1
Introduction
Wake-On-LAN
The Wake-On-LAN function is applicable only when you are using a
LAN add-in card that has the same function. It allows the network
to remotely wake up a Soft Power Down (Soft-Off) PC. Your LAN
card must support the remote wakeup function. Refer to "Wake-On-
LAN Connector" in chapter 2 and "Resume On LAN" in the Power
Management Setup section in chapter 3 for more information.
Wake-On-Keyboard
This function allows you to use the keyboard to power-on the
system. Refer to "Keyboard Power On" ("Onboard Super IO
Device" field) in the Integrated Peripherals section in chapter 3 for
more information.
Wake-On-USB Keyboard
The Wake-On-USB Keyboard function allows you to use a USB
keyboard to wake up a system that is in the S3 (STR - Suspend To
RAM) state. Refer to "USB KB Wake-Up From S3" in the Power
Management Setup section in chapter 3 for more information.
12
Important:
The 5VSB power source of your power supply must support
≥ 720mA.
Important:
• The power button will not function once a keyboard
password has been set in the "KB Power On Password"
field of the Integrated Peripherals submenu. You must type
the correct password to power-on the system. If you forgot
the password, power-off the system and remove the
battery. Wait for a few seconds and install it back before
powering-on the system.
• The 5VSB power source of your power supply must
support ≥ 720mA.
Important:
• If you are using the Wake-On-USB Keyboard function for 2
USB ports, the 5VSB power source of your power supply
must support ≥ 1.5A.
