4 - 1 / 2 I N . A N G L E G R I N D E R
OWNER'S MANUAL
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other
basic safety precautions may result in serious personal injury.
Item# 46693

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 46693 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ironton 46693

  • Page 1 4 - 1 / 2 I N . A N G L E G R I N D E R OWNER’S MANUAL WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item# 46693...
  • Page 2: Intended Use

    Thank you very much for choosing an IRONTON product! For future reference, please complete the owner’s record below: Model: _______________ Purchase Date: _______________ Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it.
  • Page 3: Electrical Safety

    • Keep bystanders, children, and visitors away while operating a power tool. Distractions can cause you to lose control. ELECTRICAL SAFETY • Power tool plugs must match the outlet. Never modify the plug in any way. Double insulated tools are equipped with a polarized plug (one blade is wider than the other). This plug will fit in a polarized outlet only one way.
  • Page 4 • Keep tool handles dry, clean and free from oil and grease. Slippery handles cannot safely control the tool. TOOL USE AND CARE • Secure the work piece. Use clamp or other practical way to hold the work piece to a stable platform.
  • Page 5: Extension Cords

    mouth or eyes, or lay on your skin may promote absorption of harmful material. Always use properly fitting NIOSH/OSHA approved respiratory protection appropriate for dust exposure, and wash exposed areas with soap and water. SERVICE • Have your power tool serviced by a qualified repair person using only identical replacement parts.
  • Page 6 SPECIFIC SAFETY RULES FOR ANGLE GRINDERS WARNING : Hold tool by insulated gripping surfaces when performing an operation where the cutting tool may contact hidden wiring or its own cord. Contact with a “live” wire will also make exposed metal parts of the tool “live” and shock the operator. 1.
  • Page 7: Unpacking And Contents

    20. ALWAYS wear proper apparel including long sleeve shirts, leather gloves and shop aprons to protect skin from contact with hot grindings. Use of this tool to grind or sand some products, paints and wood could expose user to containing hazardous substances. Use appropriate respiratory protection.mum Wire Gauge for Extension Cords...
  • Page 8 ASSEMBLY INSTALLING THE AUXILIARY HANDLE: WARNING: Always be sure that the tool is switched off and unplugged before performing any work on the tool. Your grinder is equipped with a two position auxiliary handle; it can be mounted on either the left, or right side of the die cast gear housing.
  • Page 9 1. Mount the inner flange with the machined "flats" side down onto the spindle. Slowly rotate the inner flange until it engages the corresponding matching machined “flats” on the spindle shaft. 2. Slide the wheel, crown side down and depressed side up, over the spindle shaft and over the raised shoulder on the inner flange.
  • Page 10 GRINDING AND SANDING OPERATION: WARNING: NEVER force the tool; the weight of the tool applies adequate pressure. Forcing and excessive pressure could cause dangerous wheel breakage. ALWAYS replace the wheel if the tool is dropped while grinding. NEVER bang or hit the grinding wheel or disc onto the work.
  • Page 11 To install the wire brush, unplug the tool and place it upside down allowing easy access to the spindle. Remove any accessories on the spindle, then thread the wire brush onto the spindle and tighten securely with an adjustable wrench while depressing the spindle lock. Perform wire brush operations in a fashion similar grinding as described in the previous section.
  • Page 12 DIAGRAM AND PARTS LIST Page of 14...
  • Page 13: Parts List

    PARTS LIST Part # Description Part # Description Upper flange Brush holder Grinding wheel Coil spring Lower flange Carbon brush Wheel guard Bearing 607 Screw m5-18 Bearing sleeve Square nut Air baffle plate Spindle Philips pan head screw Woodruff key Stator Screw M4*12 Crimped lug...
  • Page 14: Two Year Warranty

    TWO-YEAR WARRANTY This product is warranted free from defects in material and workmanship for 2 years after date of purchase. This limited warranty does not cover normal wear and tear or damage from neglect or accident. The original purchaser is covered by this warranty and it is not transferable. Prior to returning your tool to store location of purchase, please call our Toll-Free Help Line for possible solutions.
