ASSEMBLY INSTRUCTIONS

READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING OR OPERATING YOUR GRILL.
WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN AS SEM BLING THIS UNIT.
The following tool is required to assemble this Brinkmann 4 Burner Gas Grill:
• Phillips Head Screwdriver
PARTS LIST:
1
1
Grill Body Assembly
2
1
Left Side Table
3
1
Side Burner Assembly
4
1
Left Side Table Front Panel
5
1
Side Burner Assembly Front Panel
6
1
Warming Rack
7
3
Cooking Grates
8
1
Side Burner Control Knob
9
4
Heat Distribution Plates
10
1
Grease Cup
11
1
Foldable Cart
12
1
Side Burner Grate
13
1
Accessory Tray
14
1
Grease Tray
15
2
Wheel Assembly
16
1
Tank Holder
17
1
Large Front Plastic Foot
18
1
Small Back Plastic Foot
20
