Motorola KEM-ML34301B User Manual

®
Two-Way Radio
User Guide
KEM ML34301B
For More Information
For further information, you may call Motorola Solutions, Inc.
at 1-800-448-6686 (US and Canada) e-mail us at
consumerradio@motorolasolutions.com or visit us on the
Internet at www.motorolasolutions.com/talkabout.
Safety and General Information
Important Information on Safe and Efficient Operation
Read This Information Before Using Your Radio.
The information provided in this document supersedes the
general safety information in user guides published prior to
December 1, 2002.
Transmit and Receive Procedure
Your two-way radio contains a transmitter and a receiver. To
control your exposure and ensure compliance with the general
population/ uncontrolled environment exposure limits, always
adhere to the following procedure:
• Transmit no more than 50% of the time.
• To receive calls, release the PTT button.
• To transmit (talk), press the Push to Talk (PTT) button.
Transmitting 50% of the time, or less, is important because the
radio generates measurable RF energy exposure only when
transmitting (in terms of measuring standards compliance).
Exposure to Radio Frequency Energy
Your Motorola two-way radio complies with the following RF
energy exposure standards and guidelines:
• United States Federal Communications Commission, Code of
Federal Regulations; 47CFR part 2 sub-part J.
• American National Standards Institute (ANSI)/Institute of
Electrical and Electronic Engineers (IEEE) C95. 1-1992.
• Institute of Electrical and Electronics Engineers (IEEE) C95.
1-1999 Edition.
• International Commission on Non-Ionizing Radiation
Protection (ICNIRP) 1998.
• Ministry of Health (Canada) Safety Code 6. Limits of Human
Exposure to Radiofrequency Electromagnetic Fields in the
Frequency Range from 3 KHz to 300 GHz, 1999.
• Australian Communications Authority Radiocommunications
(Electromagnetic Radiation—Human Exposure) Standard,
2003.
• ANATEL ANNEX to Resolution No. 303 of July 2, 2002.
• ANATEL ANNEX to Resolution No. 533 of September 10, 2009.
To ensure optimal radio performance and make sure human
exposure to radio frequency electromagnetic energy is within
the guidelines set forth in the above standards, always adhere
to the following procedures.
Portable Radio Operation and EME Exposure
Ant enna Car e
Use only the supplied or an approved replacement antenna.
Unauthorized antennas, modifications, or attachments could
damage the radio and may violate FCC regulations.
Do NOT hold the antenna when the radio is "IN USE." Holding
the antenna affects its effective range.
Body- W or n Oper at i on
To maintain compliances with FCC/Health Canada RF exposure
guidelines if you wear a radio on your body when transmitting
always place the radio in a Motorola-supplied or approved clip
holder, holster, case or body harness for this product. Use of
non-Motorola-approved accessories may exceed FCC/Health
Canada RF exposure guidelines.
If you do not use one of the Motorola-supplied or approved
body-worn accessories and are not using the radio held in the
normal use position, ensure the radio and its antenna are at
least 1 inch (2.5 cm) from your body when transmitting.
Dat a Oper at i on
If applicable, when using any data feature of the radio with or
without an accessory cable, position the radio and its antenna
at least one inch (2.5 cm) from the body.
Appr oved Audi o Accessor i es
MT Series
• 53724: Remote Speaker with Push-to-Talk Microphone
• 53725: Headset with Swivel Boom Microphone
• 53727: Earbud with Push-to-Talk Microphone
• 53728: Flexible Ear Receiver
• 56320: Earpiece with Boom Microphone
Electromagnetic Interference/Compatibility
Note: Nearly every electronic device is susceptible to
electromagnetic interference (EMI) if inadequately shielded,
designed or otherwise configured for electromagnetic
compatibility. This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference; and
2. This device must accept any interference received,
including interference that may cause undesired operation.
I C Canada
The term "IC:" before the equipment certification number only
signifies that the Industry Canada technical specifications were
met.
Faci l i t i es
To avoid electromagnetic interference and/or compatibility
conflicts, turn off your radio in any facility where posted notices
instruct you to do so. Hospitals or health care facilities may be
using equipment that is sensitive to external RF energy.
Ai r cr af t
When instructed to do so, turn off your radio when onboard an
aircraft. Any use of a radio must be in accordance with
applicable regulations per airline crew instructions.
M edi calDevi ces– Pacem aker s
The Advanced Medical Technology Association recommends
that a minimum separation of 6 inches (15 cm) be maintained
between a handheld wireless radio and a pacemaker. These
recommendations are consistent with the independent research
by and recommendations of the U.S. Food and Drug
Administration.
People with pacemakers should:
• ALWAYS keep the radio more than 6 inches (15 cm) from
their pacemaker when the radio is turned ON.
• Not carry the radio in the breast pocket.
• Use the ear opposite the pacemaker to minimize the
potential for interference.
• Turn the radio OFF immediately if there is any reason to
suspect that interference is taking place.
M edi calDevi ces– Hear i ng Ai ds
Some digital wireless radios may interfere with some hearing
aids. In the event of such interference, you may want to consult
your hearing aid manufacturer to discuss alternatives.
M edi calDevi ces– Ot her
If you use any other personal medical device, consult the
manufacturer of your device to determine if it is adequately
shielded from RF energy. Your physician may be able to assist
you in obtaining this information.
Safety and General Use While Driving
Check the laws and regulations regarding the use of radios in
the area where you drive, and always obey them. If you do use
your radio while driving, please:
•
•
•
The use of a two-way radio while engaged in activities requiring
concentration may cause distraction or otherwise impair your
ability to safely participate in such activities. Always use
technology safely.
Do not place a portable radio in the area over an air bag or in the
air bag deployment area. Air bags inflate with great force. If a
portable radio is placed in the air bag deployment area and the
air bag inflates, the radio may be propelled with great force and
cause serious injury to occupants of the vehicle.
Pot ent i al l yExpl osi ve At m ospher es
Turn off your radio prior to entering any area with a potentially
explosive atmosphere. Only radio types that are especially
qualified should be used in such areas as "Intrinsically Safe."
Do not remove, install or charge batteries in such areas. Sparks
in a potentially explosive atmosphere can cause an explosion or
fire resulting in bodily injury or even death.
Note: The areas with potentially explosive atmospheres referred
to above include fueling areas such as below decks on boats,
fuel or chemical transfer or storage facilities, areas where the air
contains chemicals or particles (such as grain, dust or metal
powders) and any other area where you would normally be
advised to turn off your vehicle engine. Areas with potentially
explosive atmospheres are often—but not always—posted.
Bl ast i ng Capsand Ar eas
To avoid possible interference with blasting operations, turn off
your radio when you are near electrical blasting caps, in a
blasting area, or in areas posted "Turn off two-way radios."
Obey all signs and instructions.
Operational Cautions
Ant ennas
Do not use any portable radio that has a damaged antenna. If a
damaged antenna comes into contact with your skin, a minor
burn can result.
Bat t er i es
All batteries can cause property damage and/or bodily injury such
as burns if a conductive material—like jewelry, keys or beaded
chains— touch exposed terminals. The conductive material may
complete an electrical circuit (short circuit) and become quite hot.
Exercise care in handling any charged battery, particularly when
placing it inside a pocket, purse or other container with metal
objects.
Exercise care when removing NiMH or AA batteries. Do not use
sharp or conductive tools to remove either of these batteries.
Bat t er yChar gerSaf et yI nst r uct i ons:
Save these Instructions
1. Do not expose the charger to rain or snow.
2. Do not operate or disassemble the charger if it has received
3. Never alter the AC cord or plug provided with the unit. If the
4. To reduce the risk of damage to the cord or plug, pull the
5. To reduce the risk of electric shock, unplug the charger from
6. Use of an attachment not recommended or sold by Motorola
7. Make sure the cord is located so it will not be stepped on,
1
Give full attention to driving and to the road.
Use hands-free operation, if available.
Pull off the road and park before making or answering a call
if driving conditions so require.
a sharp blow, or has been dropped or damaged in any way.
plug will not fit the outlet, have the proper outlet installed by
a qualified electrician. An improper condition can result in a
risk of electric shock.
plug rather than the cord when disconnecting the charger
from the AC receptacle.
the outlet before attempting any maintenance or cleaning.
may result in a risk of fire, electric shock or personal injury.
tripped over or subjected to damage or stress.
MT Series
