  • Page 1 Installation Reference Guide Audyssey MultEQ Pro & Audyssey Sound Equalizer...
  • Page 2 MultEQ Pro PC application and Audyssey Installer Kit. • Activate your Installer Kit warranty. • Create a web site account. This guide is a general outline of the MultEQ Pro • Create customer certificates. calibration process. For more detailed instructions, see •...
  • Page 3 Audyssey Installation Reference Guide MultEQ Pro Calibration The MultEQ Pro calibration process is outlined in 16 steps. ������������� ������������ Follow these steps for proper installation of the Audyssey � ����� � � � � � � Sound Equalizer. STEP 1 Connect the Sound Equalizer’s inputs to the preamplifier/...
  • Page 4 Audyssey Installation Reference Guide STEP 3 Connect the Installer Kit components (A–D). A Connect XLR cable to Calibrated Microphone. ����� B Place the Calibrated Microphone in Microphone stand. C Connect the XLR and Power cables to the Calibrated Preamplifer. Connect only the MIC IN input at this time.
  • Page 5 Audyssey Installation Reference Guide STEP 4 Turn the amplifier and the Sound Equalizer on. Open the MultEQ Pro application on your laptop, read the Welcome Page and complete the first 4 screens. 1 Job Information Enter an identifying name for your installation job.
  • Page 6 Step 11. 3 Equipment Info Input information about the audio equipment installed in the zone. Create future sales opportunities by telling your customer their system will need another MultEQ Pro calibration if any of their equipment changes. Screen 3...
  • Page 7 Audyssey Installation Reference Guide Note: Complete steps 6 and 7 before proceeding to step 8 the ������������� ������������ Measurement screen. � � � � ����� � � � STEP 6 Use an XLR cable to connect the Calibrated Preamplifier LINE OUT to the XLR-to-RCA Adapter (A).
  • Page 8 1 (the primary position). Measure at position 1 Audyssey’s test signals play through each channel. Time and fre- quency response is recorded. The absolute polarity, level (within half a dB) and delay (within half an inch) of each speaker are calculated.
  • Page 9 STEP 11 your speakers and possibly cause damage to them. On the Target Sound Options screen (A), choose one of Audyssey’s four custom target curves from the STEP 13 Target Curve menu. The four choices are based on the Perform a MultEQ On/Off demo by playing program material while size and reverberant/absorptive characteristics of the room and whether you are using THX re-equalization.
  • Page 10 5-15 until you’re done. After MultEQ Pro After MultEQ Pro 2 Finish MultEQ Pro When you have no more zones left to calibrate, close the MultEQ Pro application. The Sound Equalizer is now MultEQ Pro calibrated.
  • Page 11 ����������� on the Audyssey Installer Web Site. � �������������� �������� �������� � �������������� �������� �������� � �������������� �������� �������� � �������������� �������� �������� Audyssey Laboratories, Inc. 350 South Figueroa St., Suite 196, Los Angeles, CA 90071 Tel: (213) 625-4300 http://www.audyssey.com...
