PowerLite
Home Cinema 640/740HD/1040
®

Quick Setup

Before using the projector, make sure you read the safety instructions in the
online User's Guide.
Connect the projector
Choose from the following connections. See the sections below or the online
User's Guide for details.

Video device

Connect multiple video devices and use the Source Search button on the
projector or the remote control to switch between them.
PowerLite Home Cinema 640/740HD
PowerLite Home Cinema 1040
Computer
Connect one end of an HDMI cable to the projector's HDMI port and the other
end to an HDMI port on your computer.
Note: For more information on connecting the projector to your computer or
other devices (camera, USB flash drive, etc.), see the online User's Guide.
Mobile media device (PowerLite Home Cinema 1040)
Connect tablets, smartphones, and other devices that support the MHL
standard to the HDMI2/MHL port.
Some devices may require an adapter or may not require an MHL cable. Not all
features or functions may be supported. Check your device's documentation for
more information.
S-Video cable
Component video
to VGA cable
HDMI cable
RCA video cable
(composite video)
HDMI cable
Component video
to VGA cable
RCA video cable
(composite video)
MHL cable
Connect audio
Built-in speaker
The projector has a built-in speaker that can play audio from a video source
(DVD player, streaming device, etc.) connected by an HDMI cable. If you do not
use an HDMI connection, you must connect your device's audio output to the
projector's audio input.
PowerLite Home Cinema 640/740HD
PowerLite Home Cinema 1040
External speakers
Connect your device's audio output to your home theater receiver or powered
speakers.
Note: The internal speaker is disabled when an external device is connected.
If you are using an HDMI connection to the projector, you may need to reduce
the projector speaker volume to zero (0), or make sure that the correct audio
output is selected on your device.
Home theater system
Video source
Surround sound
Powered speakers
External speakers
Video source
Note: See your home theater receiver documentation for more information
on connections.
Turn on your equipment
1
Turn on your video source or computer.
2
Plug in the projector. The
HDMI cable
Audio cable
HDMI cable
Audio cable
Video cable
Receiver
Projector
Video cable
Projector
power light on the projector turns blue.
