System Configuration

1
Front of PS4 Back of MixAmp
Plug Micro-USB Cable into MixAmp
and PS4 for power.
5
PS4 SOUND SETTINGS
Go to settings and select "Sound and
Screen," then select "Primary Output
Port" and choose "Digital Out (Optical)."
2
Back of MixAmp TM Pro
Pro
TM
Plug the mini-optical cable into the
MixAmp™ Pro and back optical port of
Pro
TM
the PS4 for Dolby® Digital 7.1 Surround
Sound (Be sure to remove the caps on
the cables).
6
6
PS4 SOUND SETTINGS
Go back to 'Audio Output Settings' and
select 'Audio Format (priority)', then
select 'Bit Stream (Dolby)'.
// PS4
3
MixAmp TM Pro Power Button
Back of PS4
*STAND BY
Power on your PS4 first, then your
MixAmp Pro. Your PS4 will automatically
TM
detect it, sign into your profile when
prompted.
7
PS4 SOUND SETTINGS
Under the "Audio Output Settings" menu
select "Output to Headphones" and
make sure "Chat Audio" is selected and
not "All Audio."
4
*POWER ON
Sign into a user profile when prompted.
8
MIN
That's it! Your MixAmp
up and ready to game.
ASTRO AUDIO
SUPERIOR
TOURNAMENT
COMPETITIVE
SIGN IN
MAX
Pro and PS4 are set
