System Connections - Infinity ENTRA SUB TWO Owner's Manual

S
YSTEM
If your receiver/processor does not have
subwoofer outputs for the left and right
channels or an LFE output:
RECEIVER/AMPLIFIER
Front Speaker Output
RED =
–
BLACK =
1. LOOSEN TERMINALS
2. INSERT BARE END;
TIGHTEN TERMINALS
–
NO STRIPE =
This figure shows how to connect bare wires to the terminals.
Banana plugs may also be inserted directly into the rear of
the connector.
C
ONNECTIONS
LEVEL
Green: On
Red: Stand-By Min Max
LFE NORMAL
PHASE
0º 180º
80Hz
CROSSOVER
FREQUENCY
50Hz 150Hz
L R
LINE LEVEL IN
For LFE use L or R
L
HIGH
LEVEL
IN
R
+ –
L
HIGH
LEVEL
OUT
R
ON OFF
120V
POWER
60Hz
Entra Sub Two
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
NTRL/C
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRICAL SHOCK CSA 22.2
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. UL1492
AVERTISSEMENT: POUR PR VENIR LES RISQUES D'INCENDIE OU DE CHOC
LECTRIQUE, VITER D'EXPOSER CET APPAREIL A LA PLUIE OU A L'HUMIDIT .
+
+
STRIPE =
If you have a Dolby* Digital or DTS
with a low-frequency-effect (LFE) or subwoofer output:
SUBWOOFER OR
LFE OUTPUT
LEVEL
Green: On
Red: Stand-By
CROSSOVER
FREQUENCY
LINE LEVEL IN
Set line-level/LFE switch to "LFE."
If your receiver/processor does not contain a Dolby Digital
or DTS processor but has a subwoofer output:
RECEIVER/PROCESSOR
L R
Set line-level/LFE switch to "Normal."
NOTE: If your receiver/processor has only one sub out,
you may use either the L or R input.
® receiver/processor
Min Max
LFE NORMAL
PHASE
0º 180º
80Hz
50Hz 150Hz
L R
For LFE use L or R
LEVEL
Green: On
Max
Red: Stand-By Min
LFE NORMAL
PHASE
0º 180º
80Hz
CROSSOVER
FREQUENCY
150Hz
50Hz
L R
LINE LEVEL IN
For LFE use L or R
L
HIGH
LEVEL
IN
R
ENTRA SUB TWO
3
