MyWeigh XL-440 Instruction Manual

XL-440
HIGH CAPACITY TALKING SCALE
ENGLISH
Thank you for purchasing the My Weigh® XL-440 Talking digital scale. Please read all operating instructions carefully before use. This electronic scale is a precision
instrument. With normal care and proper treatment, it will provide years of reliable service. For more information please visit www.myweigh.com

OPERATION INSTRUCTIONS

Inserting batteries
Insert 4 AA batteries into the battery compartment on the bottom (underside) of the scale. Be sure the polarity (+ / -) is correct when installing batteries
Taking measurement
a. Step onto the measurement platform. The scale will say "Hello". Now step o the platform and wait a few moments
b. Once the scale is stable, it'll say "It's ready" and show "0.0 lb" (or 0.0 kg). Then you may step onto the measurement platform again. Your weight will be displayed and
spoken once the reading is steady.
c. You may step o of the platform and the reading will hold for 10 secs. After that it'll say "Good-bye" and turn o automatically.
Power o
The power will shut down automatically after no operation is detected for about 10 seconds.
Switching on/o the talking function
Use the switch on the bottom of the platform to switch on/o the speaker function.
Unit conversion
Turn the Scale ON, "0.0" will show on the display". Press the [kg/lb] button on the front of the scale (under the display) to select the desired unit (LB or KG)
Selecting language
After showing "0.0", press and hold the [kg/lb] button for 7 seconds. You will hear the word "Hello" spoken in the current language. Press the [kg/lb] button to toggle
through the available languages. Once you have selected the desired language con rm the selection by pressing and holding the [kg/lb] button until the scale says
"Goodbye".

IMPORTANT NOTES

***If the Scale ever malfunctions please try installing a new battery, sometimes a low battery or defective battery may cause inaccurate readings or other errors
- When the battery runs very low, the warning icon will appear on the display. When this happens, be sure to replace the battery immediately on the underside of the
scale.
- When over-loaded, "FFFF" will be displayed.
- Use the unit on hard, at, dry and secure surface only.
- Place the unit in an area free from high temperature or high humidity. To clean, use dampened cloth and mild detergent.
- Avoid excessive impact or vibration to the unit.
- If you do not intend to use this unit for a long period of time, remove the battery before storage.
- Do not attempt to disassemble the unit, otherwise the warranty will become void.
- The unit is intended for home and personal use only (not legal for commerce).
- This scale must only be used on a hard surface such as tile, wood, or linoleum
- This and most bath scales will not perform properly on thick-carpeted surfaces.
Capacity 200kg x 0.1kg
440lb x 0.2lb
Deviation
Temperature range
Power source
Units kg, lbs
+/- 1%
Optimum 15-20°C
4 x AA alkaline batteries
Capacity
200kg x 0.1kg
440lb x 0.2lb
