Summary of Contents for Forbes Designa
- Page 1 Safe drinking water. Your style. Healthier is Happier ANUAL...
- Page 2 A better life product from Forbes, the Forbes Designa Water Purifier has been designed to provide you with safe drinking water, day after day. We recommend you to please read the user manual to understand how the Forbes Designa Water Purifier gives your family the gift of good health.
-
Page 3: Table Of Contents
Service and Spare Parts Know Y our Purifier T echnical Data - About installation and service - About the use of the Forbes Designa Installation - Installation of divertor valve to the existing water tap - Wall mounted Installation - Using the purifier for the first time... -
Page 4: Forbes Designa
T o ensure optimal functioning it is important that you read the sections Forbes Designa and how it works. Do read it carefully before you begin to use entitled ''Know Your purifier'' on page 3 and that you follow the your Forbes Designa. -
Page 5: Description Of The Water Purifier
Description of the Water Purifier Accessories LED - Red (supplied with the appliance) LED - Green Wall mounting bracket Switch - Flush Screws Descaling agent Switch - Main switch Back flush adapter Switch - Draw water Rawl plugs EVA tube with 3/4 ” nut nozzle 2 mts Display panel Divertor Valve... -
Page 6: Know Your Purifier
- The appliance can be connected to the water and electrical supplies even - Do not attempt to modify or otherwise alter the Forbes Designa in any way. when not in use. This could result in injury and/or damage to property which are not covered - The appliance must not be operated without the Dual Filter Cartridge by any warranty. -
Page 7: Installation
Installation Installation of divertor valve to the existing water tap The Forbes Designa is very convenient to use as tabletop and wall mounted. The unit has to be connected to running water tap, near the sink. A 3-pin power socket with earthing is required for this product. -
Page 8: Wall Mounted Installation
Installation Wall mounted installation If the water purifier is to be wall mounted, proceed as follows: 1. Wall mount the purifier within 1 metre from tap. Fig 1 2. Drill three holes 43-45 mm deep in the wall according to the positions of holes in the wall bracket. -
Page 9: Using The Purifier For The First Time
4. After this period press switch (5) to further flush the purifier during 5. Shut off the purifier, by pressing switch (4). (five) minutes. Press switch (5) to stop the water flow. Forbes Designa is If the product hasn't been used for a long period, flush the unit for approx. -
Page 10: Maintenance
Maintenance Replacing the Dual Filter Cartridge The Dual Filter Cartridge needs to be replaced once in six months. 1. Disconnect the power plug. 2. T o open the removable top cover (Item 10, page 2) push the release button. 3. Open the filter house lid by turning it in the direction indicated by the arrow on the filter housing top. -
Page 11: Backflushing Procedure For Dual Filter Cartridge
Pull out the Dual Filter Cartridge with the help of hook, as shown in the figure. For better performance of your Forbes Designa, it is recommended to back flush the Dual Filter Cartridge once in 15 days as following: Place the Dual Filter Cartridge onto the lid, in such a way that the projection of the lid is inserted into the cartridge. -
Page 12: Descaling Procedure
Maintenance Descaling procedure 1. Disconnect the power plug. 2. T ake down the appliance from the wall (if wall mounted) and put it on a flat surface. 3. T ake out the Dual Filter Cartridge, keep the water in the filter house. (See instructions for replacing the Dual Filter Cartridge, page 7). -
Page 13: Regular Care Of Forbes Designa
11 of this user manual. - The everyday care of the Forbes Designa consists of simple cleaning. The outside of the appliance should be cleaned using a damp, but not wet, cloth. -
Page 14: If Forbes Designa Stops Working
If the Forbes Designa Stops Working - Trouble shooting guide T rouble Cause R emedy Red lamp lit. The room temperature is low, less then 8 °C Place the product in a warmer place. In a cold environment it could take up to 5 minutes after you turn on the purifier for the green light to lit up. -
Page 15: Service And Spare Parts
Before calling Service Centre, it is a good idea to make a note of some appliance details. Look for the data plate on the bottom of the appliance, which will have all the details you need for the Forbes Designa. Y ou can record them here: Product number : ................ - Page 16 Produced for Forbes Lux Group, Switzerland Dubai Office: Forbes Lux FZE, #207, LOB Building 17, P .O. Box 261698, Jebel Ali Free Zone, Dubai, UAE. Tel: +9714-8810115. For more information visit us at www.forbeslux.com...
