Foxun SX-KVM-401 Operating Instructions

Table of Contents

Download this manual

4-PORT HDMI KVM Switch

Operating Instructions

4-PORT HDMI KVM SWITCH

Dear Customer

Thank you for purchasing this product. For optimum performance and safety,

please read these instructions carefully before connecting, operating or adjusting

this product. Please keep this manual for future reference.

FEATURES

Using only 1 set of keyboard, mouse and monitor to control 4/8 host

devices.

Support Windows 95/98/2000/2003/NT/XP/WIN7/WIN8, Linux, Unix, MAC

OSS.

Support hot plug, connect or disconnect devices to the KVM switch in any

time and without turn off devices.

Support auto switching (monitor the devices in a specified time interval.

Support keyboard hot keys to control KVM switch.

Available to use keyboard and mouse without any delay after switch host

devices.

Support auto switching host devices by just moving mouse.

Support resolution up to 1920*1440.

Our company reserve the right to make changes in the hardware, packaging and

any accompanying documentation without prior written notice.

Operating Instructions

Table of Contents

Do you have a question about the SX-KVM-401 and is the answer not in the manual?

Page 1 Operating Instructions 4-PORT HDMI KVM Switch Operating Instructions 4-PORT HDMI KVM SWITCH Dear Customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. FEATURES Using only 1 set of keyboard, mouse and monitor to control 4/8 host devices.
Page 2 Operating Instructions SPECIFICATIONS Specification Resolutions (Max) 1080p Scan interval Default 6 seconds Switch by Button / Hot key Switch control Way Auto switching, Set the switch time by hot key ,Mouse Audio Output Support LPCM,5.1 Audio channel USB version 1.1 Version Bandwidth 2.25Gbps HDMI cable...
Page 3 Operating Instructions Operating Instructions 4) Safety check: After repairs or service, ask the servicer to perform safety PANEL DESCRIPTIONS checks to confirm that the unit is in proper working condition. Front Panel WARRANTY If your product does not work properly because of a defect in materials or workmanship, our Company (referred to as "the warrantor"...
Page 4 Operating Instructions Operating Instructions CONNECTION DIAGRAM Problems Solutions Try below ways: 1. Unplug and plug the USB keyboard and mouse 2. Make sure the USB cable connections from KVM switch to host devices are all correct Keyboard and mouse don’t work at all no 3.
