- Page 1 LCD display solutions User Manual 17” High Brightness LCD HAP-17 Front NEMA4 / IP65 HOP-17 Universal Mounting Open Frame Designed and manufactured by Austin Hughes UM-UV-621-H17-Q414V4 www.austin-hughes.com...
- Page 2 Legal Information First English printing, October 2002 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
-
Page 3: Table Of Contents
Package Content Structure Diagram & Dimension P.2 - 3 Mounting Hardware & Installation P.4 - 5 < Part. 2 > HOP-17 Package Content Structure Diagram & Dimension P.7 - 8 Mounting Hardware & Installation < Part. 3 > Specifi cations / OSD Product Specifi... -
Page 4: Before Installation
Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content. -
Page 5: Package Content
< Part 1 > < 1.1 > Package Content - HAP-17 17" High Brightness LCD Display HAP-17 17" High Brightness LCD display X 1 6ft VGA cable X 1 Power adapter X 1 Power cord X 1 Mounting hardware X 1 pack - Mounting bracket x 4 pcs - M4* 6mm screw x 8 pcs - M4* 50mm screw x 8 pcs... - Page 6 < 1.2 > Structure Diagram - HAP-17 Front view HAP-17 Rear view Rear case LCD panel Protective 3mm glass 6mm aluminum front bazel Audio speaker ( for HDMI, Audio or TV option ) LCD membrane Remote sensor Product Dimension Packing Dimension Gross Model (W x D x H)
- Page 7 < 1.2 > Dimension - HAP-17 17” High Brightness LCD Display Front View Side View HAP-17 Rear View UNIT : mm 1mm = 0.03937 inch Bottom View UM-UV-621-H17-Q414V4 www.austin-hughes.com...
- Page 8 < 1.3 > Mounting Hardware - HAP-17 M4*50mm screw M4*6mm screw Mounting bracket x 8 pcs x 8 pcs x 4 pcs Hardware set part no. UV-BK#2 Steps ■ Install 4 mounting brackets with 8 x M4*6mm screws ■ Adjust the LCD panel with 8 x M4*50mm screws and fi x it on the surface. UM-UV-621-H17-Q414V4 www.austin-hughes.com...
- Page 9 < 1.3 > Installation - HAP-17 17” High Brightness LCD Display M4 screw VESA mount ( 100*100mm ) ■ Hardware and M4*4 pcs for VESA mount are not provided UM-UV-621-H17-Q414V4 www.austin-hughes.com...
- Page 10 < Part 2 > < 2.1 > Package Content - HOP-17 HOP-17 17” High Brightness LCD display X 1 6ft VGA cable X 1 Power adapter X 1 Power cord X 1 Basic I/O Power DVI-D AV2.2D upgrade I/O Audio...
- Page 11 < 2.2 > Structure Diagram - HOP-17 17” High Brightness LCD Display Front view OP-17 Rear view Rear case LCD panel Audio speaker ( for HDMI, Audio or TV option ) Universal open frame mounting LCD membrane Extended remote sensor membrane cable...
- Page 12 < 2.2 > Dimension - HOP-17 Front View Side View HOP-17 UNIT : mm Rear View 1mm = 0.03937 inch Bottom View UM-UV-621-H17-Q414V4 www.austin-hughes.com...
- Page 13 < 2.3 > Installation - HOP-17 17” High Brightness LCD Display ( I ) Universal mount ( II ) VESA mount ( 100*100mm ) M4 screw Hardware and M4*4 pcs for VESA mounting are not provided UM-UV-621-H17-Q414V4 www.austin-hughes.com...
-
Page 14: Product Specifi Cations
< Part 3 > < 3.1 > Product Specifi cations Mechanical HAP-17 HOP-17 Design Front Panel Black, RAL 9005 Rear Casing Black, RAL 9005 Black, RAL 9005 VESA Mounting 100 x 100mm 100 x 100mm Other Mounting Panel mount Universal mount... - Page 15 17” High Brightness LCD Display Physical HAP-17 HOP-17 Specifi cation Product ( W x D x H ) 439 x 64.2 x 356.6 mm 436 x 58.2 x 353.6 mm 17.3 x 2.5 x 14 inch 17.2 x 2.3 x 13.9 inch...
-
Page 16: On-Screen Display Operation ( Osd )
< 3.2 > On-screen Display Operation ( OSD ) Power light Green = On Orange = Power saving Membrane Switch Function Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control (To auto adjustment by pressing the button for 5 seconds) Exit the OSD screen Toggle analog, digital &... -
Page 17: Part 4 > Options
< Part 4 > Options 17” High Brightness LCD Display < 4.1 > Option Table Options HDMI * or DVI-D S-Video * + Composite ( BNC ) Audio Touchscreen MCS multi-display control *** DC Power MIL-type / lockable connector Quad display TV ( Analog ) * Auto / switch dimming About HDMI and DVI-D... - Page 18 < 4.2 > Options : MCS ( Multi-display Control ) More control is always good. Especially when it is necessary and easy. Austin Hughes provides MCS solution to control the OSD of various UltraView LCD display up to 64 units. The RS-232C is used for the communication between the PC and the fi...
-
Page 19: Av2.2D Upgrade : Dvi-D, S-Video + Bnc & Audio
< 4.3 > Options : 17” High Brightness LCD Display AV2.2D Upgrade Options ( DVI-D TMDS single link ) - DVI-D ( S-Video + Composite, BNC ) - AV ( 3.5mm audio jacks for audio in & out, and 2W + 2W speakers ) - Audio Audio Power... - Page 20 How to Use RC-1 Remote Controller Switches on or off the TV POWER Turn on or off the speaker MUTE Switch to signal input mode INPUT Select channels. For channel numbers 10 and above, enter the second digit within two seconds. 0- 9 Increase or decrease the speaker volume V + / -...
-
Page 21: Projected Capacitive ( 4-Point Touch )
17” High Brightness LCD Display < 4.4 > Options : Touchscreen & driver H17" USB Touchscreen Specifi cation e-Resistive Multi-touch e-Capacitive Model TPC-17 Projected Capacitive 5-Wire Resistive Capacitive Technology Single Single Touch Point Finger or Capacitive Stylus Finger or Stylus Finger Input Type 2048 x 2048... - Page 22 < 4.4 > Options : Touchscreen & driver TPC-17 Driver Connect the USB cable from the USB port on the LCD to a computer. The touch screen supports easy Plug-and-Play operations. There is no need to install additional drivers on the computer. TRB / TCB Driver Please follow the below steps to setup the touch screen:- Step 1.
- Page 23 < 4.6 > Options : MIL-type or Lockable Connector 17” High Brightness LCD Display Input Part no. MIL Standard MS3470W8-33P MIL - DTL - 26482 MIL - type DC Power Connector ( Male ) MS3470W14-15P MIL - DTL - 26482 ( Male ) There are several additional MIL DC and VGA connector types with varying design characteristics to meet cost considerations and to provide users with the most...
- Page 24 < 4.7 > Options : Quad Display QD Specifi cation Item Description Model Number QD (NTSC) QD (PAL) Number of Color 16.7 M 16.7 M Imaging System NTSC Resolution 1024 x 525 1024 x 625 Refresh Rate 1.0 Vpp, 75 Ohm x 4 Camera Input Video Input 1.0 Vpp, 75 Ohm x 1...
-
Page 25: Tv ( Analog )
< 4.8 > Options : TV ( Analog ) 17” High Brightness LCD Display Audio Power S-Video HDMI out - in - in Video PC For TV option : ( 1 ) The AD board comes standard with HDMI, VGA, S-Video, BNC, audio inputs and RC-2 remote controller. - Page 26 How to Use RC-2 Remote Controller INPUT MUTE -/-- FREEZE AUTO MENU SELECT ASPECT SLEEP ENTER BACK EXIT SWAP SOURCE POSITION AUDIO Select the source INPUT Switches on or off the TV Only use in TV mode. Select channels. For channel numbers 10 0 - 9 and above, enter the second digit within two seconds.
- Page 27 < 4.9 > Options : Auto Dimming 17” High Brightness LCD Display DA-01 Light sensor on OP model DA-01 Light sensor on AP model ( 66cm from AD board to sensor end ) DA-01 light sensor will be installed on the display front panel when auto dimming is ON in OSD menu.
- Page 28 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. Copyright 2014 Austin Hughes Electronics Ltd. All rights reserved. UM-UV-621-H17-Q414V4 www.austin-hughes.com...
