WEB BROWSER-BASED CONFIGURATION

4.6.1 Create Volume Set (0/1/10/3/5/6)

To create volume set from RAID set storage, move the cursor bar
to the main menu and click on the "Create Volume Set" link. The
"Select The Raid Set To Create On It" screen will show all RAID
set number. Tick on a RAID set number that you want to create
and then click on the "Submit" button.
The new create volume set attribute allows user to select the
Volume Name, RAID Level, Capacity, Greater Two TB Volume
Support, Initialization Mode, Strip Size, Cache Mode, Tagged
Command Queuing, and SCSI Channel/SCSI ID/SCSI Lun.
•

Volume Name

The default volume name will always appear as "ThunderBox
600-VOL". You can rename the volume set providing it does not
exceed the 15 characters limit.
•

Volume Raid Level

Set the Raid Level for the volume set. Highlight the desired
RAID level and from the available levels option.
•

Capacity

The maximum volume size is the default initial setting. Enter
the appropriate volume size to fit your application.
•

Greater Two TB Volume Support

Controller uses the "Greater Two TB Volume Support" sub-menu
to set the volume capacity and sector size. Greater Two TB
Volume Support option: "No", "64bit LBA" and "Use 4K Block".
58
