Contents
Product contents ..................................................................................................... 3
Controls Diagram .................................................................................................... 4
Controls ................................................................................................................... 5
Downlink Overview (Camera, TX, Power) ............................................................... 5
Transmitter .......................................................................................................... 6
Camera ................................................................................................................ 6
Power (via discharge filter supply) ....................................................................... 6
AV in/out Port .......................................................................................................... 6
Recording Video .................................................................................................. 6
Using an external receiver: .................................................................................. 7
Battery Charging ..................................................................................................... 7
Accessories ............................................................................................................. 8
Diopter lens ......................................................................................................... 8
SpiroNET Circular Polarized Antenna ................................................................. 8
Tiny Telemetry from ImmersionRC ...................................................................... 8
Specifications .......................................................................................................... 9
Headset Specifications ........................................................................................ 9
Camera Specifications: ...................................................................................... 10
Transmitter Specifications (250mW 5G8 V3): ................................................... 10
Downlink Kit ....................................................................................................... 10
Operational advice ................................................................................................ 11
Trouble shooting .................................................................................................... 12
Warranty ................................................................................................................ 12
Introduction
Congratulations on purchasing the Fat Shark Predator RTF FPV video piloting
system with goggles, transmitter and camera.
enjoyment, please take the time to thoroughly read through this operating manual
before using.
Product Compatibility
The Predator has been designed to adhere to established video standards and is
compatible with any product also adhering to accepted video standards.
the high number of different manufacturers and variation in quality, it's impossible
to for us to have tested with every product combination and some troubleshooting
may be required if mix/matching components. The Predator has been thoroughly
tested with ImmersionRC gear. For best results and no compatibility issues, Fat
Shark recommends ImmersionRC gear for your accessory products.
IMPORTANT!!!! Product Warning!!!!!
DO NOT LEAVE HEADSET EXPOSED TO DIRECT SUNLIGHT.
SUNLIGHT WILL MAGNIFY THROUGH THE OPTICS AND BURN
HOLES IN THE LCD COLOR FILTER
THIS WILL NOT BE COVERED BY WARRANTY. KEEP GOGGLES
IN PROTECTIVE CASE WHEN NOT IN USE
