Please read carefully before proceeding with installation. Your failure to follow any attached instructions or operating parameters may lead to the product’s failure and possible damage to property. MODEL UC-2 System Tested and certified by NSF International against ANSI/NSF Standard 53 for the reduction of claims specified on the performance data sheet.
Page 2
Table of Contents Maintenance Record..................... Operational Parameters ....................Contents of UC-1 System .................... Tools Recommended For Installation ................. Faucet Installation ......................Installation ........................Filter Change & Parts Layout..................Parts Listing ........................Preformance Data Sheet .................... Warranty ........................Maintence Record Date of Purchase:__________ Date of Install:_________ Installed by:____________ DATE FILTER DATE...
1 UC-1 Unit 2 Filters 1 Parts Bag 1 Manual and Warranty Card If any of the items are missing, please contact Watts Premier prior to installing. Tools Recommended For Installation √ A small knife √ Variable Speed drill √ 1/8” (3mm), 1/4” (6.4 mm) and 7/16” (11.0mm) Drill bits √...
Page 4
Special Note: Porcelain sink surface material is extremely hard and can crack or chip quite easily. Use extreme caution if drilling . Watts Premier accepts no responsibility for consequential damage resulting from the installation of faucet to the sink or counter top.
(When attaching the adapta valve to straight pipe threads, use Teflon tape on the treads.) The green tube Brass compression nut from inlet side of UC-2 module will nee to be cut to length and attached later in the installation. Figure C Configuration for 3/8”...
104015 and 101015). Other filters may look the same, but Figure D only filters by Watts is manfactured to fit your UC-2 filter unit in order to ensure proper reduction of water contaminants. A. Turn off incoming feed water supply to unit. Note: There will be water in the unit filter housing.
Page 7
Two Stage Under Counter Filtration Model Number UC-2 Part Number 500310 Exploded Drawing Sink or counter Item Part # Description Item Part # Description 134007 Adapt-A-Valve 131017 Insert Brass 1/4" Lock Washer 131012 Sleeve Delrin 1/4" Black Locating Washer 131002 Nut Brass 1/4"...
Page 8
Phoenix, Arizona 85027 – USA Performance Data Sheet for specific claims to NSF Std-53. CT-1, UC-1, UC-2 & Ultra-UV-R GENERAL USE CONDITIONS: 1: System to be used with municipal or well water sources treated and tested on regular basis to insure bacteriological safe quality.
What your Warranty Covers: If any part of your WATTS PREMIER UC-2 is defective in workmanship (excluding replaceable filters ), return unit after obtaining a return authorization (see below), within 3 year of original retail purchase, WATTS PREMIER will repair or, at WATTS PREMIER’S option, replace the system at no charge.
