Parts List - Icom IC-F70DT Service Manual

SECTION 6
[MAIN UNIT]
REF ORDER
NO. NO.
IC1 1130010100 S.IC LMX2352TMX
IC2 1110005340 S.IC NJM12902V-TE1
IC3 1110003490 S.IC TA31136FN
IC4 1190002050 S.IC SPM5001
IC5 1110002750 S.IC TA75S01F (TE85R)
IC6 1130004200 S.IC TC4S66F (TE85R)
IC12 1110005340 S.IC NJM12902V-TE1
IC300 1130009700 S.IC LC73872M-TRM
IC301 1110006220 S.IC AK2346-E2
IC302 1130008230 S.IC BU4053BCFV-E2
IC303 1190001350 S.IC M62364FP 600D
IC304 1110006260 S.IC BD5242G-TR
IC305 1130008230 S.IC BU4053BCFV-E2
IC307 1140010190 S.IC HD64F2268TF20
IC308 1140009240 S.IC HN58X24128FPI
IC310 1190001340 S.IC M62334FP 600C
IC311 1180002270 S.REG TK11250CMCL
IC312 1190001860 S.IC EW-460-FT
IC313 1130006220 S.IC TC4W53FU (TE12L)
Q1 1590001940 S.TR DTC144EE TL
Q2 1560000540 S.FET 2SK880-Y (TE85R)
Q3 1530002850 S.TR 2SC4116-BL (TE85R)
Q4 1530002920 S.TR 2SC4226-T1 R25
Q5 1530002920 S.TR 2SC4226-T1 R25
Q6 1530003310 S.TR 2SC5107-O (TE85R)
Q7 1590001400 S.TR XP1214 (TX)
Q8 1590001940 S.TR DTC144EE TL
Q9 1530003310 S.TR 2SC5107-O (TE85R)
Q10 1530003310 S.TR 2SC5107-O (TE85R)
Q11 1530003420 S.TR 2SC5110-O (TE85R)
Q12 1560001240 S.FET RD01MUS1
Q13 1560001230 S.FET RD07MVS1
Q14 1530002380 S.TR 2SC4215-Y (TE85R)
Q15 1590002430 S.TR DTA144EE TL
Q16 1590001940 S.TR DTC144EE TL
Q17 1560000670 S.FET 2SK1771 (TE85R)
Q18 1580000730 S.FET 3SK293 (TE85L)
Q19 1560000840 S.FET 2SK1829 (TE85R)
Q20 1530002920 S.TR 2SC4226-T1 R25
Q21 1590001400 S.TR XP1214 (TX)
Q300 1590001940 S.TR DTC144EE TL
Q302 1590001940 S.TR DTC144EE TL
Q303 1530002380 S.TR 2SC4215-Y (TE85R)
Q304 1510000920 S.TR 2SA1577 T106 Q
Q305 1510000920 S.TR 2SA1577 T106 Q
Q306 1510000920 S.TR 2SA1577 T106 Q
Q307 1590001190 S.TR XP6501-(TX) AB
Q308 1520000450 S.TR 2SB1132 T100 Q
Q309 1590003320 S.FET TPC6103 (TE85L)
Q310 1590001940 S.TR DTC144EE TL
Q311 1590002430 S.TR DTA144EE TL
D1 1790001260 S.DIO MA2S077-(TX)
D2 1790001260 S.DIO MA2S077-(TX)
D3 1790001250 S.DIO MA2S111-(TX)
D4 1750000770 S.VCP HVC376BTRF
D5 1750000770 S.VCP HVC376BTRF
D6 1750000770 S.VCP HVC376BTRF
D7 1750000770 S.VCP HVC376BTRF
D8 1720000470 S.VCP 1SV239 (TPH3)
D9 1790001260 S.DIO MA2S077-(TX)
D10 1790001260 S.DIO MA2S077-(TX)
D11 1790001670 S.DIO RB706F-40T106
D12 1750000580 S.DIO 1SV307 (TPH3)
D13 1750001070 S.DIO DAN235ETL
D14 1750001070 S.DIO DAN235ETL
D15 1750000710 S.VCP HVC350BTRF
D16 1750000710 S.VCP HVC350BTRF
D17 1790001250 S.DIO MA2S111-(TX)
D18 1750000720 S.VCP HVC375BTRF
D19 1750000720 S.VCP HVC375BTRF
D20 1790001260 S.DIO MA2S077-(TX)
D21 1790001240 S.DIO MA2S728-(TX)
D22 1750000580 S.DIO 1SV307 (TPH3)
D23 1790001250 S.DIO MA2S111-(TX)
D24 1720000640 S.VCP 1SV284 (TPH3)
D25 1750000720 S.VCP HVC375BTRF
D26 1720000640 S.VCP 1SV284 (TPH3)
D27 1720000640 S.VCP 1SV284 (TPH3)
D28 1720000640 S.VCP 1SV284 (TPH3)
D29 1750000770 S.VCP HVC376BTRF
D30 1750000770 S.VCP HVC376BTRF

PARTS LIST

DESCRIPTION M.
B
T
B
B
T
B
T
B
B
B
T
B
B
B
B
T
B
B
T
B
T
B
T
T
T
B
B
B
B
B
T
T
B
T
T
B
T
T
T
B
T
B
T
B
B
B
B
B
B
B
B
B
B
B
T
T
T
T
B
B
B
B
B
B
B
T
T
T
T
T
T
T
B
T
T
T
T
T
T
T
T
[MAIN UNIT]
H/V REF ORDER
LOCATION NO. NO.
8.3/75.8
D31 1790001250 S.DIO MA2S111-(TX)
8/75.7
D301 1160000050 S.DIO DAP202U T106
14.6/57.6
D302 1160000050 S.DIO DAP202U T106
31.4/78.3
D303 1160000050 S.DIO DAP202U T106
24.8/101.4
D304 1160000050 S.DIO DAP202U T106
17.7/85.4
D306 1730002320 S.ZEN MA8051-M (TX)
31.9/56.5
D307 1790001260 S.DIO MA2S077-(TX)
34.9/29.5
D308 1790001250 S.DIO MA2S111-(TX)
15/39.8
D309 1790001250 S.DIO MA2S111-(TX)
13.9/29.3
D310 1750000270 S.DIO 1SS301 (TE85R)
20.2/71.7
D311 1750000270 S.DIO 1SS301 (TE85R)
4.7/8.6
D312 1790001250 S.DIO MA2S111-(TX)
33.4/66.4
D313 1160000050 S.DIO DAP202U T106
20.2/15
38.2/17.7
32.5/84.4
FI1 2020001930 S.CER CFWCA450KFFA-R0
8.6/119.6
FI2 2020002120 S.CER CFWCA450KGFA-R0
30.1/43.8
FI3 2030000410 S.MLH FL-380 MFT46.3P
8.5/38.2
X1 6050012060 S.XTL CR-796 (15.300 MHz)
8.4/88.3
X2 6070000190 S.DCR CDBCB450KCAY24-R0
24.2/80.5
X300 6050012100 S.XTL CR-800 (3.579545 MHz)
9.1/96.8
X301 6050012090 S.XTL CR-799 (3.6864 MHz)
19.3/95.8
X302 6050012110 S.XTL CR-803 (19.6608 MHz)
25.2/93.8
22.3/97
26.6/96
L1 6200004930 S.COL MLF1608E 8R2K-T
18.4/93
L2 6200011250 S.COL LLQ1608-A18NG
14.8/94.8
L3 6200007170 S.COL MLF1608A 3R3K-T
24/99.4
L4 6200007170 S.COL MLF1608A 3R3K-T
14/100.9
L6 6200008090 S.COL LQW2BHN68NJ01L
14.9/109.8
L7 6200003640 S.COL MLF1608E 100K-T
21/109.4
L8 6200003640 S.COL MLF1608E 100K-T
8.9/64.9
L9 6200011110 S.COL 0.40-2.00-9TL 80.2N
21.3/64.7
L10 6200007760 S.COL LQW2BHN82NJ01L
19.3/64.7
L11 6200009180 S.COL ELJRE R10J-F3
15.3/64.3
L12 6200011240 S.COL LLQ1608-A33NG
34.3/96.3
L13 6200011280 S.COL C1608CB-R10G
33/93.5
L14 6200005740 S.COL ELJRE 47NG-F
19.3/92.1
L15 6200003590 S.COL EXCCL3225U1
18.6/95.3
L16 6200005690 S.COL ELJRE 18NG-F
36.7/49.7
L17 6200008210 S.COL 0.45-1.5-5TL 23.2N
7.2/5.9
L18 6200009710 S.COL 0.30-0.9-4TL 10.5N
19.4/49
L19 6200008490 S.COL 0.30-0.9-3TR 7.5N
3.9/106
L20 6200008280 S.COL 0.30-1.7-7TL 50N
7.3/101.7
L21 6200002860 S.COL NL 252018T-4R7J
5.6/84.6
L22 6200009800 S.COL 0.26-1.1-7TR 30N
3.4/110.6
L23 6200008580 S.COL 0.30-1.4-6TL 32N
4.1/119.1
L24 6200003540 S.COL MLF1608D R22K-T
12.3/120.1
L25 6200004480 S.COL MLF1608D R82K-T
8.9/9.6
L26 6200002690 S.COL MLF1608A 1R0M-T
33.3/45.1
L27 6200004660 S.COL MLF1608A 1R8K-T
L29 6200004790 S.COL MLF1608D R47K-T
L30 6130003000 S.COL 617DB-1714=P3
12.9/87.1
L31 6130003000 S.COL 617DB-1714=P3
12.9/88.9
L32 6200004780 S.COL MLF1608A 1R5K-T
10/93.3
L33 6130003000 S.COL 617DB-1714=P3
10.9/89.3
L34 6200011260 S.COL C1608CB-15NG
12.1/89.3
L35 6200011260 S.COL C1608CB-15NG
27.2/85.4
L37 6200009920 S.COL C2012C-R10G
25/85.3
L38 6200011050 S.COL C2012C-R12G
26.3/90.2
L39 6200011050 S.COL C2012C-R12G
24.9/101.4
L40 6200011150 S.COL C1608CB-68NG
19.6/101.3
L41 6200010400 S.COL ELJRE 39NJ-F
30.5/104.3
L42 6200008280 S.COL 0.30-1.7-7TL 50N
35.3/108.7
L43 6200007170 S.COL MLF1608A 3R3K-T
20/60
L44 6200007170 S.COL MLF1608A 3R3K-T
21.6/55.4
L45 6200011130 S.COL C1608CB-12NG
40.1/89.5
L46 6200004660 S.COL MLF1608A 1R8K-T
39.4/92.1
L47 6200007170 S.COL MLF1608A 3R3K-T
35.1/89.7
L48 6200007170 S.COL MLF1608A 3R3K-T
40.3/98.6
L49 6200010100 S.COL C2012C-33NG
39.1/104.1
L50 6200003640 S.COL MLF1608E 100K-T
35.2/105.5
L51 6200011120 S.COL 0.40-2.00-10TL 90.5N
35.2/109
L52 6200011150 S.COL C1608CB-68NG
40.4/106.3
L53 6200011140 S.COL C1608CB-39NG
28.1/102.4
L54 6200011150 S.COL C1608CB-68NG
13.5/91.3
L55 6200010310 S.COL C2012C-27NG
21.9/88.8
L56 6200011230 S.COL LLQ1608-A22NG
13.8/90.1
L57 6200011230 S.COL LLQ1608-A22NG
17.4/89.3
L58 6200011060 S.COL C1608CB-18NG
16.2/89.5
L60 6200009890 S.COL C2012C-82NG
13.3/85.5
L61 6200009920 S.COL C2012C-R10G
13.3/88
L301 6200002860 S.COL NL 252018T-4R7J
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
6 - 1
DESCRIPTION M.
T
T
B
T
T
B
B
B
T
B
B
B
B
T
B
B
B
T
B
B
B
B
B
T
T
T
T
T
T
T
T
B
B
B
B
T
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
T
B
B
T
T
T
T
T
B
B
B
B
T
B
B
S.=Surface mount
