- Page 1 ETC-RW900D SOLDERING STATION SMD REWOEK 2 in 1 THERMO-CONTROL ANTI-STATIC Intelligent lead-free rework station User's Manual CBN 019006...
-
Page 2: Safety And Caution
ETC-RW900D is an intelligent lead-free rework station, which combines rework station Characteristics: and soldering station. It is especially suitable for R&D, production, lab of scientific 1. MCU computer offers PID advanced algorithms industrial control with thermo- research and so on. It is easy to operate, user-friendly and greatly space-saving. -
Page 3: Function Diagram
Technical Specifications: Button instructions: Model ETC-RW900D Intelligent lead-free rework station Total power About 900W (max) Heating:800W(max), pump (diaphragm):40W Soldering Station:50W Range for temperature Hot Air Rework Station 100-500 controlling Soldering Station 200-480 Temperature unit Convertible Temperature Static ±2 controlling stability... -
Page 4: Installation
Installation: Power: The brackets for the handles must be installed when operating for the first time. Upon power on the unit, the reworking station and soldering station be standby. Please see the following illustration: 1. Please fix the bracket by tightening the four screws according to the illustration Standby state of screen A Standby state of screen B and your personal habit. - Page 5 Under the setting condition. Then you can press "SET" button to set hot -air rework station' s temperature and the main temperature area shines the setting temperature, you can press UP knob or DOWN knob to adjust the setting temperature. 4s-no-press or press SET knob, you can keep the temperature and quit out this setting.
-
Page 6: Soldering Station
10. Error/Fault indication 1. When "H-E" is displayed on the screen A, there is no hot air in the nozzle (diagram13), which indicates that the heating element fails. 2. When "S-E" is displayed on the screen A, there is a fault in sensor (diagram 11) (diagram14), which signifies that there is something wrong with the 7. - Page 7 5.Standby In normal working condition, press POWER key at the right of panel to make the device be standby (diagram 2). Make the power off, at the same time, the soldering station is off and the whole station will off when the temperature is low to 100 .
-
Page 8: List Of Accessories
