CFD-S03CP/S03CPL
SERVICE MANUAL
Ver. 1.3 2006.04
CD player section
System
Compact disc digital audio system
Laser diode properties
Emission duration: Continuous
Laser output: Less than 44.6 µW
(This output is the value measured at a distance of
about 200 mm from the objective lens surface on the
optical pick-up block with 7 mm aperture.)
Number of channels
2
Frequency response
20 - 20 000 Hz +1/–2 dB
Wow and flutter
Below measurable limit
Radio section
Frequency range
FM: 87.5 - 108 MHz
CND, E92, MX model:
AM: 530 - 1 710 kHz
TW model:
AM: 531 - 1 611 kHz
EXCEPT CND, E92, MX, TW model:
AM/MW: 531 - 1 611 kHz (9 kHz step)
530 - 1 610 kHz (10 kHz step)
CFD-S03CPL:
LW: 153 - 279 kHz
IF
FM: 10.7 MHz
AM/MW/LW: 450 kHz
Antennas
FM: Telescopic antenna
AM/MW/LW: Built-in ferrite bar antenna
Sony Corporation
9-887-043-04
Personal Audio Division
2006D04-1
Published by Sony Techno Create Corporation
© 2006.04
Photo: CFD-S03CP
Model Name Using Similar Mechanism CFD-S01
CD
CD Mechanism Type
Section
Optical Pick-up Name
Model Name Using Similar Mechanism CFD-S01
TC
Section Tape Transport Mechanism Type
SPECIFICATIONS
Cassette-corder section
Recording system
4-track 2 channel stereo
Fast winding time
Approx. 150 s (sec.) with Sony cassette C-60
Frequency response
TYPE I (normal): 80 - 10 000 Hz
General
Speaker
Full range: 8 cm dia., 4 Ω, cone type (2)
Outputs
Headphones jack (stereo minijack):
For 16 - 32 Ω impedance headphones
Power output
1.7 W + 1.7 W (at 4 Ω, 10% harmonic distortion)
Power requirements
For CD radio cassette-corder:
120 V AC, 60 Hz (CND, E92, MX, TW model)
220 V AC, 60 Hz (KR model)
220 – 230 V AC, 50 Hz (AR model)
230 V AC, 50 Hz (EXCEPT E92, KR, MX, AR, TW model)
9 V DC, 6 R14 (size C) batteries
For remote control:
3 V DC, 2 R03 (size AAA) batteries
CD RADIO CASSETTE-CORDER
Canadian Model
CFD-S03CP
AEP Model
CFD-S03CP/S03CPL
UK Model
E Model
Australian Model
CFD-S03CP
KSM-213CDP
KSS-213C
MF-S01
– Continued on next page –

Advertisement

loading

  Also See for Sony CFD-S03CP

Sony CFD-S03CP Service Manual
Sony CFD-S03CP Service Manual 54 pages
Sony CFD-S03CP Operating Instructions
Sony CFD-S03CP Operating Instructions 2 pages
Sony CFD-S03CPL Operating Instructions
Sony CFD-S03CPL Operating Instructions 2 pages

  Related Manuals for Sony CFD-S03CP

  Summary of Contents for Sony CFD-S03CP

  • Page 1 4-track 2 channel stereo Laser diode properties Fast winding time Emission duration: Continuous Approx. 150 s (sec.) with Sony cassette C-60 Laser output: Less than 44.6 µW Frequency response (This output is the value measured at a distance of TYPE I (normal): 80 - 10 000 Hz about 200 mm from the objective lens surface on the optical pick-up block with 7 mm aperture.)
  • Page 2 CFD-S03CP/S03CPL SECTION 6 DIAGRAMS 6-1. BLOCK DIAGRAM — CD SECTION — AOUT1 CD_IN_ L SYNCHRONOUS (Page 18) CIRCUIT AOUT2 CD_IN_R PRI- SERVO RF AMP, SYSTEM SERVO PROCESSOR, DIGITAL SIGNAL PROCESSOR IC201 DIGITAL SERVO LD POWER CONTROL CONTROLLER Q321 VDD (3.3V)

  • Page 3: Block Diagram - Main Section

    CFD-S03CP/S03CPL Ver. 1.1 6-2. BLOCK DIAGRAM — MAIN SECTION — IC302 R.RO ELECTRONIC VOLUME R.IN R.LIN POWER AMP REC/PB CD_IN_R IC303 PRE AMP R-CH (Page 17) L.RO IC301 VOL AMP J321 ALC 2 L-IN L-OUT L.LIN L.LO CD_IN_L HRP301 RECORD/PLAYBACK HEAD L.IN...
  • Page 4 CFD-S03CP/S03CPL Ver. 1.2 6-3. CIRCUIT BOARDS LOCATION • NOTE FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS. (In addition to this, the necessary note is printed in each block.) POWER board For schematic diagrams.

  • Page 5: Printed Wiring Board - Bd83S Section

    CFD-S03CP/S03CPL 6-4. PRINTED WIRING BOARD — BD83S SECTION — • Refer to page 19 for Circuit Boards Location. : Uses unleaded solder. (Page 22) MAIN BOARD CN805 IC202 IC201 OPTICAL PICK-UP BLOCK (KSS-213C) 1-868-067- (11) 1-868-067- (11) CFD-S03CP/S03CPL...

  • Page 6: Schematic Diagram - Bd83S Section

    CFD-S03CP/S03CPL 6-5. SCHEMATIC DIAGRAM — BD83S SECTION — • Refer to page 19 for Waveforms. • Refer to page 32 for IC Block Diagram. • Refer to page 34 for IC Pin Description of IC201. C210 CN301 C301 R260 R257...

  • Page 7: Printed Wiring Board - Main Section

    CFD-S03CP/S03CPL Ver. 1.2 6-6. PRINTED WIRING BOARD — MAIN SECTION — • Refer to page 19 for Circuit Boards Location. : Uses unleaded solder. (Page 30) (Page 26) ANT2 POWER BOARD HP BOARD FM TERESCOPIC CN901 CN307 ANTENNA JW167 JW232...

  • Page 8: Schematic Diagram - Main Section

    CFD-S03CP/S03CPL Ver. 1.2 6-7. SCHEMATIC DIAGRAM — MAIN SECTION (1/3) — • Refer to page 19 for Waveforms. • Refer to page 32 for IC Block Diagram. (CND,E92,MX) (CND,E92,MX) (EXCEPT CND,E92,MX) (EXCEPT CND,E92,MX) IC B/D ANT1 ANT2 (Page 24) CND,E92,MX MODEL...
  • Page 9 CFD-S03CP/S03CPL Ver. 1.2 6-8. SCHEMATIC DIAGRAM — MAIN SECTION (2/3) — • Refer to page 19 for Waveforms. • Refer to page 37 for IC Pin Description of IC801. CN807 CN804 R870 R817 C456 R818 R819 IC802 C455 R869 Q451...
  • Page 10 CFD-S03CP/S03CPL 6-9. SCHEMATIC DIAGRAM — MAIN SECTION (3/3) — • Refer to page 32 for IC Block Diagrams. D323 C323 R323 R324 C324 R245 R145 C113 C115 R134 C129 C132 C130 R140 C110 R135 R136 C216 C116 C355 R138 R142...

  • Page 11: Printed Wiring Boards - Tc Section

    CFD-S03CP/S03CPL 6-10. PRINTED WIRING BOARDS — TC SECTION — • Refer to page 19 for Circuit Boards Location. : Uses unleaded solder. CN308 CN307 SP201 SPEAKER (R-CH) MAIN BOARD CN306 SP101 (Page 22) JW322 SPEAKER R108 (L-CH) R110 JW321 J321...

  • Page 12: Schematic Diagram - Tc Section

    CFD-S03CP/S03CPL Ver. 1.2 6-11. SCHEMATIC DIAGRAM — TC SECTION — • Refer to page 19 for Waveforms. • Refer to page 33 for IC Block Diagram. IC B/D (AEP,UK,CET,KR,IT) IC301 (CND,E41,E92,AUS,MX,SP,AR,TH,TW) C102 R102 R108 R103 R112 R104 R109 C301 C104...

  • Page 13: Printed Wiring Boards - Panel Section

    CFD-S03CP/S03CPL Ver. 1.1 6-12. PRINTED WIRING BOARDS — PANEL SECTION — • Refer to page 19 for Circuit Boards Location. : Uses unleaded solder. (Page 22) (Page 22) MAIN BOARD MAIN BOARD CN804 CN803 IC401 S417 S407 IC401 CN403 C401...

  • Page 14: Schematic Diagram - Panel Section

    CFD-S03CP/S03CPL Ver. 1.1 6-13. SCHEMATIC DIAGRAM — PANEL SECTION — R401 R402 R403 R404 R405 R406 R407 R408 R409 S401 S402 S403 S404 S405 S406 S407 (EXCEPT AEP,UK,CET,IT) OPERATE (AEP,UK,CET,IT) S413 S414 S415 S416 S417 FFC412 CN421 R411 R412 R413...

  • Page 15: Printed Wiring Boards - Power Supply Section

    CFD-S03CP/S03CPL 6-14. PRINTED WIRING BOARDS — POWER SUPPLY SECTION — • Refer to page 19 for Circuit Boards Location. : Uses unleaded solder. T901 FH901 FH902 F902 D903 C903 D901 (11) 1-869-167- JW908 C901 D902 CN903 MAIN BOARD C902 D904...

  • Page 16: Schematic Diagram - Power Supply Section

    CFD-S03CP/S03CPL 6-15. SCHEMATIC DIAGRAM — POWER SUPPLY SECTION — CN902 CN903 C901 D901 D902 C902 CN901 T901 C903 F902 D903 J901 C906 D904 FH901 FH902 (Page 25) C904 CFD-S03CP/S03CPL...

  • Page 17: Ic Block Diagrams

    CFD-S03CP/S03CPL • IC BLOCK DIAGRAMS IC402 BA5947FM-E2 (BD83S Board) IC1 LV23003VA (MAIN Board (1/3)) AM RF-IN 36 FM RF-IN MUTING 35 GND2 34 FM RF-OUT 33 VCC2 FM-MIX 32 FM OSC + – GND1 INTERFACE AM MIX-OUT 31 AM OSC...
  • Page 18 CFD-S03CP/S03CPL IC302 PT2257-S (MAIN Board (3/3)) L-IN L-OUT VR 2 VOL AMP 2 VREF LOGIC CONTROL VOL AMP 1 REF AMP VR 1 R-IN R-OUT DATA IC301 TA2068N (TC Board) LINE L.LIN L.PO MIC I/EX AMP1 BUF AMP TAPE L.NF RADIO L.RAD...

  • Page 19: Section 8 Electrical Parts List

    CFD-S03CP/S03CPL Ver. 1.2 SECTION 8 BATTERY-1 BATTERY-2 ELECTRICAL PARTS LIST BD83S NOTE: • Due to standardization, replacements in • CAPACITORS The components identified by mark 0 or dotted line with mark the parts list may be different from the uF : µF 0 are critical for safety.
  • Page 20 CFD-S03CP/S03CPL BD83S HEADPHONE KEY-1 KEY-2 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark < CONNECTOR > R423 1-216-833-11 METAL CHIP 1/10W R451 1-216-837-11 METAL CHIP 1/10W CN102 1-770-706-21 CONNECTOR, FFC/FPC 23P R452 1-216-833-11 METAL CHIP 1/10W...
  • Page 21 CFD-S03CP/S03CPL Ver. 1.2 KEY-2 MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark < SWITCH > 1-162-968-11 CERAMIC CHIP 0.0047uF 10% (CND,E92,MX) S423 1-786-050-21 SWITCH, KEYBOARD (VOLUME –) 1-162-970-11 CERAMIC CHIP 0.01uF S424 1-786-050-21 SWITCH, KEYBOARD (VOLUME +) 1-162-968-11 CERAMIC CHIP 0.0047uF 10%...
  • Page 22 CFD-S03CP/S03CPL MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark C212 1-126-925-11 ELECT 470uF C952 1-162-974-11 CERAMIC CHIP 0.01uF C213 1-126-960-11 ELECT C953 1-126-925-11 ELECT 470uF C215 1-126-960-11 ELECT C956 1-126-965-11 ELECT 22uF C217 1-162-964-11 CERAMIC CHIP 0.001uF...
  • Page 23 CFD-S03CP/S03CPL Ver. 1.1 MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark < JUMPER RESISTOR > 1-216-864-11 SHORT CHIP 1-216-864-11 SHORT CHIP 1-216-864-11 SHORT CHIP 0 (EXCEPT AEP) 1-216-809-11 METAL CHIP 1/10W 1-216-864-11 SHORT CHIP 0 (AEP)
  • Page 24 CFD-S03CP/S03CPL Ver. 1.2 MAIN Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R262 1-216-864-11 SHORT CHIP R813 1-216-821-11 METAL CHIP 1/10W R316 1-216-864-11 SHORT CHIP R814 1-216-821-11 METAL CHIP 1/10W R321 1-216-809-11 METAL CHIP 1/10W R815...

  • Page 25: Main Panel

    CFD-S03CP/S03CPL Ver. 1.1 MAIN PANEL Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R869 1-216-821-11 METAL CHIP 1/10W A-1157-006-A PANEL BOARD, COMPLETE R870 1-216-821-11 METAL CHIP 1/10W ********************** R871 1-216-821-11 METAL CHIP 1/10W R872 1-216-821-11 METAL CHIP...

  • Page 26: Panel Power

    CFD-S03CP/S03CPL Ver. 1.2 PANEL POWER Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark S407 1-786-050-21 SWITCH, KEYBOARD (u) C305 1-162-962-11 CERAMIC CHIP 470PF S413 1-786-050-21 SWITCH, KEYBOARD (./PRESET –) C306 1-162-970-11 CERAMIC CHIP 0.01uF S414 1-786-050-21 SWITCH, KEYBOARD (>/PRESET +)
  • Page 27 CFD-S03CP/S03CPL Ver. 1.2 Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark R102 1-216-805-11 METAL CHIP 1/10W MISCELLANEOUS R103 1-216-845-11 METAL CHIP 100K 1/10W *************** R104 1-216-825-11 METAL CHIP 2.2K 1/10W R105 1-216-837-11 METAL CHIP 1/10W 1-797-376-11 DECK, MECHANICAL (including M901)
