MDG ICE FOG Compack User Manual

Low fog generator
Hide thumbs
Table of Contents

Advertisement

Quick Links

TM
ICE FOG Compack
Low Fog Generator
U
G
SER
UIDE
No: 120818, Revision B/a
Les Générateurs de Brouillard MDG Ltée / MDG Fog Generators Ltd
10301 avenue Pelletier, Montréal, Québec, Canada H1H 3R2
Tel. 514-272-6040 / 800-663-3020 - Fax 514-722-3229
www.mdgfog.com
e-mail : info@mdgfog.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ICE FOG Compack and is the answer not in the manual?

Questions and answers

Related Manuals for MDG ICE FOG Compack

Summary of Contents for MDG ICE FOG Compack

  • Page 1 ICE FOG Compack Low Fog Generator UIDE No: 120818, Revision B/a Les Générateurs de Brouillard MDG Ltée / MDG Fog Generators Ltd 10301 avenue Pelletier, Montréal, Québec, Canada H1H 3R2 Tel. 514-272-6040 / 800-663-3020 - Fax 514-722-3229 www.mdgfog.com e-mail : info@mdgfog.com...
  • Page 2 ICE FOG Compack Intentionally left blank User Guide120818, Rev: B/a 2 / 19...
  • Page 3 ICE FOG Compack INTRODUCTION MDG is a company globally recognized as the leader of the fog production industry. We design and manufacture the most reliable fog/haze generators since 1979 and, we continue to impress the entertainment and industrial market with unmatched innovations.

  • Page 4: Basic Description

    At the heart of the MDG Generators is an electronic assembly that keeps the heating module(s) at a very stable temperature, which integrates three types of fail-safe systems.
  • Page 5 ICE FOG Compack Detacheable standard remote control See next page Fog Output adjustment: Pressure regulator & Gauge Maximum Operating pressure 4.14 bar (60 psi) Pressure Switch: Upward position will pressurize the Fluid Reservoir. Main Power switch Downward position will depressurize allowing to refill Power Cord the Fluid reservoir.
  • Page 6 ICE FOG Compack XLR-5 Remote Control Connector Green LED indicates that the Generator is HEAT yellow LED indicator READY to operate 1) The LED turns on and off from time to time to indicate the control of temperature. 2) The LED will start blinking indicating the FAIL mode.
  • Page 7 ICE FOG Compack Standard Accessories Fluid input: 2,5 - Liter reservoir Use only MDG Low Fog Fluid Output Fog Hose: 2.5 m (8’) long / 13 cm (5”) diameter Low Fog Different lengths available Output Front cover Optional Accessories IF35-RCT...
  • Page 8 ICE FOG Compack High pressure Liquid Carbon Dioxide (L-CO ) with Dip Tube (or Siphon) Use only carbon dioxide cylinder equipped with a dip (siphon) tube) allowing the discharge of liquid CO Dip (Siphon) tube Refrigerated Low pressure Liquid Carbone Dioxide (L-CO ) Container (Dewar preset at 1500 kPa (225 psi).

  • Page 9: Operating Instructions

    ICE FOG Compack OPERATING INSTRUCTIONS The MDG Low Fog Generators are quite easy to operate and require no preventive maintenance. They are supplied with a removable remote control. A DMX Interface can be purchased as an option. When the MAIN POWER 115 or 230 VAC and the MAIN POWER SWITCH are applied, the generator is placed in stand-by mode.

  • Page 10: Startup Procedure

    OFF the pressure switch located on the back panel of the generator. Unscrew the brass cap Pour the MDG Low Fog Fluid until it reaches the inside bottom of the opening. Avoid overfilling. Screw back the closure and make sure it is hand tightened.
  • Page 11 ICE FOG Compack  When not in use ALWAYS switch off the power switch located on the back panel, or unplug the generator.  Never install above people.  These Low Fog Generators must be installed on a stable and horizontal surface.
  • Page 12 ICE FOG Compack LIQUID GAS REQUIREMENTS WARNING In the European Community the gas cylinder and regulator must be compliant with the Pressure Vessel Directive. In North America the gas cylinder must be manufactured, inspected and tested in accordance with U.S. Department of Transportation (DOT) 3AL and Transport Canada (TC) 3ALM requirements.

  • Page 13: Shutdown Procedure

    ICE FOG Compack SHUT DOWN PROCEDURE A generator must never be shut down while making Fog. To power off a generator the following sequence must be observed:  Always turn off the low fog emission on the remote,  Switch off the pressure switch on the main panel ...
  • Page 14  Always turn off the low fog emission on the remote,  Switch off the pressure switch on the main panel  Unscrew the brass cap and pour the MDG Low Fog Fluid until it reaches the inside bottom of the opening.

  • Page 15: Technical Data

    ICE FOG Compack TECHNICAL DATA Model ICE FOG Compack Fluid consumption 0.035 L (1.05 oz) (per minute at full output) Liquid CO type High pressure version: Non-refrigerated Low pressure version: Refrigerated Liquid CO consumption High pressure version:1.35 kg (3 lb) at 6000 kPa (875 psi) (per minute) Low pressure version: 3 L (6.8 lb) at 1500 kPa (225 psi)

  • Page 16: Technical Dimensions

    ICE FOG Compack TECHNICAL DIMENSIONS User Guide120818, Rev: B/a 16 / 19...

  • Page 17: Warranty

    MDG or one of is authorized service center, or if it is used under conditions for which it has not been designed, or if a none MDG Fog Fluid has been used. MDG Fog Generators Ltd is not responsible for any damages resulting from a faulty installation or from abusive use of the product.

  • Page 18: Declaration Of Conformity

    ICE FOG Compack DECLARATION OF CONFORMITY User Guide120818, Rev: B/a 18 / 19...
  • Page 19 ICE FOG Compack NOTE User Guide120818, Rev: B/a 19 / 19...
