Summary of Contents for Intel PRO/Wireless 2011
- Page 1 Intel PRO/Wireless 2011 ® Access Point Quick Installation Guide Additional documentation is on the Intel CD. See page 2 for details.
-
Page 2: Table Of Contents
Specifications ........7 Intel Automated Customer Support ..... .10 Copyright ©... -
Page 3: More Information
Online User’s Guide The full Product Reference Guide and other user documenta- tion is located on the Intel CD. Use Adobe Acrobat* to view or print topics from the guide. The guide covers additional configu- ration topics, and site setup information. To view the guide, put the CD in your drive and wait for the Autorun screen to display. -
Page 4: Mounting The Access Point
Mounting the Access Point The access point rests on a flat surface or attaches to any hard, flat, sta- ble surface. Use the mounting kit provided to secure the access point. Select an access point mounting option based on its intended operating environment. -
Page 5: Led Indicators
Network Administrator who has knowledge of your entire network setup. There are several methods of attaching to the AP and configuring it. Refer to Chapter 2 of the Intel PRO/Wireless 2011 Access Point Product Reference Guide for instructions and password information. -
Page 6: Installing The Wlan Utilities
To install the WLAN Utilities from the Intel CD: 1. Insert the installation CD in the computer CD-ROM drive. 2. Click Start and select Run. -
Page 7: Troubleshooting
Troubleshooting If you cannot link to an Access Point, refer to the Troubleshooting sec- tion in the PRO/Wireless Access Point Product Reference Guide. Specifications Table 1: Physical Specifications Feature Value Drop Withstands up to a 30-inch (76 cm) drop to con- crete with possible surface marring LEDs Power, LAN, Wireless... - Page 8 DIX, Ethernet II and IEEE 802.3 Filtering Packet Rate 14,400 frames per second filtering and forwarding Ethernet Connection 10Base-T (RJ-45) Serial PC/AT serial port - DB9 Male RS-232 using a DTE termination, 19,200 bps SNMP Version 1, Intel MIB, 802.11 MIB and MIB-11...
- Page 9 Blank Page...
-
Page 10: Intel Automated Customer Support
Intel Automated Customer Support You can reach Intel’s automated support services 24 hours a day, every day at no charge. The services contain the most up-to-date information about Intel products. You can access installation instructions, troubleshooting information, and general product information.
