SERVICE MANUAL

Model No.
Service No. HL19K2a
Chassis
WARNING
©2010 Qingdao Haier Electronics Co., Ltd.
All rights reserved. Unauthorized copying and distribution is a violation of law.
Haier Group
LCD TV
HL19K2
MTK5305
