USER MANUAL
High Resolution IR Camera
Please read the instructions thoroughly before using the product.
alarm shop
USER MANUAL
High Resolution IR Camera
Please read the instructions thoroughly before using the product.
396Z
467a_V0.9
396Z
467a_V0.9

Advertisement

loading
Need help?

Need help?

Do you have a question about the AVC467A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Avtech AVC467A

  • Page 1 396Z USER MANUAL High Resolution IR Camera Please read the instructions thoroughly before using the product. 467a_V0.9 alarm shop 396Z USER MANUAL High Resolution IR Camera Please read the instructions thoroughly before using the product. 467a_V0.9...
  • Page 2 alarm shop...
  • Page 3 IMPORTANT SAFEGUARD All lead-free products offered by the company comply with the requirements of the European law on the Restriction of Hazardous Substances (RoHS) directive, which means our manufacture processes and products are strictly “lead-free” and without the hazardous substances cited in the directive. The crossed-out wheeled bin mark symbolizes that within the European Union the product must be collected separately at the product end-of-life.
  • Page 4 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device mat not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.
  • Page 5: Table Of Contents

    TABLE OF CONTENT FEATURES ......................1 PACKAGE CONTENT .................... 1 SPECIFICATIONS*....................2 CONNECTION......................4 INSTALLATION ....................... 4 CAMERA CONFIGURATION.................. 6 alarm shop TABLE OF CONTENT FEATURES ......................1 PACKAGE CONTENT .................... 1 SPECIFICATIONS*....................2 CONNECTION......................4 INSTALLATION ....................... 4 CAMERA CONFIGURATION.................. 6...
  • Page 6 alarm shop...
  • Page 7: Features

    FEATURES 1. 1/3" color CCD sensor with SONY Effio DSP 2. High resolution 3. Low light sensitivity of 0.05 Lux, 0 Lux (IR ON) 4. External alarm-in device connection 5. Customized OSD menu for camera configuration 6. IP67, suitable for outdoor use 7.
  • Page 8: Alarm Shop

    SPECIFICATIONS* Pick up Element 1/3" Color CCD image sensor with SONY Effio DSP Number of Pixel 768(H)x494(V) <NTSC> / 752(H)x582(V) <PAL> Resolution Super High Resolution Min. Illumination 0.05 Lux / F1.4; 0 Lux (IR ON) S/N Ratio More than 48dB (AGC off) Electronic Shutter 1/60 (1/50) to 1/100,000 sec Lens...
  • Page 9 External Alarm Device Connection Alarm in Video Output 1.0 Vp-p composite, 75Ω Startup Temperature 0˚C~40˚C Operating Temperature -20˚C~40˚C Power Source (±10%) DC12V Current Consumption (±10%) 75mA (IR OFF), 400mA (IR ON) Dimensions (mm)** 142(H) x 75(Φ) * The specifications are subject to change without notice. ** Dimensional Tolerance: ±...
  • Page 10: Connection

    CONNECTION 1. Connect the power connector of the camera to a DC 12V regulated power supply. NOTE: Please use a regulated DC12V power adaptor to operate this unit. The power tolerance of this unit is DC12V ± 10% (DC 10.8V ~ DC 13.2V). A power input of more than the DC 13.2V will damage this unit.
  • Page 11: Installation

    INSTALLATION 1. Use the supplied three screws to attach the bracket to wall. Drill a hole in advance on the proper position of the wall for the Power and Video Cable to pass through later. 2. Remove the Joint Lock from the bracket by turning it counterclockwise. Then, screw the Joint Lock to the backside of the camera (turn clockwise).
  • Page 12 Figure 1 Figure 2 Figure 3 alarm shop Figure 1 Figure 2 Figure 3...
  • Page 13: Camera Configuration

    CAMERA CONFIGURATION This camera has its own menu for parameter settings. To enter the menu, please connect this camera with a DCCS-enabled DVR, or used with our control box, AVK-T1, when it’s connected to a non-DCCS DVR. Enter camera menu Connect the supplied power adapter to the camera’s power jack on the rear panel and the power outlet.
  • Page 14 From DCCS menu Right-click to display the DVR main menu, and select “ADVANCED CONFIG“ “DCCS“. ADVANCED CONFIG CANERA C H 1 C H 2 C H 3 C H 4 DETECTION DIAGNOSTIC START ALERT MENU SETUP NETWORK DISPLAY RECORD DEVICES DCCS DEVICE OSD CAM...
  • Page 15 Camera menu SUB-MENU DESCRIPTION SHUTTER / AGC 1. Select “AUTO” to allow the camera to act automatically when the light condition of the environment changes. 2. Select “MANUAL” to fix the shutter and AGC modes of the camera no matter how the light condition of the environment changes.
  • Page 16 Camera menu tree SUB-MENU OPTIONS SHUTTER / AGC AUTO HIGH MODE AUTO IRIS / LUNINANCE SHUT+AUTO IRIS BRIGHTNESS 0 ~ 255 MODE AGC / OFF LUMINANCE BRIGHTNESS x0.25 / x0.50 / x0.75 / x1.00 MANUAL MODE SHUT + AGC SHUTTER 1/50;...
  • Page 17 SUB-MENU OPTIONS WHITE BAL PUSH USER1 B – GAIN / 0 ~ 255 USER2 R – GAIN BACKLIGHT OFF / BLC / HLC PICT ADJUST MIRROR OFF / ON BRIGHTNESS / 0 ~ 255 CONTRAST / SHARPNESS / HUE / GAIN LUMINANCE LOW / MID / HIGH CONTRAST...
  • Page 18 SUB-MENU OPTIONS DAY/NIGHT COLOR BURST ON / OFF AUTO BURST ON / OFF DELAY CNT 0 ~ 255 DAY-> NIGHT 0 ~ 255 NIGHT-> DAY 0 ~ 255 NR MODE Y/C; Y; C; OFF Y LEVEL C LEVEL CAMERA ID OFF / ON LANGUAGE ENGLISH / 日本語...
