- Page 1 AIR TO WATER HEAT PUMP Installation and Operation Manual H series Only Heating series & AC series Heating Cooling series & HC series Mutifunctional Heating Cooling Hot water...
-
Page 2: Table Of Contents
Content Safety Precautions ............. 1 ..............1 General ........... 1 Transport and storage Components ............2 Wired controller . -
Page 3: Safety Precautions
1 Safety Precautions Note! It is required to read the Safety precautions in detail before operation. The precautions listed below are all-important for safety, please obey without fail. 1 1 General Make sure that the fixed ground wire in the building is securely connected to earth. Wiring tasks should be carried out by qualified electricians only, in addition, they should check the safety conditions of power utilization, for example, check if the line capacity is adequate, and check if the power cable is damaged. -
Page 4: Components
2 Components Parts List NO. Description Quantity Description Quantity 1 Water pressure gauge Low pressure switch 2 Electrical three-way valve 3 Compressor R410A Needle valve 4 D.H.W outlet Gas-liquid separator 5 A.C water outlet Safety valve Water return 7 Drain AC contactor 8 Ball valve switch Transformer... -
Page 5: Wired Controller
3 Wired controller 3 1 Display and Button 1 2 3 4 5 6 Display 15.Defrost running 1.Cooling operation mode 16.Fan motor 2.Heating operation mode 17.DHW water pump C5 3.Day display 18.DHW heater 4.DHW operation mode 5.Antibacterial(legionella)function 6.A/C returned water temp Button or Outdoor ambient temp in only Heating series 7.Timer number... -
Page 6: 2 Operating The Unit
3 Wired controller 3 2 Operating the unit 3.2 1 OPERATION MODE SHIFT (OPERATING STEPS) A, in the On / Standby cases, press the M key, air conditioning cooling icon appears and flashes; press M -> key every time to shift from air-conditioning cooling domestic hot water mode air conditioning ->... - Page 7 3 Wired controller B, the clock icon appears, number of hours flashing, press or ▼ key to select number between 0 ~ 23, and then key to confirm. C, at this time the number of minutes flashing, press or ▼ key to select number between 0 ~ 59, and then press button to confirm and exit setting automatically after 15 seconds, or press C key to exit setting.
-
Page 8: 3 Week And Clock Setting
3 Wired controller 3 3 Week and Clock Setting Press and hold key for 3 seconds until the week digits on the screen start flashing. Press to select the , press to confirm, the number of hour appears flickers. press key to adjust hour, press to confirm, then the number of... -
Page 9: 4 Timer Setting
3 Wired controller 3 4 Timer setting Flicker Press and hlod Press to select “ ” for 5 seconds Press Press to active adjust the time digital clock Press to activation Press to confirm digital clock Press Press to confirm adjust the time Press Press... - Page 10 3 Wired controller Press Press to confirm adjust the time Press to activation Press digital clock adjust the time Press to confirm Press to activation digital clock Press to confirm Press adjust the time After monday's timer setting is finished, it will be automatically switched to Tuesday's timer setting .until sunday's timer setting is finished,then return to normal display interface.
-
Page 11: Error Code
4 Error Code Shortly press you can enter into the error code checking state Then press key again you can check each error code The error code meaning was given on the function book " " " " . Display Err Ex or Err Px For example Err E2 Err P5... -
Page 12: Installation
5 Installation 5 1 Installation information Users need to install DHW water tank with coil heat exchanger built inside if this heat pump is used for DHW together with air conditioning function. 2 Water pump can be build inside of outside according to requirement 3 Even with builtin water pump, user need to check to ensure the minimum water flow volume shown below, If necessary, install external water pumps for DHW circulation or for air conditioning circulation,... -
Page 13: 2 Installation Method
5 Installation 5 2 Installation method Method 1 DHW with Room Heating Method 2... - Page 14 Method 3 Method 4 8. Water pump ->C4 1. Heat Pump 9. Drain valve 2. Wired Controller 10. Ball valve 3. DHW water pump 12. Water pump ->C5 4. DHW temp sensor 13. Water pump ->C6 5. DHW water tank 14.
- Page 15 5 Installation 5 3 Installation with solar assistant Application 1 Application 2...
- Page 16 5 Installation 5 3 Installation with solar assistant Application 3 The most energy saving application G1 DHW and AC switching valve G2 Solar automatic selection valve...
-
Page 17: 3 Dimensions
5 Installation 5 3 Dimensions AH-14/15 AH-8/9 Model Model AH-8/9 AH-14/15 1090 1090 1018... -
Page 18: 4 Installation Position
5 Installation 5 4 Installation position Note! Installation must be carried out by professional personnel. 1 If the unit is to be installed on the floor, its undercarriage should be heightened, to avoid ingression of accumulated water in rainy season. In snowy areas, it is important to prevent accumulated snow from blocking up the air-out. The recommended height is 20cm to 30cm. -
Page 19: Electric Connection
6 Electric connection 6 1 General Note! Electrical installation and service must be carried out under the supervision of a qualified electrician. Electrical installation and wiring must be carried out in accordance with the stipulations in force. The heat pump must not be connected without the permission of the electricity supplier and must be connected under the supervision of a qualified electrician. -
Page 20: 3 Wiring Diagram
6 Electric connection 6 3 Wiring Diagram The parts with dotted circle are optional parts Single Phase according to actual installation requirement. Water pump C4: water pump for both DHW and A/C C4 water pump is not built inside for C5: water pump is addtional option for DHW standard model. -
Page 21: Test Run
7 Test Run 7 1 Preparation After finish the installation tasks, please check the items: 1 Check the dip switch setting and short wiring as shown below to be sure of correct electricty connection. The DIP switch can only be set at factory or by authorized engineer Any improper setting may cause unrecoverable damage or misfunction SW4 1... -
Page 22: Temperature Sensor Data
9 Temperature sensor data The temperature sensor data for water outlet sensor, water inlet sensor, coil pipe sensor, ambient sensor, DHW sensor, Etc. The sensor model is 3470RT R25=5K +-1% RT(K ) t2( ) RT(K ) t2( ) 105.780 -36.9 0 10 4.039 30.6... - Page 23 9 Temperature sensor data The temperature sensor data for compressor exhaust gas temperature sensor. The sensor model is 3950RT R 2 5 = 10 K , B 2 5 /5 0 = 3 9 5 0 A / D R T ( K t 2( A /D R T (K...
-
Page 24: Heat Pump Test Run
10 Heat Pump Test Run Check list before turn on heat pump Better to print this page out and make sure that you can tick all ot fhe following items to avoid any ’ Problem After finish the installation tasks please check the item listed below before turn on heat pump Things you should have done: 1 Power cable...
