- Page 1 IPPSB-DB Mainboard User Guide...
-
Page 2: Table Of Contents
Speaker connector (A23/Pitch 1.25mm) ..........16 RF connector (A24/Pitch 1.5mm) ............. 16 IR connector (A25/Pitch 1.25mm) ............17 TV tuner slot (A26/Pitch 0.8mm) .............. 18 Low Pin Count connector (for Debug Card) (A28/Pitch 0.5mm) ..19 IPPSB-DB Mainboard User Guide... -
Page 3: Introduction
6 USB ports, VGA Input, Mic input, Audio output, LAN (RJ-45) port, Memory card reader, 2.5”/3.5” HDD SATA port, ODD SATA port, Webcam, Speakers, TV tuner, WLAN, RF, IR. The mainboard has a layout specialized for thermal design and ID structure.” IPPSB-DB Mainboard User Guide... -
Page 4: Hardware Specifications
1x RF connector (A24/Pitch 1.5mm) 1x IR connector (A25/Pitch 1.25mm) 1x TV tuner slot (A26/Pitch 0.8mm) 1x Low Pin Count connector (for Debug Card) (A28/Pitch 0.5mm) AMI 32Mb (SPI) BIOS Proprietary, 7.90 inches x 9.05 inches Form factor IPPSB-DB Mainboard User Guide... -
Page 5: Mainboard Layout
Mainboard Layout Top view A2 A3 A4 A5 (HDMI optional) (USB3.0 optional) IPPSB-DB Mainboard User Guide... -
Page 6: Components
Power button/ Speaker ATX power port A35* Power LED/ connector Volume control connector A11* Intel Socket 1155 RF connector CPU Socket EDID IR connector connector *These components do not have pin definitions shown in this document. IPPSB-DB Mainboard User Guide... -
Page 7: Selectors
Selectors Clear CMOS selector (A20/Pitch 2.54mm) Signal Name Signal Name RTC_RST# Settings: [1-2] Normal [2-3] Clear CMOS Intel Management Engine selector (A29/Pitch 2.54mm) Signal Name Signal Name HDA_SDO +3P3VSB Settings: [2-3] Normal [1-2] Flash override IPPSB-DB Mainboard User Guide... -
Page 8: Connectors
Connectors 2.5” HDD connector (A1/Pitch 1.27mm) Signal Name Signal Name Signal Name +3P3V SATA_TXP0_C +12V SATA_TXN0_C +12V +12V SATA_RXN0_C SATA_RXP0_C +3P3V +3P3V ODD Power connector (A2/Pitch 2.0mm) Signal Name Signal Name IPPSB-DB Mainboard User Guide... -
Page 9: Sata Hdd Power Connector (A3/Pitch 2.0Mm)
Connectors SATA HDD Power connector (A3/Pitch 2.0mm) Signal Name Signal Name +12V SATA connector (A4 and A33/Pitch 1.27mm) Signal Name Signal Name Signal Name SATA_TXP1 SATA_RXN1 SATA_TXN1 SATA_RXP1 IPPSB-DB Mainboard User Guide... -
Page 10: Cpu Fan2 Connector (A5/Pitch 1.25Mm)
Connectors CPU fan2 connector (A5/Pitch 1.25mm) Signal Name Signal Name CPU_FAN_TACH +12V CPU_FAN_PWM System fan connector (A6/Pitch 1.25mm) Signal Name Signal Name System_FAN_TACH +12V System_FAN_PWM IPPSB-DB Mainboard User Guide... -
Page 11: Panel Inverter Connector (A7/Pitch 2.0Mm)
LVDS connector (A9/Pitch 1.0mm) Signal Name Signal Name Signal Name L1_TX2+_NB_C L1_TX0-_NB_C L2_TX2+_NB_C L2_TX0-_NB_C L1_TX3+_NB_C L1_TX2-_NB_C L2_TX3+_NB_C L2_TX2-_NB_C L1_TX3-_NB_C L2_TX3-_NB_C L1_TX1+_NB_C +5VSB L2_TX1+_NB_C +5VSB L1_TXC+_NB_C L1_TX1-_NB_C +5VSB L2_TXC+_NB_C L2_TX1-_NB_C +5VSB L1_TXC-_NB_C +5VSB L2_TXC-_NB_C +5VSB L1_TX0+_NB_C L2_TX0+_NB_C IPPSB-DB Mainboard User Guide... -
Page 12: Power Button/Power Led/Volume Control Connector (A10/Pitch 1.0Mm)
Connectors Power button/Power LED/Volume control connector (A10/Pitch 1.0mm) Signal Name Signal Name Signal Name FP_LED+ PWRBTN# FP_LED- VOLUME_UP +12V VOLUME_DN EDID connector (A12/Pitch 1.25mm) Signal Name Signal Name DATA PWR +5V IPPSB-DB Mainboard User Guide... -
Page 13: Webcam+Dmic Connector (A13/Pitch 1.0Mm)
Connectors Webcam+DMIC connector (A13/Pitch 1.0mm) Signal Name Signal Name Signal Name USB PWR +5V DMIC_CLK USBP 10-- +3P3VSB USBP 10+ DMIC_DATA IPPSB-DB Mainboard User Guide... -
Page 14: Wireless Slot (A16/Pitch 0.8Mm)
Connectors Wireless slot (A16/Pitch 0.8mm) Signal Name Signal Name Signal Name WAKE# +3.3V +3.3V +3.3V PCIE_RST1# +3.3V PE1_RXN0_WLAN +3.3V +1.5V PE1_RXP0_WLAN +1.5V +1.5V CLK_PCIE_ SMB_CLK_S WLAN# PE1_TXN0_WLAN CLK_PCIE_WLAN SMB_DATA_S PE1_TXP0_WLAN +3.3V HUB_USBN1_BT HUB_USBP1_BT IPPSB-DB Mainboard User Guide... -
Page 15: Lcd Mode Switch/Hd Led/Brightness Control Connector (A18/Pitch 1.0Mm)
Signal Name Signal Name Signal Name HDD_LED+ MODE HDD_LED- BRIGHT_UP +12V BRIGHT_DOWN Card Reader (A19) Signal Name Signal Name Signal Name DATA2 DATA2 DATA1 CARD_3V3_CON SD_CD# DATA3 DATA0 DATA1 SD_WP MS_CLK SD_CLK SD_CMD MS_BS DATA3 MS_INS# DATA0 IPPSB-DB Mainboard User Guide... -
Page 16: Speaker Connector (A23/Pitch 1.25Mm)
Connectors Speaker connector (A23/Pitch 1.25mm) Signal Name Signal Name Signal Name SPKR _OUT_R- SPKR_OUT_L- SPKR _OUT_R+ SPKR_OUT_L+ RF connector (A24/Pitch 1.5mm) Signal Name Signal Name +5V_DUAL_USB HUB_USBP4_RF HUB_USBN4_RF IPPSB-DB Mainboard User Guide... -
Page 17: Ir Connector (A25/Pitch 1.25Mm)
Connectors IR connector (A25/Pitch 1.25mm) Signal Name Signal Name Signal Name RX_NR# +5VSB IPPSB-DB Mainboard User Guide... -
Page 18: Tv Tuner Slot (A26/Pitch 0.8Mm)
Connectors TV tuner slot (A26/Pitch 0.8mm) Signal Name Signal Name Signal Name WAKE# +3.3VSB PCIE_RST1# +3.3VSB PE1_RXN1_TV +1.5V PE1_RXP1_TV +1.5V +1.5V CLK_PCIE_TV# SMB_CLK_S PE1_TXN1_TV CLK_PCIE_TV SMB_DATA_S PE1_TXP1_TV IPPSB-DB Mainboard User Guide... -
Page 19: Low Pin Count Connector (For Debug Card) (A28/Pitch 0.5Mm)
Connectors Low Pin Count connector (for Debug Card) (A28/Pitch 0.5mm) Signal Name Signal Name Signal Name +3P3VSB LAD0 LAD2 LFRAME# +3P3VSB LAD1 LAD3 CK_33M_DEBUG IPPSB-DB Mainboard User Guide...
