- Page 1 OWNER’S MANUAL FOR 24V/36V ELECTRIC VEHICLES This manual contains important safety, performance and maintenance information. Read the manual before taking your first ride on your new ride-on vehicle, and keep the manual handy for future reference. REGISTER your bike online at www.dynacraftwheels.com...
- Page 2 DO NOT return this item to the store. STOP Questions or comments? Call Dynacraft at 1-800-288-1560 NOTE: Illustrations in this Manual are for reference purposes only and may not reflect the exact appearance of the actual product. Specifications are subject to change without notice.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1. Introduction, Safety and Warnings 2. Carton Contents 3. E-Skateboard Parts 4. Before You Ride 5. Getting Started 6. Regular Maintenance and Repair 7. Troubleshooting Guide 8. Warranty... -
Page 4: Introduction, Safety And Warnings
INTRODUCTION, SAFETY, AND WARNINGS ABOUT THIS MANUAL: This Manual was written to help you get the most performance, comfort, enjoyment and safety when riding your new electric skateboard. It is important for you to understand your new electric skateboard. By reading this manual before you or your child go out on your first ride, you will know how to get the most from your new electric skateboard. - Page 5 Always wear appropriate clothing and shoes, including long sleeved shirts and long pants and lace-up or similar shoes with rubber soles. Never ride barefoot or in sandals and make sure that shoelaces or other fasteners are tied and kept away from the wheels and drive system of the skateboard.
- Page 6 · Children must be supervised by an adult to be safe. · Always be alert and ride your skateboard defensively. Watch out for obstacles that could catch one of the skateboard’s wheels or force you to turn suddenly and/or lose control.
- Page 7 in contact with moving parts, wheels, while the motor is running. · Before each cycle of operation, the operator shall perform the preoperation checks specified in this manual and/or by the manufacturer, including: · That all guards and pads originally supplied by the manufacturer are in proper place and in serviceable condition;...
-
Page 8: Carton Contents
· Consider joining a club in your area and learning more about skateboarding safely; Prove you are a good skateboarder; be conscientious and take care of yourself and others. PRE-RIDE SAFETY CHECKLIST · Check to make sure that all components are properly secured and are functioning according to the manufacturer’s specifications. -
Page 9: E-Skateboard Parts
E-SKATEBOARD PARTS Part Description Part Description Maple Deck Belt Enclosing Cover Foam Pad Driven Wheel Group Battery Wheels Battery Retainers Cushion Battery Box Truck Fixer ON/OFF Switch Controller Motor Front Truck Rear Truck Remote Control Belt Casing 9V Battery (not included) Belt Battery Cover (For Remote Control) -
Page 10: Before You Ride
BEFORE YOU RIDE Battery Always make sure the power switch is in the “off” position whenever the skateboard is not in use. Never store the product in outdoor conditions, never store it in the rain, and never store the product in freezing or below freezing temperatures. These low temperatures will permanently damage the battery. - Page 11 Avoid uneven surfaces, potholes, surface cracks and obstacles. Always ride at a safe speed, maintaining full control over the board at all times. Know your limits and ride within them. Adult supervision is strongly recommended. This board does not conform to Federal Motor Vehicle Standards and is not intended for operation on public streets, roads or highways.
-
Page 12: Getting Started
Preparation 1. Inspect outer carton for damages; open carton and inspect for internal damage. Report any damage to your freight carrier or dealer. 2. Remove your new Electric Skateboard, remote control and charger. Plug charger into wall and the Electric Skateboard will begin the charging process. Lights on the charger will turn from red to green when a full charge is attained. - Page 13 NOTE: · Turn off power switch when not in use. · Batteries may become damaged and could no longer accept a charge if switch is left in the ON position when not in use. · Fully charge the battery before storage. NOTE: Failure to recharge the battery at least once a month may result in a battery that will no longer accept a charge.
-
Page 14: Battery Information
BATTERY INFORMATION Battery may leak fluids that can cause chemical burn injury or ruin your product. To avoid battery leakage: Install batteries correctly, observing the polarity (+/-) signs to avoid leakage. • Insert batteries as indicated inside the battery compartment. •... -
Page 15: Regular Maintenance And Repair
IMPORTANT: The Electric Skateboard wireless remote uses a unique, close proximity low-frequency radio signal that minimizes the possibility of signal interference. However, signal interference may occur with high power lines, cell phones or other signal emitting devices. Use caution and check your ride area for possible sources of signal interference before use. - Page 16 Drive Wheel The drive wheel will wear considerably more than the other 3 wheels. If you start noticing that your board is grinding, you need to replace the drive wheel. Contact Dynacraft to order replacement wheels and other parts. Drive Belt Parts like the drive belt, wheel and battery will wear out with normal use and must be changed if they stop working smoothly.
- Page 17 Illustration on how to replace Drive Wheel and Drive Belt: 1. Loosen the two bolts on belt casing 2. Use a 13mm socket wrench to loosen the axle locknut. 3. Move the drive wheel from the axle(and 4. After installing a new belt (or new wheel), replace it when needed), and remove the use a socket wrench to tighten the axle belt for replacing.
-
Page 18: Troubleshooting Guide
Replacing wheel bearings: When you find a wheel doesn’t rotate smoothly, is loose or makes clicking noises (and the wheel shows few signs of wear and tear), the wheel bearing may need to be replaced according to the following guidelines: 1. - Page 19 Troubleshooting Issu e Problem/C ause Solution • Skateboard controller is not Turn on. turned on. • The indicator light on the Recharge the skateboard. Skateboard does not start up. charger is red. Battery is not properly installed or is No beep heard when turning on •...
-
Page 20: Replacement Parts
Battery Care and Disposal Do not store the battery in temperatures above 75°F (23.5°C) or below 32°F (0°C). THIS PRODUCT CONTAINS SEALED LEAD ACID BATTERIES WHICH MUST BE RECYCLED IN ACCORDANCE WITH YOUR LOCAL AND STATE LAWS. PLEASE CAREFULLY READ AND UNDERSTAND THE FOLLOWING DISPOSAL INSTRUCTIONS: Disposal: This product contains sealed lead acid batteries which must be disposed or recycled in an environmentally safe manner. - Page 21 WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 22: Warranty
Parents that allow their children to ride taking such actions will assume their own risk and the risk of injury to their children, and Dynacraft will not be responsible. THE PURCHASE OF THIS ELECTRIC SKATEBOARD WILL CONFIRM THE BUYER’S AGREEMENT THAT DYNACRAFT’S LIABILITY UNDER THIS WARRANTY SHALL BE NO... - Page 23 Dynacraft Customer Service 1-800-288-1560 7AM to 4PM Pacific Standard Time DO NOT return this item to the store. STOP Please call Dynacraft for assistance. Please have the following information available when you call: Model Number: (sample: 8802-33) Production Date: (sample: 03.03.2015)
- Page 24 Please visit dynacraftwheels.com for more information. Or call Customer Service at 1-800-288-1560, 7AM to 4PM PST. Please have the following information available when you call: Model Number: (example: 8XXX-XX) Production Date: (example: 2014.XX.XX) Serial Number: (example: XXXXXXXXXXX) 2015 Printed in China...
