Foreword And Warning - Sharp R-2130JS Supplemental Service Manual

SERVICE MANUAL
OVER THE RANGE
MICROWAVE OVEN
This Manual has been prepared to provide Sharp Electronics Corp.
Service Personnel with Operation and Service Information for the
SHARP OVER THE RANGE MICROWAVE OVEN, R-2130JS.
It is recommended that service personnel carefully study the entire
text of this manual so that they will be qualified to render satisfactory
customer service.
Check the interlock switches and the door seal carefully. Special
attention should be given to avoid electrical shock and microwave
radiation hazard.
Never operate the oven until the following points are ensured.
(A) The door is tightly closed.
(B) The door brackets and hinges are not defective.
(C) The door packing is not damaged.
(D) The door is not deformed or warped.
(E) There is no other visible damage with the oven.
Servicing and repair work must be carried out only by trained service
personnel.
Certain initial parts are intentionally not grounded and
present a risk of electrical shock only during servicing.
Service personnel - Do not contact the following parts while
the appliance is energized;
Inverter unit that includes High Voltage Capacitor, High
Voltage Power Transformer, High Voltage Rectifier, Heat
sink, etc., and Magnetron, High Voltage Harness etc.;
If provided, Vent Hood, Fan assembly, Cooling Fan Motor.
All the parts marked "*" on parts list are used at voltages more than
250V.
Removal of the outer wrapper gives access to voltage above 250V.
All the parts marked "∆" on parts list may cause undue microwave
exposure, by themselves, or when they are damaged, loosened
or removed.
