LION 60000LP Instruction Manual

Hide thumbs

Table of Contents

Quick Links

MODEL NO: 60000LP

4 Burner Stainless Steel, Lights, Built-In, L.P. (Propane) Gas

MODEL NO: 60000NG

4 Burner Stainless Steel, Lights, Built-In, Natural

MODEL NO: 75000LP

4 Burner Stainless Steel, Rotisserie, Lights, Built-In, L.P. (Propane) Gas

MODEL NO: 75000NG

4 Burner Stainless Steel, Rotisserie, Lights, Built-In, Natural Gas

MODEL NO: 90000LP

5 Burner Stainless Steel, Rotisserie, Lights, Built-In, L.P. (Propane) Gas

MODEL NO: 90000NG

5 Burner Stainless Steel, Rotisserie, Lights, Built-In, Natural Gas

SAFETY INSTRUCTIONS ..............................................................................................................

INSTALLATION INSTRUCTIONS .....................................................................................................

LIGHTING & OPERATING INSTRUCTIONS ........................................................................................

CLEANING & MAINTENANCE ..........................................................................................................

TROUBLESHOOTING .................................................................................................................... 20

PARTS LIST .................................................................................................................................

WARRANTY...................................................................................................................................

READ THE FOLLOWING INSTRUCTIONS CAREFULLY AND BE SURE YOUR GRILL IS PROPERLY INSTALLED, ASSEMBLED AND

CARED FOR. FAILURE TO FOLLOW THESE INSTRUCTIONS MAY RESULT IN SERIOUS BODILY INJURY AND/OR PROPERTY

DAMAGE. IF YOU HAVE QUESTIONS CONCERNING ASSEMBLY OR OPERATION, CONSULT YOUR DEALER, GAS APPLIANCE

SERVICE REPRESENTATIVE OR YOUR GAS COMPANY

NOTE TO INSTALLER:

LEAVE THESE INSTRUCTIONS WITH THE CONSUMER AFTER INSTALLATION.

NOTE TO THE CONSUMER

RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.

THIS OUTDOOR COOKING GAS APPLIANCE IS NOT INTENDED TO BE INSTALLED IN OR ON RECREATIONAL VEHICLES

AND/OR BOATS.

Ontario, California 91761

Instructions Manual

Gas

PAGE

Certificate 252521-2405769

Project 2405769

Figure No.(75)

Table of Contents

Need help?

Do you have a question about the 60000LP and is the answer not in the manual?

Questions and answers

Summary of Contents for LION 60000LP

Page 1: Table Of Contents
Ontario, California 91761 Instructions Manual MODEL NO: 60000LP 4 Burner Stainless Steel, Lights, Built-In, L.P. (Propane) Gas MODEL NO: 60000NG 4 Burner Stainless Steel, Lights, Built-In, Natural MODEL NO: 75000LP 4 Burner Stainless Steel, Rotisserie, Lights, Built-In, L.P. (Propane) Gas...
Page 2: Safety Instructions
SAFETY INSTRUCTIONS Read carefully before assembling and operating your gas grill This gas grill must be installed in accordance with local codes or, if in an area without local codes, with the latest edition of the National Fuel Gas Code ANSI Z223.1/NFPA54, Natural Gas and Propane Installation Code, CSA B149.1 or Propane Storage and Handling Code, B149.2. WARNING: Fuels used in gas or oil-fired appliances and the products of combustion of such fuels, contain chemicals known to the State of California to cause cancer, birth defects and/or reproductive harm.
Page 3 If an external electrical source is utilized, a statement that the outdoor cooking gas appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22 1 This outdoor cooking gas appliance shall be used only outdoors and shall not be used in a building, garage or any other enclosed area A serial number and model number located on this appliance should be provided for services.
Page 4 Use Power Supply; 120V AC, 60 Hz, 0.5 A. Do not use this appliance under overhead combustible surfaces. For a built-in appliance, Only for installation in a built-in enclosure constructed of non-combustible materials If this appliance provided with a flexible service cord for connection to a line-voltage electrical supply shall bear a Class VI marking attached to the plug end of the cord which includes the following information: Warning Electrical Grounding Instructions...
Page 5: Natural Gas Safety
NATURAL GAS SAFETY Your Natural Gas grill is designed to operate on natural gas ONLY, at a pressure of 4” water column (W.C.) regulated at the natural gas regulator attached at the back of the grill. Check with your gas utility for local gas pressure and with your local municipality for building code requirements.
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS PLEASE READ THESE INSTRUCTIONS BEFORE INSTALLING YOUR GAS GRILL Your Gas BBQ Grill comes to you fully assembled. We strongly recommend professional installation and hookup of the Gas BBQ grill. These instructions will provide you with the measurements necessary for you or your builder to construct a masonry structure to house your outdoor gas grill.
Page 7: Natural Gas Connections
NATURAL GAS CONNECTIONS Pipe sealing compound or pipe thread tape of the type resistant to the action of natural gas must be used on all male pipe thread. Apply compound or tape to at least the first three threads when making the connection. Remove plastic cap from regulator installed on grill.
Page 8: Cutout Dimensions
Cutout Dimensions Upper and lower vents (20 sq in. minimum must be provided) for combustion air on both sides of built-in cabinet. When choosing a location for your gas grill keep in mind that it should never be located under any overhead combustible construction.
Page 9 INSPECTING I CLEANING BURNERS AND GAS VALVE ORIFICES By following these cleaning procedures on a timely basis, your grill will be kept clean and working properly with minimum effort. BURNER CLEANING 1. Remove burner from the grill bowl. Bend a stiff wire (a light-weight coat hanger works well) into a small hook. Run the hook through each burner tube and burner several times.
Page 10 CAUTION – Always turn off the gas supply prior to clearing your grill. 1. Replace burner and put cotter pin back to hole of the cast peg beneath the burner. 2. Check the burner for proper location after replacing. To assure the valve orifices are inside of the burner tubes. See below drawing. If the valve orifices do not fit inside the burner tubes, lighting the burners may cause explosion and/or fire.
Page 11 BURNER OPERATION CHECK 1. With BBQ Grill control knobs in “OFF” position turn on the Gas supply. 2. Light any burner by pushing its control knob in fully and slowly (3 to 4 seconds) turning it about 1/4 turn to the left (counter- clockwise) until a click is heard.
Page 12 COOKING COMPONENT INSTALLATION IMPORTANT: Before first use wash flame tamers, cooking grids, and warming rack with warm, soapy water. Rinse and dry thoroughly. Season metal surfaces with cooking oil occasionally. (After cooking is completed, turn grill to high setting for NO MORE THAN five minutes to burn off excess grease or food residue) CAUTION: DO NOT LEAVE GRILL UNATTENDED.
Page 13: Lighting & Operating Instructions
LIGHTING & OPERATING INSTRUCTIONS LIGHTING PROCEDURES Lighting Main Burner(s): 1. Become familiar with safety guidelines at front of manual. DO NOT SMOKE WHILE LIGHTING GRILL OR CHECKING GAS SUPPLY CONNECTIONSI 2. If your grill fuel source is a LP gas cylinder, check to see that cylinder is filled. 3.
Page 14 LIGHTING & OPERATING INSTRUCTIONS OPERATING PROCEDURE Burn-off: Before cooking on your gas grill for the first time, burn the grill to get rid it of any odors or foreign matter by igniting the burners, closing the lid, and operating at “HI” setting for about five minutes. You may then either set the controls to “OFF” or cook on your grill immediately by turning the control knobs to a lower setting.
Page 15 LIGHTING & OPERATING INSTRUCTIONS ROTISSERIE COOKING Rotisserie is mostly used to cook large pieces of meat and poultry to assure slow, even cooking. The constant turning provide s a self- basting action, making food cooked on a rotisserie exceptionally moist and juicy. Rotisserie cooking generally requires 1 ½ to 4½ hrs to cook depending on the size and type of meat being cooked.
Page 16 Since indirect heat is often used in cooking on a rotisserie, a foil or aluminum drip pan is advisable to prevent excessive flare-ups. Generally, the cooking grills are removed to allow for the swing of the rotisserie. A basting pan is placed under the rotisserie area on top of the flame tamer(s) to catch the drippings.
Page 17 LIGHT BULB REPLACEMENT If light bulb(s) need to be replaced, make sure power is disconnected and grill and light bulbs are completely cool to the touch. 1. Remove screw with a small Phillips screwdriver. Caution: Glass cover may be loose, ensure the cover is properly supported before completely GLASS COVER removing the screw.
Page 18: Wiring Diagram
5. Replace glass cover and re-snap metal clip into light housing. Replace screw and tighten. To replace the other bulb, follow the same procedure. 6. Plug in DC power Place wire clamp and wire in position then fix it with screw and nut RIGHT LIGHT HOUSING LEFT LIGHT HOUSING WIRING DIAGRAM...
Page 19: Cleaning & Maintenance
CLEANING & MAINTENANCE CLEANING THE COOKING GRIDS After cooking, turn control knobs to “OFF” and let grill cool before attempting to clean your cooking grids. Before first use and periodically it is suggested that you wash the cooking grids in a mild soap and warm water solution. You can use a washcloth or a vegetable brush to clean your cooking grids.
Page 20: Troubleshooting
TROUBLESHOOTING If grill fails to operate properly 1. Turn off gas at source, turn control knobs to “OFF”, and wait five minutes before trying again 2. Check gas supply/connections. 3. Repeat lighting procedure and, if grill still fails to operate properly, TURN “OFF”...
Page 21: Parts List
While the gas grill is still hot, you must wait for a minimum of five minutes before commencing to re-ignite (this allows accumulated gas fumes to clear). If all checks/corrections have been made and gas grill still fails to operate properly, consult your grill dealer or gas appliance service person.
Page 22 MODEL NO: 75000LP 4 Burner Stainless Steel, Rotisserie, Lights, Built-In, L.P. (Propane) Gas MODEL NO: 75000NG 4 Burner Stainless Steel, Rotisserie, Lights, Built-In, Natural Gas Certificate 252521-2405769 Project 2405769 Figure No.(75)
Page 23 LP REGULATOR STAINLESS FLEX TUBE INFRARED BURNER VALVE ASSEMBLY MANIFOLD GAS VALVE ASSEBMLY GREASE TRAY CONTROL PANEL ASSEMBLY KNOB BEZEL KNOB LOGO LION LOGO LIGHT SWITCH GRIDDLE PLATE SMOKER BOX SMOKER LID CONNECTOR TRANSFORMER MOTOR BRACKET ROTISSERIE MOTOR FORK ROTISSERIE...
Page 24 MOOEL NO:90000LP 5 Burner Stainless Steel, Rotisserie, Lights, Built-In, L.P. (Propane) Gas MOOEL NO:90000NG 5 Burner Stainless Steel, Rotisserie, Lights, Built-In, Natural Gas Certificate 252521-2405769 Project 2405769 Figure No.(75)
Page 25 STAINLESS FLEX TUBE INFRARED BURNER VALVE ASS E 1 MANIFOLD GAS VALVE ASSEBMLY GREASE TRAY CONTROL PANEL ASSEMBLY KNOB BEZEL KNOB LOGO LION LOGO LIGHT SWITCH GRIDDLE PLATE SMOKER BOX SMOKER LID CONNECTOR TRANSFORMER MOTOR BRACKET ROTISSERIE MOTOR FORK ROTISSERIE...
Page 26 MODEL NO: 60000LP 4 Burner Stainless Steel, Lights, Built-In, L.P. (Propane) Gas MODEL NO: 60000NG 4 Burner Stainless Steel, Lights, Built-In , Natural Gas Certificate 252521-2405769 Project 2405769 Figure No.(75)
Page 27 PARTS LIST MODEL NO: 60000LP 4 Burner Stainless Steel, Lights, Built-In, L.P. (Propane) Gas MODEL NO: 60000NG 4 Burner Stainless Steel, Lights, Built-In, Natural Gas REF# Parts# DESCRIPTION Quantity LID FRONT THERMOSAT BEZEL THERMOSAT LID HANDLE HANDLE END CAP LID REAR...
Page 28 This warranty gives you specific legal rights, and you may have other rights, which vary from state to state. Lion Exterior Products Inc. shall not be liable for loss of use of the barbecue grills, related hardware or other incidental or consequential costs, expense or damages, which may include, but are not limited to, removal of permanent deck or other custom fixtures or the necessity for crane removal.
