- Page 1 BENUTZERHANDBUCH OWNER’S MANUAL VERS1.2 CAR AUDIO SYSTEMS SE7000 D CLASS D MONO CAR AUDIO AMPLIFIER...
-
Page 2: Table Of Contents
TABLE OF CONTENT SAFETY INSTRUCTIONS INSTALLATION INSTRUCTIONS SE7000D Features and operational controls Interconnection example Low Pass-Mode (standard subwoofer operation) Interconnection example Master/Slave-Mode FILTER SETTING RANGE SPECIFICATIONS TROUBLE SHOOTING OPTIONAL ACCESSORIES This symbol adverts you a important reference note on the following pages. Follow these reference notes by any means, otherwise damage of the device or the vehicle may be caused. -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS PLEASE ATTEND THE FOLLOWING ADVICES BEFORE THE FIRST OPERATION! DO NOT INSTALL THE DEVICE AT LOCATIONS, WHERE IT THE PURCHASED DEVICE IS ONLY SUITABLE FOR AN OPER- WILL BE EXPOSED TO HIGH HUMIDITY AND DUST. Install ATION WITH A 12V ON-BOARD ELECTRICAL SYSTEM OF A the device at a location, where it will be protected from high VEHICLE. -
Page 4: Installation Instructions
Do not mount the amplifier on top of a subwooferbox or any other vibrating parts, thereby parts in the inside of the amplifier may get loosen. The wires and cables of power supply and the audio signal must be as short as possible, to avoid any losses and interferences. Pen or ESX Amplifier ESX Amplifier peening... - Page 5 (+12V) power supply wire. REFERENCE NOTE The ESX SE7000D model has due to construction-conditioned reasons NO internal fuse-protection. This amplifier must be fused by any means with an external In-Line-Fuse with a value of 300 A. Due to the very high power currents, only high grade quality wires and ANL fuses should be used.
-
Page 6: Se7000D
SE7000D FUNCTIONS AND OPERATIONAL CONTROLS 10 11 The LINE INPUT RCA jacks must be connected with the RCA output jacks of the headunit. The optional BALANCED INPUT is unlike the regular RCA-cables insusceptible against interspersion and interferences of the vehicle’s electronics. You need therefor a Balanced-Line-Transmitter with a special cable, which can be connected between the head unit and the amplifier. -
Page 7: Interconnection Example Low Pass-Mode (Standard Subwoofer Operation)
SE7000D INTERCONNECTION EXAMPLE Low Pass-Mode (Standard Subwoofer Operation) NOTE! Switch setting = MASTER Connect stereo RCA output A additional subwoofer can be (R/L or SUB OUT) connected to the non-occupied of the headunit with speaker outputs. In this case LINE INPUT R/L of the amplifier ensure a impedance of 2 - 8 ohms per subwoofer. -
Page 8: Interconnection Example Master/Slave-Mode
SE7000D INTERCONNECTION EXAMPLE Master/Slave Mode Connect the bass remote 1. Connect Stereo RCA output (L/R controller and the remote terminal or SUB OUT) of the headunit with the at the amplifier (MASTER) LINE INPUT CH1/2 of the MASTER amp with the enclosed cable. - Page 9 SE7000D INTERCONNECTION EXAMPLE 1 Subwoofer with a Single-Voicecoil SLAVE MASTER MASTER/SLAVE Link like described on page 21. The Impedance may not Subwoofer be lower than 2 ohms. 2 – 8 Ohms INTERCONNECTION EXAMPLE 1 Subwoofer with a Dual-Voicecoil MASTER MASTER/SLAVE Link SLAVE like described on page 21.
-
Page 10: Filter Setting Range
FILTER SETTING RANGE LEVEL 0,7 V 0,25 V 0,2 V SUB SONIC 35 Hz 21 Hz 48 Hz 15 Hz 55 Hz LOW PASS 140 Hz 40 Hz 220 Hz 35 Hz 250 Hz EXTENDED BASS CONTROL SUB BOOST 9 dB 3 dB 15 dB 0 dB... -
Page 11: Specifications
Technical specifications are subject to change! Errors are reserved! For damages on the vehicle and the device, caused by handling errors of the device, we can’t assume liability. All ESX Amplifiers are tagged with a individual serialnumber, which will be registerd for statistic and service conditional purposes. -
Page 12: Trouble Shooting
TROUBLE SHOOTING Malfunction: no function Reason: Remedy: 1. The power supply connection of the device is not correct. Recheck 2. The cabels have no mechanical or electrical contact. Recheck 3. The remote turn-on connection from the headunit to the amplifier is not correct. Recheck 4. - Page 13 TROUBLE SHOOTING REFERENCE NOTE PROTECTION CIRCUIT This amplifier owns a protection circuit. If overloading, overheating and shorted loudspeakers, or too low impedance or insufficient power supply is insisted, the amplifier shuts down to prevent serious damage. If one of this disfunctions is detected, the red PROTECT LED lights up.
-
Page 14: Optional Accessories
BALANCED LINE TECHNOLOGY BALANCED INPUT With the optional BALANCED INPUTS, ESX offers an absolutely state-of-the-art-technology. Balanced inputs have been used for many years in professional sound studios and high end home stereo systems. Unlike the regular unbalanced RCA's connections, balanced wires are insusceptible against interferences of the vehicle's electronics.
