Onkyo HTP-780 Service Manual

7.1-CH HOME THEATER
MODEL
Front Speakers (L / R)
"SKF-780"
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
SERVICE MANUAL SERVICE MANUAL
SPEAKER PACKAGE
HTP-780(B)
Surround Speakers (L / R)
Center Speaker
"SKC-780"
Surround Back Speakers (L / R)
Black model
B MDC 120V AC, 60Hz
Powered Subwoofer
"SKR-780"
"SKB-780"
ON THE
HTP-780
Ref. No. 4229
062010
"SKW-780"
