ASTRO MIXAMP PRO Instruction Manual page 7

System Configuration
1
Back of MixAmp TM Transmitter USB Port on PC
Plug Micro-USB Cable into MixAmp Pro
TM
and PC for power.
5
CONTROL PANEL
To enable Voice Chat; go to "Control Panel,"
select "Sound," then "Recording." Select
"ASTRO MixAmp™ Pro," then "Set as Default
Device."
// PC
2
Back of MixAmp TM Transmitter
Optical Port on PC
Plug the optical cable into the MixAmp™
Transmitter and PC for Dolby® Digital 7.1
Surround Sound (Be sure to remove the
caps on the cable tip
6
MIN MAX
The MixAmp™ Pro and PC are set up and ready
to go. Game on!
3
MixAmp Pro Power Button
TM
*STAND BY *POWER ON
Power on the PC, then the MixAmp™ Pro. The
PC will automatically detect it.
4
CONTROL PANEL
To enable Game Audio on a PC using Windows 7;
go to "Control Panel," select "Sound," then
"Playback." Select "SPDIF Out" as the digital
output, then "Set as Default Device."k.'
