SERVICE MANUAL

Ver. 1.0 2005. 01
Sony Corporation
9-879-394-01
2005A04-1
e Vehicle Company
© 2005. 01
Published by Sony Engineering Corporation

SPECIFICATIONS

AUDIO POWER SPECIFICATIONS (US model)
POWER OUTPUT AND TOTAL HARMONIC DISTORTION
165 watts per channel minimum continuous average power into 4 ohms,
both channels driven from 20 Hz to 20 kHz with no more than 0.04% total
harmonic distortion per Car Audio Ad Hoc Committee standards.
Other Specifications
Circuit system
OTL (output transformerless) circuit
Pulse power supply
Inputs
RCA pin jacks
High level input connector
Input level adjustment range
0.3 – 6 V (RCA pin jacks),
1.2 – 12 V (High level input)
Outputs
Speaker terminals
Speaker impedance
2 – 8 Ω (stereo)
4 – 8 Ω (when used as a bridging amplifier)
Maximum outputs
380 W × 2 (at 4 Ω)
1,000 W (BTL, at 4 Ω)
Rated outputs (supply voltage at 14.4 V)
165 W RMS × 2 (20 Hz – 20 kHz, 0.04% THD+N, at 4 Ω)
200 W RMS × 2 (20 Hz – 20 kHz, 0.1% THD+N, at 2 Ω)
400 W RMS (BTL) (20 Hz – 20 kHz, 0.1% THD+N,
at 4 Ω)
S/N Ratio
93 dBA (reference: 1 W into 4 Ω)
Frequency response
5 Hz – 80 kHz (
0.008% or less (at 1 kHz, 4 Ω, 10 W)
Harmonic distortion
Low-pass filter
80 Hz, –18 dB/oct
Power requirements
12 V DC car battery
(negative ground)
Power supply voltage
10.5 – 16 V
at rated output : 40 A (4 Ω, 165 W × 2)
Current drain
Remote input : 1 mA
Approx. 424 × 55 × 290 mm
Dimensions
(16
× 2
× 11
3/4
1/4
projecting parts and controls
Mass
Approx. 4.0 kg (8 lb. 13 oz.) not incl. accessories
Supplied accessories
Mounting screws (4)
High level input cord (1)
Protection cap (1)
Design and specifications are subject to change without
notice.
XM-1652Z
+0
dB)
–3
in.) (w/h/d) not incl.
1/2
STEREO POWER AMPLIFIER
US Model
E Model
1
