π H-1075
20" VACUUM SEALER
SAFEty PRECAUtIONS
to insure safe operation, the operator should be familiar
with the pinch points and a possible burn hazard near
the seal jaw area. Warning stickers mark the location of
these hazards.
Do not wear neckties, jewelry or loose clothing when
operating the H-1075.
Do not operate, troubleshoot or maintain the H-1075
under the influence of any drug or alcohol.
Always observe all safety warnings and notices on the
machine and in this manual.
DO NOt use flammable or toxic cleaning fluids such as
gasoline, benzene or ether.
CAUTION! Keep hands, fingers and flammable
objects out of the seal jaw area. If a foreign
object is caught between the jaws, turn main
power switch to OFF immediately to prevent
possible burns.
PAGE 1 OF 4
1-800-295-5510
uline.com
OvervIew
CONtROlS
MAIN POWER SWItCH – turns power off and on.
FOOt SWItCH – Controls vacuum cycle and initiates
seal cycle.
HEAt tIMER – Controls heating time. to increase heat,
turn heat timer knob clockwise. to decrease, turn knob
counterclockwise. timer is set in seconds – 10 seconds
maximum.
COOl tIMER – Controls amount of time that pressure
bar remains closed for cooling. to increase cool time,
turn cool timer knob clockwise. to decrease, turn knob
counterclockwise. timer is calibrated in increments of
1/10 minute.
lED INDICAtORS ON HEAt/COOl tIMERS:
• UNlIt: timer is not active.
• SOlID COlOR: timer is active.
• FlASHING: timer has timed-out.
0614 IH-1075
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for U-Line H-1075
Summary of Contents for U-Line H-1075
- Page 1 H-1075. counterclockwise. timer is set in seconds – 10 seconds Do not operate, troubleshoot or maintain the H-1075 maximum. under the influence of any drug or alcohol. COOl tIMER – Controls amount of time that pressure Always observe all safety warnings and notices on the bar remains closed for cooling.
- Page 2 NOTe: Sealing cycle may be aborted at any SEtUP time by turning Main Power Switch to "OFF." Place the H-1075 on a flat working surface. HEAtING tIPS 2. locate the "Air In" port on rear. • Uline recommends cooling time should be double the heating time.
- Page 3 ® CAUTION! Prior to cleaning, always unplug the element for wrinkles, bumps or burn marks. If present, machine. Never immerse or spray the H-1075 remove and reapply covering to smooth them out. with a hose. Failure to follow these instructions For burn marks, replace with new teflon covers.
- Page 4 TrOUBLeSHOOTING OPERAtING ISSUE ACtIONS RECOMMENDAtIONS No Green Power light Check Main Power Switch. Is Power Switch in the ON position? Check fuse. Replace fuse if necessary. Is the machine operating? If yes, green lamp is out on the Main Power Switch. Replace Power Switch.
Need help?
Do you have a question about the H-1075 and is the answer not in the manual?
Questions and answers
Hi, How to fix if the nozzel is not pulling back after vacuum and is not sealing properly.
To fix the U-Line H-1075 nozzle that is not pulling back and not sealing properly:
1. Nozzle Not Pulling Back:
- Check incoming air pressure. It should be set to 75–85 psi.
- Adjust the Nozzle Extend Flow Control to control the nozzle speed (reduce or increase the opening to slow down or speed up the nozzle movement).
- Realign the Pressure Bar pistons if the Pressure Bar does not close. To do this, disconnect air pressure and close the jaw by hand.
2. Not Sealing Properly:
- Increase heat time settings.
- Check the heating element for hot spots or burns. Replace the element if needed.
- Ensure the element is extended all the way to the right.
- Tighten element finger nuts and ensure there are no gaps.
- Clean all contact surfaces.
- Check the fuse and replace it if it is burnt out.
- If the seal has gaps or creases, ensure the bag is flat and crease-free when the vacuum jaw closes. Replace the element and Teflon® if damaged.
- Increase both heat and cool times if the seal remains weak.
