- Page 1 User’s Manual VF770 To ensure safe and easy installation, please read the following precautions. http://www.zalman.com Ver. 1.0...
-
Page 2: Specifications
1. Precautions By installing this product on a VGA (Video Graphics Array) card, one PCI slot adjacent to the PCIe (or AGP) slot occupied by the VF770 will become unusable. If this product is to be installed on a recently released VGA card, please check for compatibility at Zalman’s website first. - Page 3 3. Components VGA Cooler VGA RAM Heatsinks Dual Connector Thermal Grease User’s Manual Rubber Washers PET Washers Fixing Bolts Springs .COM...
-
Page 4: Exploded View
4. Exploded View VGA Cooler Rubber Washer RAM Heatsink VGA RAM VGA Chipset PET Washer Spring Fixing Bolt .COM... -
Page 5: Installation
5. Installation 1) VGA RAM Heatsink Attachment Remove the film from the Thermal Tapes on the bottom of the RAM Heatsinks and attach the Heatsinks on the VGA RAM. Caution Clean the surface of the RAM with acetone or alcohol before attaching the RAM Heatsinks. - Page 6 3) Thermal Grease Application Clean the contact surface of the VGA Chipset completely. Apply a thin and thorough layer of Thermal Grease on the VGA Chipset that makes contact with the base of the VGA Cooler. 4) Rubber Washer Installation Determine the appropriate holes for the Rubber Washers from the table below, then align and attach the Rubber Washers to the holes.
- Page 7 5) Spring Insertion on the Fixing Nut Install the Spring end with the smaller diameter on the Fixing Nut as shown in the diagram. 6) VGA Cooler Installation After installing the Rubber Washers to the cooler, face the VGA card’s side with the fan downward, and align with the installation holes.
-
Page 8: Power Supply
7) VGA Cooler Installation Install the VGA card to the slot after installing the cooler. 8) Power Supply Connect the 3-Pin dual connector to the User’s performance and noise preference. The Fan RPM can be adjusted according to the 3-Pin Connector’s color. - Page 9 GS1000 / GS1000SE • E-ATX / Standard ATX / microATX Compatible * Supports Intel Dual Xeon server motherboards • UP to 6 Hot Swap HDD Bays * GS1000(3 Standard / 3 Optional) * GS1000 SE(Optional) • Tool-Free HDD Installation • Airflow Optimized Design •...
