Bodi-Tek Ab-Tek Belt User Manual

Hide thumbs Also See for Ab-Tek Belt:

Advertisement

Table of Contents

See also: User Manual
fitness
fitness
Ab-Tek Belt
TM
© The Dezac Group 2011
© The Dezac Group 2011
© The Dezac Group 2011
User Guide
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ab-Tek Belt and is the answer not in the manual?

Questions and answers

Related Manuals for Bodi-Tek Ab-Tek Belt

Summary of Contents for Bodi-Tek Ab-Tek Belt

  • Page 1 Ab-Tek Belt © The Dezac Group 2011 © The Dezac Group 2011 © The Dezac Group 2011 User Guide...
  • Page 2 • You have suffered acute trauma, fracture or are recovering from recent surgery. • You have swollen, inflamed or injured parts of the body • You have diabetes and it affects the sensory perception of your extremities. © The Dezac Group 2011 If you are in any doubt about using the Ab-Tek Belt for any reason, please consult your doctor before use. Do not place the Ab-tek Belt: • Over sore or broken skin, scars, moles, infected areas or parts of the body where normal sensation is limited. In very rare cases, skin irritation occurs around the electrode area. If this happens discontinue use.
  • Page 3 • Do NOT clean with solvents or abrasives • If the gel comes into contact with the eyes, rinse thoroughly with water. If irritation persists, © The Dezac Group 2011 consult a doctor. • Should you experience any discomfort, firstly reduce the intensity, if discomfort persists discontinue use and contact our Customer Care line • Always consult your doctor and obtain a diagnosis if you do not know what is causing your pain. • Bodi-Tek will not accept responsibility if the guidelines and instructions supplied with the unit are not followed. © The Dezac Group 2011 General Care • DO NOT immerse the unit in water. • Never machine wash your belt, you can hand wash it with warm water. • Do not place the unit close to excessive heat.

  • Page 4: Table Of Contents

    Contents Introduction ..............................5 Welcome to your Ab-Tek Belt ......................6 The Ab-Tek Belt Display ........................7 Getting Started ............................8 Operating Guide & Excerise Guidance ..................9 © The Dezac Group 2011 Troubleshooting Guide ........................10 Troubleshooting Guide & Maintance ..................11 Warranty & Disposal ..........................12 Technical Specification & Environment .................. 13 © The Dezac Group 2011...

  • Page 5: Introduction

    How does the Ab-tek Belt work? The Ab-Tek Belt works on the principle of EMS (Electrical Muscle Stimulation). It generates safe, gentle electrical pulses that are delivered onto your skin through the special electrodes placed on the inside ©...

  • Page 6: Control Unit/Display Overview

    Welcome to your Ab-Tek Belt Control Unit MODE KEY • Pressing the key once takes you to the Toning program ON/HI • Pressing it down briefly will turn the unit ON • Single presses increase intensity OFF/LO • Single presses decrease intensity of the contractions until it turns off © The Dezac Group 2011 RESET • Holding the reset key down, restarts the unit Battery Compartment • Sliding down the cover reveals the compartment. 2 x 1.5V AAA batteries should be placed in this compartment ©...

  • Page 7: The Ab-Tek Belt Display

    The Ab-Tek Belt Display HIGH Step The display shows how intense the contraction is by blackening the step segments from left to right depending on selection. This ranges from 1-10. © The Dezac Group 2011 Mode The mode will display which programme you are using by highlighting the programme letter. MoDE nAME DESCRIPtIon Toning 4 pulses per second © The Dezac Group 2011 Massage 8 pulses per second Warm Up 20 pulses per second...

  • Page 8: Detaching Unit From Belt Cradle

    Getting Started Detaching unit from Belt cradle Once you have unpacked the Ab-Tek Belt, you will find the main unit sitting inside the cradle on the belt. To detach the main unit, push the top half of the unit firmly away from the cradle, once the unit has snapped out from the magnetic contacts on the cradle, just slide it out.

  • Page 9: Operating Guide

    Operating Guide Operation 1. Switch the unit on by pressing the ON/HI button once. The LCD display will show the level. 2. Select mode A - F by pressing the MODE button repeatedly. 3. Push the ON/HI button several times to carefully increase the intensity. 4. You will notice a tingling sensation prior to the muscle contracting. Once the muscle is contracting it will be pleasant and relaxing. Adjust the intensity according to your comfort level. You should feel a strong but comfortable contraction of the muscles. 5. The intensity has 10 steps. With every push of the button ON/HI you increase the intensity by one step, with every push of the button OFF/LO you decrease the intensity by one step. 6. To switch the unit off, press the OFF/LO button until the display goes blank. © The Dezac Group 2011 Push on/HI button x10 to increase intensity 10 steps Push oFF/Lo button 10 x to decrease intensity 10 steps ©...

  • Page 10: Troubleshooting Guide

    Troubleshooting Guide PRoBLEM PoSSIBLE CAUSE SoLUtIon No LCD Display Batteries not installed Install Batteries Batteries installed incorrectly Check Polarity matches Batteries are dead Replace batteries LCD Display shown No skin contact Use Conductive Gel on conductive area of belt and directly onto skin but no function Unit not snapped on Check that the unit is connected firmly with both connectors belt correctly...
  • Page 11 Use a new battery Wrong battery polarity Remove and insert correctly Incorrect pad placement Move the pad until you feel a stong contraction Defective unit Contact Bodi-Tek Prickling sensation but no Incorrect pad placement Move the pad until you feel a stong contraction contraction © The Dezac Group 2011...

  • Page 12: Warranty & Disposal

    Warranty If you have any questions, or if you experience any difficulties with this product, please call our customer care line on +44 (0)1242 702360 or email us at online@bodi-tek.co.uk To register your two year guarantee online visit: www.bodi-tek.co.uk/warranty Disposal The Waste of Electrical and Electronic Equipment (WEEE) Directive (2002/96/EC) has been put in place to recycle products using best available recovery and recycling techniques to minimise the impact on the environment, saving energy and resources and avoiding © The Dezac Group 2011 hazardous materials from going to landfill.

  • Page 13: Technical Specifications

    Technical Specifications Program Details oUtPUt VoLtAGE 90V p-p across 500 ohm load oUtPUt CURREnt 180mA across 500 ohm load oUtPUt FREQUEnCY 4 - 37Hz PULSE WIDtH 50 µs PoWER SUPPLY 2 x 1.5V AAA batteries - Type LR033 © The Dezac Group 2011 Environment Operating Conditions: 0 - 40°C 20 - 65% RH Storage Conditions: 0 - 55°C 10 - 65% RH Read these instructions carefully before use and then retain for future use. © The Dezac Group 2011 This means that the unit complies with current product legislation ©...
  • Page 14 © The Dezac Group 2011 © The Dezac Group 2011 © The Dezac Group 2011...
  • Page 15 © The Dezac Group 2011 © The Dezac Group 2011 © The Dezac Group 2011...
  • Page 16 © The Dezac Group 2011 © The Dezac Group 2011 Bodi-Tek, Bodi-Tek Technology for Life, Dezac and Ab-Tek Belt are trademarks of The Dezac Group Ltd 2011 ©The Dezac Group Ltd 2011 Manufactured by The Dezac Group Ltd. Dezac House, Montpellier St., Cheltenham, GL50 1SS, UK www.bodi-tek.co.uk...
