Luxman DA-200 Owner's Manual

Luxman DA-200 Owner's Manual

Usb d/a converter
Hide thumbs Also See for DA-200:
Table of Contents

Advertisement

Quick Links

Owner`s Manual

Advertisement

Table of Contents
loading

Related Manuals for Luxman DA-200

Summary of Contents for Luxman DA-200

  • Page 1 Owner`s Manual...

  • Page 2: Table Of Contents

    Contents Precautions ············································································································· 1 Features of This Unit ································································································ 2 Names and Functions ······························································································ 4 Connections ············································································································ 8 Operations ············································································································· 10 Block Diagram ······································································································· 12 Specifications ········································································································ 13 Before Asking for Repair Services ·········································································· 14...

  • Page 3: Precautions

    Precautions USB D/A CONVERTER DA-200 Installation place Cleaning • Choose a stable place near the devices that are to be used • Usually, wipe the unit with a dry soft cloth. When the dirt in combination with this unit. is hard to remove, dip soft cloth in detergent diluted 5 or 6 •...

  • Page 4: Features Of This Unit

    PCM1792A manufactured by Burr-Brown DD converter function For the DAC chip, this unit applies PCM1792A manufactured by Burr-Brown that has been used for the Luxman new D- All the digital inputs including USB are converted into digital series SACD players.
  • Page 5 USB D/A CONVERTER DA-200 Compatibility with high-resolution formats Input/output terminals This unit has the compatibility with digital inputs of 32 kHz to Introduction of an 18 mm pitch RCA terminal with gold plating 192 kHz (32 kHz to 96 kHz for USB) sampling frequencies...

  • Page 6: Names And Functions

    Names and Functions Front panel 1. Operation switch (OPERATION) 4. Sampling frequency LED (SAMPLING RATE) Toggles the power on and off. When wiring or connection is performed, be sure to turn off Displays the sampling frequency of a digital input signal this switch.
  • Page 7 7. Line output level fix indicator (FIX/VARIABLE). (FIX LINE-OUT) Relational table of the input and output of DA-200 Lights up when the line output level fix/variable selection Line output Digital output...

  • Page 8: Rear Panel

    Names and Functions Rear panel 13 14 15 16 17 9. Analog input terminals (LINE-1/LINE-2) 11. Line output level fix/variable selection switch (FIX/VARIABLE) These are RCA input terminals used for the line level input signals from a CD player, an SACD player, a tuner, a DVD Toggles the level of the playback signals from the analog player, a TV, and other such devices.
  • Page 9 The playback signals from analog input terminals (LINE-1/ kHz is input, the sampling frequency is internally converted LINE-2) are not output from this terminal. into 96 kHz. Relational table of the input and output of DA-200 14. Digital input terminal (COAX) Line output Digital output...

  • Page 10: Connections

    Connections DVD PLAYER CD/SACD PLAYER TUNER ( D ) ( B ) ( C ) ( A ) (To the headphone jack PC／Mac on the front panel of this unit) HEADPHONE VARIABLE CD PLAYER (Equipped with digital input terminals) ( E ) ( F ) ( G ) POWER AMP...
  • Page 11 USB D/A CONVERTER DA-200 How to connect power supply How to connect output devices 1. Unbalanced connection with such Use the accessory power cable and insert the AC plug in an device as a pre-main amplifier outlet on the wall in the room where the unit will be installed.

  • Page 12: Operations

    Operations Sound reproduction of a device connected This unit is a D/A converter. Any operations for sound repro- duction are performed with such input device as a PC/Mac or to an analog input terminal (Analog output) CD player connected to the input terminals. 1.
  • Page 13 ABLE) is set to VARIABLE and the analog unbalance output terminals (RCA) of this unit and the main in terminals (MAIN IN) of such device as a pre-main amplifier (such as Luxman L- 505u) equipped with the separate function , the pre-amplifier section can be upgraded to a newly-designed pre-amplifier circuit.

  • Page 14: Block Diagram

    Block Diagram...

  • Page 15: Specifications

    Specifications USB D/A CONVERTER DA-200 Format 2-channel, USB D/A converter Ambient operating +5 °C to +35 °C temperature 290mV / 24kΩ Line input Input sensitivity/input impedance Output voltage / UNBALANCE terminal (RCA terminal) Fixed output 2.5 Vrms/400Ω output impedance UNBALANCE terminal (LINE terminal) Variable output 1.0 Vrms/400Ω...

  • Page 16: Before Asking For Repair Services

    · Connect digital cables correctly. 8∼9 volume is too low. (Digital input) · If the USB is selected as an input source, select this unit (DA-200) as Refer to the instruc- the output destination by configuring the sound setting of a PC/Mac.
  • Page 17 MEMO USB D/A CONVERTER DA-200...
  • Page 18 MEMO...
  • Page 20 LUXMAN CORPORATION, JAPAN AG00987C81A Printed in Japan...
