SERVICE MANUAL SERVICE MANUAL
POWERED SUBWOOFER
SKW-204(B)/(S)/(Y)
MODEL
Black, Silver and Yellow models
120V AC, 60Hz
230-240V AC, 50Hz
230-240V AC, 50Hz
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
x ao u163
y
i
http://www.xiaoyu163.com
2 9
8
Q Q
3 6 7 1 3 1 5
S MPA 230-240V AC, 50Hz
S MWT 120/220-240V AC, 50/60Hz
Y MWT 120/220-240V AC, 50/60Hz
ON THE
co
.
9 4 2 8
Ref. No. 3946
052006
0 5 8 2 9 9 4 2 8
m
SKW-204
