ZALMAN CNPS9700 NT User Manual

ZALMAN CNPS9700 NT User Manual

Hide thumbs Also See for CNPS9700 NT:
1
2
3
4
5
6
7
8
9

Advertisement

Table of Contents

User's Manual
AMD Socket AM3/AM2+/AM2/754/939/940 CPU
CNPS9700 NT
Intel Socket 1155/1156/775 CPU
Core i7
Core i5
Core i3
Core 2 Quad
Core 2 Duo
Pentium Dual Core
Pentium D
Pentium 4
Celeron D
Phenom II
Phenom
Athlon II
Athlon X2
Athlon FX
Athlon
Opteron
Dual-Core Opteron
Sempron
To ensure safe and easy installation,
please read the following precautions.
www.ZALMAN.com
V 2.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CNPS9700 NT and is the answer not in the manual?

Questions and answers

Related Manuals for ZALMAN CNPS9700 NT

Summary of Contents for ZALMAN CNPS9700 NT

  • Page 1 User’s Manual CNPS9700 NT Intel Socket 1155/1156/775 CPU Core i7 Core i5 Core i3 Core 2 Quad Core 2 Duo Pentium Dual Core Pentium D Pentium 4 Celeron D AMD Socket AM3/AM2+/AM2/754/939/940 CPU Phenom II Phenom Athlon II Athlon X2...

  • Page 2: Specifications

    Check the components list and condition of the product before installation. If any problem is found, contact the retailer to obtain a replacement. Zalman Tech Co., Ltd. is not responsible for any damages due to overclocking. During transportation of the system, the cooler must be removed.
  • Page 3 3. Components 1) Common Components Thermal Grease User’s Manual Cooler [ZM-STG1] 2) Intel Components Clip Support Intel Clip Clip Support Fixing Bolts Clip Fixing Bolts Nuts Washers 3) AMD Components AMD Clip AMD Clip Lever .COM...

  • Page 4: Installation Requirements

    4. Installation Requirements 1) Space Requirements The cooler’s installation requires unobstructed space with dimensions of 127㎜ (width), 93㎜(length), 145㎜(height), and the CPU as a central reference point. Please check if components such as ODDs and PSU protrude into the required space.
  • Page 5 4) Installation Based On Clip Orientation A. Horizontal Clip Orientation B. Vertical Clip Orientation .COM...

  • Page 6: Installation

    5. Installation 1) Intel Socket 1155 / 1156 / 775 Installation ① Install the Clip Support to the motherboard according to the socket-type. Bolt(silver) Clip Support Socket 1155 / 1156 Socket 775 Washer Caution Lever Slot ▶ Please make note of the Lever Slot’s direction when installing the Clip Support.
  • Page 7 ③ Insert a Bolt into both ends of the Intel Clip, then screw each Bolt a little at a time, alternating between each Bolt, until the Clip is fully installed. Caution ▶ For installations with horizontal Clip orientation, please be cautious to not exert excessive force on the fan while using a screwdrivers to install the Clip.
  • Page 8 2) AMD Socket AM3 / AM2+ / AM2 / 754 / 939 / 940 Installation ① Remove any foreign particles from the Base of the the cooler and the surface of the CPU, then shake well the enclosed thermal grease and apply a through layer of thermal grease on the surface of the CPU and the Base of the cooler.
  • Page 9 GS1000 / GS1000SE • E-ATX / Standard ATX / microATX Compatible * Supports Intel Dual Xeon server motherboards • UP to 6 Hot Swap HDD Bays * GS1000(3 Standard / 3 Optional) * GS1000 SE(Optional) • Tool-Free HDD Installation • Airflow Optimized Design •...
