 435034714R1 PCB1 R5597 C-CARBON R RN72K1J-122JE 435031224R1 PCB1 R5598 C-CARBON R RN72K1J-103JE 435031034R1 PCB1 R5599 C-CARBON R RN72K1J-103JE 435031034R1 PCB1 R5600 C-CARBON R RN72K1J-224JE 435032244R1 PCB1 R5601 C-CARBON R RN72K1J-224JE 435032244R1 PCB1...
  • Page 89 25/69 PAGE R5634 C-CARBON R RN72K1J-103JE 435031034R1 PCB1 R5660 METAL R RNU1WCJ-2.2 453630224T PCB1 R5661 METAL R RNU1WCJ-2.2 453630224T PCB1 R5666 CARBON R R16J-22 417342204T PCB1 R5667 CARBON R R16J-22 417342204T PCB1 R5670 METAL O R RS2WBJ-10 441721004F PCB1 R5671 METAL O R RS2WBJ-27 441722704F...
  • Page 90 26/69 PAGE R6003 CARBON R R16J-5.6K 417345624T PCB1 R6004 CARBON R R16J-5.6K 417345624T PCB1 R6005 CARBON R R16J-5.6K 417345624T PCB1 R6006 CARBON R R16J-5.6K 417345624T PCB1 R6010 CARBON R R16J-3.9K 417343924T PCB1 R6011 CARBON R R16J-3.9K 417343924T PCB1 R6012 CARBON R R16J-3.9K 417343924T PCB1...
  • Page 91 27/69 PAGE R6051 CARBON R R16J-3.3K 417343324T PCB1 R6052 CARBON R R16J-3.3K 417343324T PCB1 R6053 CARBON R R16J-3.3K 417343324T PCB1 R6054 CARBON R R16J-3.3K 417343324T PCB1 R6055 CARBON R R16J-3.3K 417343324T PCB1 R6056 CARBON R R16J-3.3K 417343324T PCB1 R6070 NF CARBON R R25J-120 415471214T PCB1...
  • Page 92 28/69 PAGE R6106 METAL PR MPR2W+2W 0R22 4000234 PCB1 R6130 METAL R RNU1WCJ-8.2 453630824T PCB1 R6131 METAL R RNU1WCJ-8.2 453630824T PCB1 R6132 METAL R RNU1WCJ-8.2 453630824T PCB1 R6133 METAL R RNU1WCJ-8.2 453630824T PCB1 R6134 METAL R RNU1WCJ-8.2 453630824T PCB1 R6135 METAL R RNU1WCJ-8.2 453630824T...
  • Page 93 29/69 PAGE R6174 CARBON R R16J-47K 417344734T PCB1 R6175 CARBON R R16J-47K 417344734T PCB1 R6176 CARBON R R16J-47K 417344734T PCB1 R6180 CARBON R R16J-47K 417344734T PCB1 R6181 CARBON R R16J-47K 417344734T PCB1 R6182 CARBON R R16J-47K 417344734T PCB1 R6183 CARBON R R16J-47K 417344734T PCB1...
  • Page 94 30/69 PAGE P304 PLUG NPLG-3P0958 25056008 PCB1 P5505 TRM-423(SCREW) 25060495 PCB1 P6080 PLUG NPLG-2P130 25055146 PCB1 P6081 PLUG NPLG-2P130 25055146 PCB1 P6082 PLUG NPLG-2P130 25055146 PCB1 P6083 PLUG NPLG-2P130 25055146 PCB1 P6084 PLUG NPLG-2P130 25055146 PCB1 P6085 PLUG NPLG-2P130 25055146 PCB1 P6086 PLUG...

  • Page 95: U10 Display Pc Board (Nadis

    31/69 PAGE JL5502 JUMPER LEAD JL9 300 B PCB1 JL5502A WIRE HOL NSCT-9P880 25051093 PCB1 JL6402 JUMPER LEAD JL3 300 B PCB1 JL6402A WIRE HOL NSCT-3P874 25051087 PCB1 JL6600 JUMPER LEAD JL7 250 H PCB1 JL6600A WIRE HOL NSCT-7P898 25051111 PCB1 JL6603 JUMPER LEAD...
  • Page 96 32/69 PAGE Q7033 or 2SC1815-GR 2211255T PCB2 Q7401 NJM4580D-D 22241112 PCB2 Q7403 KRC111M 2216320T PCB2 Q7403 or DTC114TS 221299T PCB2 Q7404 KRC111M 2216320T PCB2 Q7404 or DTC114TS 221299T PCB2 D7002 ZENER D MTZJ8.2B 224470822T PCB2 D7033 ZENER D MTZJ3.9B 224470392T PCB2 D7151 SLI-343URC-TE7...
  • Page 97 33/69 PAGE C901 or IS C ECQU2A103MLC 3800039S PCB2 C902 TF C ECQ-V50V-104J 374721044T PCB2 C911 TF C ECQ-B50V-102J 374721024T PCB2 C921 CERA C CK45F50V-223Z 335622230T PCB2 C922 VR C CE04W16V-2200M(VR) 394642227S <MPP> PCB2 C922 VR C CE04W25V-2200M(VR) 394652227S <MDD, MDC> PCB2 C930 UTSP C...
  • Page 98 34/69 PAGE C7203 TF C ECQ-B50V-102J 374721024T PCB2 C7204 TF C ECQ-B50V-102J 374721024T PCB2 C7301 TF C ECQ-B50V-471J 374724714T PCB2 C7302 TF C ECQ-B50V-471J 374724714T PCB2 C7303 MMT C MMT50V-104J 375521044T PCB2 C7304 MMT C MMT50V-104J 375521044T PCB2 C7305 MMT C MMT50V-104J 375521044T PCB2...
  • Page 99 35/69 PAGE R7101 CARBON R R16J-330 417343314T PCB2 R7102 CARBON R R16J-470 417344714T PCB2 R7103 CARBON R R16J-560 417345614T PCB2 R7104 CARBON R R16J-820 417348214T PCB2 R7105 CARBON R R16J-1.2K 417341224T PCB2 R7107 CARBON R R16J-330 417343314T PCB2 R7108 CARBON R R16J-470 417344714T PCB2...
  • Page 100 36/69 PAGE R7402 CARBON R R16J-220K 417342244T PCB2 R7403 CARBON R R16J-4.7K 417344724T PCB2 R7404 CARBON R R16J-220 417342214T PCB2 R7405 CARBON R R16J-47K 417344734T PCB2 R7406 CARBON R R16J-330 417343314T PCB2 R7407 CARBON R R16J-1K 417341024T PCB2 R7408 CARBON R R16J-33K 417343334T PCB2...
  • Page 101 37/69 PAGE S7138 PUSH SW NPS-111-S681 25035718T PCB2 S7140 PUSH SW NPS-111-S681 25035718T PCB2 S7142 PUSH SW NPS-111-S681 25035718T PCB2 S7144 PUSH SW NPS-111-S681 25035718T PCB2 S7146 PUSH SW NPS-111-S681 25035718T PCB2 S7148 PUSH SW NPS-111-S681 25035718T PCB2 S7149 PUSH SW NPS-111-S681 25035718T PCB2...
  • Page 102 38/69 PAGE JL6605A WIRE HOL NSCT-5P896 25051109 PCB2 JL7101 JUMPER LEAD JL9 200 H PCB2 JL7101A WIRE HOL NSCT-9P900 25051113 PCB2 JL7101B WIRE HOL NSCT-9P900 25051113 PCB2 JL9101 JUMPER LEAD JL7 350 H PCB2 JL9101A WIRE HOL NSCT-7P898 25051111 PCB2 MICROPROCESSOR PC BOARD (NADG-9457-1F / 1G) PCB3 XM/SIRIUS PC BOARD (NADG-9457-1F / 1G)
  • Page 103 39/69 PAGE Q746 or TA48033BF(TE16L_NQ) 22278033DBR2TO PCB3 Q746 or NJM2391DL1-33 22278033DR2JR PCB3 Q746 or BA33BC0FP 22278033DR2RH PCB3 Q751 KRC104S 2216210R2 PCB3 Q751 or RN1404 2214490R2 PCB3 Q752 KRA102S 2216220R2 PCB3 Q752 or RN2402 2214530R2 PCB3 Q753 KRA107S 2216350R2 PCB3 Q753 or RN2407(TE85L_F) 2216360R2 PCB3...
  • Page 104 40/69 PAGE D705 or C-DIODE MA2J111 223279R2 PCB3 D706 C-DIODE KDS4148U 223283R2 PCB3 D706 or C-DIODE 1SS352 223234R2 PCB3 D706 or C-DIODE MA2J111 223279R2 PCB3 D2082 C-DIODE KDS4148U 223283R2 PCB3 D2082 or C-DIODE 1SS352 223234R2 PCB3 D2082 or C-DIODE MA2J111 223279R2 PCB3 D2083...
  • Page 105 41/69 PAGE L2086 CHOKE COIL BLM21PG221SN1 230949R2 PCB3 C102 C-CERA C CK725F1E-104Z1 332161040R1 PCB3 C103 VR C CE04W16V-100M(VR) 394641017T PCB3 C104 C-CERA C CK725F1E-104Z1 332161040R1 PCB3 C106 C-CERA C CK725F1E-104Z1 332161040R1 PCB3 C107 C-CERA C CK725F1E-104Z1 332161040R1 PCB3 C109 C-CERA C CK725F1E-104Z1 332161040R1 PCB3...
  • Page 106 42/69 PAGE C308 UTSP C CE04W10V-100M(UTSP) 397531017T PCB3 C309 C-CERA C CK725F1E-104Z1 332161040R1 PCB3 C310 C-CERA C CK725B1H-222K1 332102225R1 PCB3 C311 C-CERA C CK725B1H-473K1 332104735R1 PCB3 C312 C-CERA C CK725F1E-104Z1 332161040R1 PCB3 C313 C-CERA C CK725F1E-104Z1 332161040R1 PCB3 C314 C-CERA C CK725F1E-104Z1 332161040R1 PCB3...
  • Page 107 43/69 PAGE C414 TF C ECQ-B50V-153J 374721534T PCB3 C415 C-CERA C CC725CH1H-681J1 342106814R1 PCB3 C416 C-CERA C CC725CH1H-681J1 342106814R1 PCB3 C417 C-CERA C CC725CH1H-681J1 342106814R1 PCB3 C418 C-CERA C CC725CH1H-681J1 342106814R1 PCB3 C421 TF C ECQ-B50V-681J 374726814T PCB3 C422 TF C ECQ-B50V-681J 374726814T PCB3...
  • Page 108 44/69 PAGE C619 C-CERA C CK725B1H-102K1 332101025R1 PCB3 C620 C-CERA C CK725B1H-102K1 332101025R1 PCB3 C621 C-CERA C CK725B1H-102K1 332101025R1 PCB3 C624 C-CERA C CK725F1E-104Z1 332161040R1 PCB3 C625 C-CERA C CK725F1E-104Z1 332161040R1 PCB3 C634 C-CERA C CC725CH1H-101J1 342101014R1 PCB3 C635 C-CERA C CC725CH1H-101J1 342101014R1 PCB3...
  • Page 109 45/69 PAGE R104 C-CARBON R RN72K1J-000JE 435030004R1 <MPP> PCB3 R105 C-CARBON R RN72K1J-103JE 435031034R1 PCB3 R106 C-CARBON R RN72K1J-000JE 435030004R1 PCB3 <MDD, MDC> R107 C-CARBON R RN72K1J-000JE 435030004R1 <MDD, MDC> PCB3 R108 C-CARBON R RN72K1J-105JE 435031054R1 PCB3 R109 C-CARBON R RN72K1J-221JE 435032214R1 PCB3...
  • Page 110 46/69 PAGE R309 C-CARBON R RN72K1J-221JE 435032214R1 PCB3 R311 C-CARBON R RN72K1J-272JE 435032724R1 PCB3 R312 C-CARBON R RN72K1J-470JE 435034704R1 PCB3 R313 C-CARBON R RN72K1J-151JE 435031514R1 PCB3 R314 C-CARBON R RN72K1J-331JE 435033314R1 PCB3 R315 C-CARBON R RN72K1J-470JE 435034704R1 PCB3 R316 C-CARBON R RN72K1J-470JE 435034704R1 PCB3...
  • Page 111 47/69 PAGE R411 C-CARBON R RN72K1J-332JE 435033324R1 PCB3 R412 C-CARBON R RN72K1J-332JE 435033324R1 PCB3 R413 C-CARBON R RN72K1J-332JE 435033324R1 PCB3 R414 C-CARBON R RN72K1J-332JE 435033324R1 PCB3 R415 C-CARBON R RN72K1J-332JE 435033324R1 PCB3 R416 C-CARBON R RN72K1J-332JE 435033324R1 PCB3 R417 C-CARBON R RN72K1J-332JE 435033324R1 PCB3...
  • Page 112 48/69 PAGE R452 C-CARBON R RN72K1J-472JE 435034724R1 PCB3 R453 C-CARBON R RN72K1J-472JE 435034724R1 PCB3 R454 C-CARBON R RN72K1J-472JE 435034724R1 PCB3 R455 C-CARBON R RN72K1J-472JE 435034724R1 PCB3 R456 C-CARBON R RN72K1J-472JE 435034724R1 PCB3 R457 C-CARBON R RN72K1J-472JE 435034724R1 PCB3 R458 C-CARBON R RN72K1J-472JE 435034724R1 PCB3...
  • Page 113 49/69 PAGE R601 C-CARBON R RN72K1J-473JE 435034734R1 PCB3 R604 C-CARBON R RN72K1J-221JE 435032214R1 PCB3 R605 C-CARBON R RN72K1J-470JE 435034704R1 PCB3 R606 C-CARBON R RN72K1J-221JE 435032214R1 PCB3 R607 C-CARBON R RN72K1J-221JE 435032214R1 PCB3 R608 C-CARBON R RN72K1J-221JE 435032214R1 PCB3 R609 C-CARBON R RN72K1J-103JE 435031034R1 PCB3...
  • Page 114 50/69 PAGE R640 C-CARBON R RN72K1J-470JE 435034704R1 PCB3 R641 C-CARBON R RN72K1J-470JE 435034704R1 PCB3 R642 C-CARBON R RN72K1J-470JE 435034704R1 PCB3 <MDD, MDC> R643 C-CARBON R RN72K1J-470JE 435034704R1 PCB3 R644 C-CARBON R RN72K1J-221JE 435032214R1 <MDD, MDC> PCB3 R645 C-CARBON R RN72K1J-103JE 435031034R1 PCB3 R646...
  • Page 115 51/69 PAGE R678 C-CARBON R RN72K1J-103JE 435031034R1 PCB3 R679 C-CARBON R RN72K1J-273JE 435032734R1 PCB3 R680 C-CARBON R RN72K1J-273JE 435032734R1 PCB3 R682 C-CARBON R RN72K1J-470JE 435034704R1 PCB3 R683 C-CARBON R RN72K1J-470JE 435034704R1 PCB3 R684 C-CARBON R RN72K1J-470JE 435034704R1 PCB3 R685 C-CARBON R RN72K1J-221JE 435032214R1 PCB3...
  • Page 116 52/69 PAGE R709 C-CARBON R RN72K1J-333JE 435033334R1 <MPP> PCB3 R710 C-CARBON R RN72K1J-103JE 435031034R1 PCB3 <MPP> R711 C-CARBON R RN72K1J-470JE 435034704R1 PCB3 R712 C-CARBON R RN72K1J-102JE 435031024R1 PCB3 R713 C-CARBON R RN72K1J-222JE 435032224R1 PCB3 R714 C-CARBON R RN72K1J-103JE 435031034R1 PCB3 R719 C-CARBON R RN72K1J-222JE...
  • Page 117 53/69 PAGE R2088 C-CARBON R RN72K1J-224JE 435032244R1 PCB3 R2089 C-CARBON R RN72K1J-000JE 435030004R1 PCB3 R2091 C-CARBON R RN72K1J-334JE 435033344R1 PCB3 R2092 C-CARBON R RN72K1J-000JE 435030004R1 PCB3 R2104 C-CARBON R RN72K1J-333JE 435033334R1 PCB3 R2105 C-CARBON R RN72K1J-333JE 435033334R1 PCB3 R2106 C-CARBON R RN72K1J-333JE 435033334R1 PCB3...
  • Page 118 54/69 PAGE VIDEO PC BOARD (NAVD-9467-1E / 1F) PCB4 SPEAKER TERMINAL PC BOARD (NATRM-9468-1E / 1F) PCB4 PCB4 CIRCUIT NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS PCB4 Q3001 AN15880A-VT 22242319R3 PCB4 Q6601 KRC105S 2217290R2 PCB4 Q6601 or RN1405 2214500R2 PCB4 Q6602...
  • Page 119 55/69 PAGE D6603 or C-DIODE MA2J111 223279R2 PCB4 D6605 C-DIODE KDS4148U 223283R2 PCB4 D6605 or C-DIODE 1SS352 223234R2 PCB4 D6605 or C-DIODE MA2J111 223279R2 PCB4 D6607 C-DIODE KDS4148U 223283R2 PCB4 D6607 or C-DIODE 1SS352 223234R2 PCB4 D6607 or C-DIODE MA2J111 223279R2 PCB4 D9001...
  • Page 120 56/69 PAGE L6604 S COIL S-1.3C 231176S <MPP> PCB4 L6605 S COIL S-1.3C 231176S PCB4 <MPP> L6606 S COIL S-1.3C 231176S PCB4 <MPP> C3001 VR C CE04W16V-100M(VR) 394641017T PCB4 C3002 C-CERA C CK725F1E-104Z1 332161040R1 PCB4 C3003 UTSP C CE04W50V-22M(UTSP) 397582207T PCB4 C3004 VR C...
  • Page 121 57/69 PAGE C3039 C-CERA C CK725B1H-102K1 332101025R1 PCB4 C3040 UTSP C CE04W50V-10M(UTSP) 397581007T PCB4 C3041 UTSP C CE04W50V-10M(UTSP) 397581007T PCB4 C3042 C-CERA C CK725F1E-104Z1 332161040R1 PCB4 C3043 C-CERA C CK725B1H-102K1 332101025R1 PCB4 C3044 UTSP C CE04W50V-10M(UTSP) 397581007T PCB4 C3045 UTSP C CE04W50V-10M(UTSP) 397581007T PCB4...
  • Page 122 58/69 PAGE C6646 TF C ECQ-B50V-103J 374721034T <MPP> PCB4 C6650 TF C ECQ-B50V-102J 374721024T PCB4 <MPP> C6651 TF C ECQ-B50V-102J 374721024T PCB4 <MPP> C6652 TF C ECQ-B50V-102J 374721024T <MPP> PCB4 C6653 TF C ECQ-B50V-102J 374721024T <MPP> PCB4 C6654 TF C ECQ-B50V-102J 374721024T <MPP>...
  • Page 123 59/69 PAGE R3021 C-CARBON R RN72K1J-750JE 435037504R1 PCB4 R3022 C-CARBON R RN72K1J-750JE 435037504R1 PCB4 R3023 C-CARBON R RN72K1J-750JE 435037504R1 PCB4 R3024 C-CARBON R RN72K1J-750JE 435037504R1 PCB4 R3025 C-CARBON R RN72K1J-750JE 435037504R1 PCB4 R3026 C-CARBON R RN72K1J-750JE 435037504R1 PCB4 R3027 C-CARBON R RN72K1J-750JE 435037504R1 PCB4...
  • Page 124 60/69 PAGE R3070 C-CARBON R RN72K1J-000JE 435030004R1 PCB4 R3071 C-CARBON R RN72K1J-000JE 435030004R1 PCB4 R3072 C-CARBON R RN72K1J-000JE 435030004R1 PCB4 R3073 C-CARBON R RN72K1J-000JE 435030004R1 PCB4 R3074 C-CARBON R RN72K1J-000JE 435030004R1 PCB4 R3075 C-CARBON R RN72K1J-000JE 435030004R1 PCB4 R3089 C-CARBON R RN72K1J-750JE 435037504R1 PCB4...
  • Page 125 61/69 PAGE R9029 METAL R RNU1WCJ-0.22 453632294T PCB4 R9030 METAL O R RS2WBJ-22 442722204F PCB4 R9031 METAL R RNU2WCJ-3.3 452730334F PCB4 R9032 METAL R RNU2WCJ-3.3 452730334F PCB4 R9033 METAL R RNU1/2WCJ-1 453530104T PCB4 R9035 METAL R RNU1/2WCJ-1 453530104T PCB4 RL6600 RELAY NRL-2P5A-DC24-129 25065563A...
  • Page 126 62/69 PAGE There are the following two types of colors of the speaker terminal of HT-R560 by the specification change. PCB4 Type-A PCB4 Color ---> FL : Red-Black, FR : Red-Black, C : Red-Black, SL : Red-Black, SR : Red-Black, SBL : Red-Black, SBR : Red-Black...
  • Page 127 63/69 PAGE Q281 M12L64164A-7TG 22242441R3 PCB5 Q281 or K4S641632K-UC60 22242462R2 PCB5 Q282 IC (DSP ROM) ES29LV160ET-70TG (0271) 222W0069R302716 PCB5 Q282 or IC (DSP ROM) S29AL016D70TFI010 (0271) 222W0063R302716 PCB5 Q8001 TMDS341APFCR 22242491R2 PCB5 Q8002 TA48033AF(TE16L_NQ) 22278033DR2TO PCB5 Q8002 or TA48033BF(TE16L_NQ) 22278033DBR2TO PCB5 Q8002 or BA33BC0FP...
  • Page 128 64/69 PAGE X202 CRYSTAL HC-49USSMD17.734MHz 3010442R2 PCB5 X202A IB CUSHION W15*3t TAPE 28141585 PCB5 L201 CHOKE COIL BLM21PG221SN1 230949R2 PCB5 L202 CHOKE COIL BLM21PG221SN1 230949R2 PCB5 L203 C-CARBON R RN72K1J-000JE 435030004R1 PCB5 L204 EMIFIL BK1608LM182-T 230958R1 PCB5 L205 CHOKE COIL LBC2518T470M 231364M470R2 PCB5...
  • Page 129 65/69 PAGE C216 C-CERA C CK725F1E-104Z1 332161040R1 PCB5 C217 C-CERA C CK725F1E-104Z1 332161040R1 PCB5 C218 CHIP ELECT C CEWX4V-220M 3981G2217R2 PCB5 C219 C-CERA C CK725F1E-104Z1 332161040R1 PCB5 C221 C-CERA C CK725F1E-104Z1 332161040R1 PCB5 C222 C-CERA C CK725F1E-104Z1 332161040R1 PCB5 C223 C-CERA C CK725F1E-104Z1 332161040R1...
  • Page 130 66/69 PAGE C286 C-CERA C CK725F1E-104Z1 332161040R1 PCB5 C287 C-CERA C CK725F1E-104Z1 332161040R1 PCB5 C288 C-CERA C CK725F1E-104Z1 332161040R1 PCB5 C289 C-CERA C CK725F1E-104Z1 332161040R1 PCB5 C290 C-CERA C CK725F1E-104Z1 332161040R1 PCB5 C291 C-CERA C CK725F1E-104Z1 332161040R1 PCB5 C295 C-CERA C CK725F1E-104Z1 332161040R1 PCB5...
  • Page 131 67/69 PAGE C8072 CHIP ELECT C CEWX4V-100M 3981G1017R2 PCB5 C8073 CHIP ELECT C CEWX16V-10M 398141007R2 PCB5 C8074 C-CERA C CK725F1E-104Z1 332161040R1 PCB5 C8075 CD C UCD1A471MNL1GS 396634717R2 PCB5 C8076 CD C UCD1E221MNL1GS 396652217R2 PCB5 C8077 C-CERA C CK725B1H-223K1 332102235R1 PCB5 C8078 C-CERA C CK725F1E-104Z1...
  • Page 132 68/69 PAGE R263 C-CARBON R RN72K1J-331JE 435033314R1 PCB5 R264 C-CARBON R RN72K1J-331JE 435033314R1 PCB5 R265 C-CARBON R RN72K1J-331JE 435033314R1 PCB5 R266 C-CARBON R RN72K1J-331JE 435033314R1 PCB5 R267 C-CARBON R RN72K1J-470JE 435034704R1 PCB5 R268 C-CARBON R RN72K1J-221JE 435032214R1 PCB5 R269 C-CARBON R RN72K1J-470JE 435034704R1 PCB5...
  • Page 133 69/69 PAGE R8019 C-CARBON R RN72K1J-103JE 435031034R1 PCB5 R8020 C-CARBON R RN72K1J-182JE 435031824R1 PCB5 R8021 C-CARBON R RN72K1J-000JE 435030004R1 PCB5 R8022 C-CARBON R RN72K1J-473JE 435034734R1 PCB5 R8023 C-CARBON R RN72K1J-182JE 435031824R1 PCB5 R8024 C-CARBON R RN72K1J-182JE 435031824R1 PCB5 R8027 C-CARBON R RN72K1J-000JE 435030004R1 PCB5...
  • Page 134 Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Tel: 072-831-8023 Fax: 072-831-8163 ONKYO U.S.A. CORPORATION 18 Park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 201-785-2600 Fax: 201-785-2650 http://www.us.onkyo.com/ ONKYO EUROPE ELECTRONICS GmbH Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY Tel: +49-8142-4401-0 Fax: +49-8142-4401-555 http://www.eu.onkyo.com/...
