USB ports
(Wired version)
Power
(Bluetooth version)
WIRED VERSION
1.
Insert USB cable into a spare USB port on your computer
2.
There are two auxiliary USB ports on the rear of the keyboard for use with peripherals
Warning lights
a.
Number lock (Number Lock key found on slide out number pad)
b.
Caps lock
c.
Scroll lock
BLUETOOTH VERSION
To pair with a Windows® PC
1.
Turn on Bluetooth via the Control Panel on your PC and search for devices
2.
On the keyboard rear edge, slide the keyboard ON/OFF switch to the ON position
3.
Press the 'CONNECT' button on the rear edge. The power light should flash until pairing is
complete
4.
On your PC control panel, select Posturite KB Number Slide
5.
To un-pair at any time, simply delete from the list of Bluetooth items
Connect
(Bluetooth pairing)
With built in rechargeable Li-ion battery (charging cable included)
(b)
(a)
(c)
Tab - pull gently
to slide out
number pad
Advertisement
Table of Contents
Need help?
Do you have a question about the Number Slide and is the answer not in the manual?
Questions and answers
When I charge it, the red light doesn’t show up, but if I touch it then it shows up
If the red light does not show up when charging the Posturite Number Slide, possible reasons include:
1. Improper Connection – Ensure the USB end is directly connected to a computer's USB port (not a multi-port hub) and the micro USB end is properly inserted into the keyboard.
2. Faulty Cable or Port – Try using a different USB cable or port to check if the issue persists.
3. Battery Already Fully Charged – The red LED light turns off when charging is complete.
4. Battery or Hardware Issue – If the keyboard does not charge or function, the battery or internal components may be faulty.
Checking these factors can help identify the cause of the issue.
