Philips AZ 3038 Service Manual
Philips AZ 3038 Service Manual

Philips AZ 3038 Service Manual

Cd sound machine

Advertisement

Quick Links

CD Sound Machine

TABLE OF CONTENTS

Technical Specification & Measurement Setup ...............2 - 1
Service tools ....................................................................2 - 1
Service Measurement......................................................2 - 2
Connections and controls........................................3 - 1 3 -2
Instructions for use ..................................................3 - 3 3 -4
Block Diagram .................................................................4 - 1
Wiring Diagram ................................................................4 - 2
Pins description and Block diagram of IC...............5 - 1 5 - 2
circuit diagram .........................................................6 - 1
layout diagram................................................6 - 2 6 - 3
circuit diagram .........................................................7 - 1
layout diagram.........................................................7 - 2
Tuner adjustment ....................................................7 - 2
©
Copyright 2001 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in a retrieval
system or transmitted, in any form or by any means, electronic, mechanical, photocopying,
or otherwise without the prior permission of Philips.
Published by YT 0313 Service Audio
Printed in The Netherlands
Subject to modification
circuit diagram .........................................................8 - 1
layout diagram.........................................................8 - 2
circuit diagram .........................................................9 - 1
layout diagram.........................................................9 - 2
Exploded view ...............................................................10 - 1
Mechanical partslist .......................................................10 - 2
Electrical partslist ...............................................11 - 1 11 - 2
AZ 3038
all versions
CLASS 1
© 3140 785 32040

Advertisement

Table of Contents
loading

Summary of Contents for Philips AZ 3038

  • Page 1: Table Of Contents

    LASER PRODUCT © Copyright 2001 Philips Consumer Electronics B.V. Eindhoven, The Netherlands All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without the prior permission of Philips.
  • Page 2: Handling Chip Components

    1 - 1 HANDLING CHIP COMPONENTS © ñ WARNING WAARSCHUWING All ICs and many other semiconductors are susceptible to Alle IC´s en vele andere halfgeleiders zijn gevoelig voor electrostatic discharges (ESD). Careless handling during electrostatische ontladingen (ESD). repair can reduce life drastically. Onzorgvuldig behandelen tijdens reparatie kan de levensduur When repairing, make sure that you are connected with the drastisch doen vermindern.
  • Page 3: Service Tools

    2 - 1 TECHMICAL SPECIFICATIONS TUNER - FM SECTION GENERAL Tuning range : 87.5 - 108 MHz Mains voltage -/00C : 230 V IF frequency : 10.7 MHz ± 0.2 MHz /05 : 240V Sensitivity : 20 dBf at 26dB S/N Mains frequency -/00C/05 : 50 Hz Selectivity...
  • Page 4: Service Measurement

    2 - 2 SERVICE MEASUREMENT Bandpass Tuner SW LF Voltmeter 250Hz-15kHz Aerial replacement e.g. PM2534 e.g. 7122 707 48001 RF Generator Capacitor e.g. PM5326 S/N and distortion meter e.g. Sound Technology ST1700B To avoid atmospheric interference all AM-measurements have to be carried out in a Faraday«s cage. Use a bandpass filter (or at least a high pass filter with 250Hz) to eliminate hum (50Hz, 100Hz).
  • Page 5: Connections And Controls

    3 - 1 CONNECTIONS AND CONTROLS...
  • Page 6 3 - 2 CONNECTIONS AND CONTROLS...
  • Page 7: Instructions For Use

    3 - 3 INSTRUCTIONS FOR USE...
  • Page 8 3 - 4 INSTRUCTIONS FOR USE For more detail on operation instruction please visit Philips Audio internet site : http://www.audio.philips.com...
  • Page 9: Block Diagram

    4 - 1 4 - 1 BLOCK DIAGRAM...
  • Page 10: Wiring Diagram

    4 - 2 4 - 2 WIRING DIAGRAM...
  • Page 11 5 - 1 5 - 1 PINS DESCRIPTION OF IC BLOCK DIAGRAM OF IC 29ILV400B BA6892FP MC 1 44 RESET# RY/BY# 2 43 WE# A17 3 42 A8 A7 4 41 A9 A6 5 40 A10 A5 6 39 A11 A4 7 38 A12 A3 8...
  • Page 12 5 - 2 5 - 2 BLOCK DIAGRAM AND PINS DESCRIPTION PINS DESCRIPTION OF IC GSL88301 WM8725 Name I/O Function LRCIN SCKI Data Bus bit 15-8 / XD15-8 GPIO D bit 15-8 FORMAT 11-18 XD7-0 I/O Data Bus bit 7-0 DEEMPH 19-43 A0-18...
  • Page 13: Cd Board Circuit Diagram

    6 - 1 6 - 1 CD BOARD - CIRCUIT DIAGRAM...
  • Page 14: Layout Diagram

    6 - 2 6 - 2 CD BOARD - LAYOUT DIAGRAM...
  • Page 15 6 - 3 6 - 3 CD BOARD - LAY0UT DIAGRAM...
  • Page 16: Tuner Board Circuit Diagram

    7- 1 7 - 1 TUNER BOARD - CIRCUIT DIAGRAM...
  • Page 17: Tuner Adjustment

    7 - 2 7 - 2 TUNER BOARD - LAYOUT DIAGRAM TUNER ADJUSTMENT TABLE ( ECO6 FM/MW- and FM/MW/LW - versions with ferrite antenna) Waverange Input frequency Input Tuned to Adjust Output Scope/Voltmeter 1105 B7 2106 D6 2129 C5 2155 C5 2191 A2 5102 D7 5110 B3...
  • Page 18: Front Board Circuit Diagram

    8 - 1 8 - 1 FRONT BOARD - CIRCUIT DIAGRAM...
  • Page 19: Layout Diagram

    8 - 2 8- 2 FRONT BOARD - LAYOUT DIAGRAM...
  • Page 20: Power Board Circuit Diagram

    9 - 1 9 - 1 POWER BOARD - CIRCUIT DIAGRAM...
  • Page 21: Layout Diagram

    9 - 2 9 - 2 POWER BOARD - LAYOUT DIAGRAM...
  • Page 22: Exploded View

    10 - 1 10 - 1 EXPLODED VIEW DIAGRAM - CABINET 63 62 57 56 54 53 28 29...
  • Page 23: Mechanical Partslist

    10 - 2 MECHANICAL PARTSLIST 9965 000 13405 FRONT CONTROL PANEL 9965 000 13407 FUNCTION KNOB 9965 000 13409 CD SEARCH +/-KEY 9965 000 13408 TUNING UP KNOB 9965 000 13410 BAND KNOB 9965 000 13413 FEET RIGHT (BLACK) 9965 000 11807 RUBBER FOOT STAND 9965 000 13412 FEET LEFT (BLACK)
  • Page 24 11 - 1 ELECTRICAL PARTSLIST - TUNER BOARD - MISCELLANEOUS - - DIODES - 1106 4822 158 60645 FERRITE BAR 6103 5322 130 34337 BAV99 2106 2020 800 00191 CTRM 100V 3P-11P N450 6105 4822 130 83075 HN1V02H-B 2155 2020 800 00191 CTRM 100V 3P-11P N450 6120 9340 255 30135...
  • Page 25: Electrical Partslist

    11 - 2 ELECTRICAL PARTSLIST MICOM (MICROCOMPUTER) BOARD CD MAIN BOARD - COILS & FILTERS - - COILS & FILTERS - 9965 000 13437 FER. CORE FCI2012-R82K JW15 4822 157 71363 10µH 035N 9965 000 13436 FIL. NFM3212R13C223R JW31 4822 157 71363 10µH 035N 9965 000 13436 FIL.

Table of Contents
