IPitomy IP400 Quick Manual

Hide thumbs Also See for IP400:
1
2
3
4
5
6

Advertisement

Table of Contents

See also: User Manual
________________________________________________________________
The IP400 is a four port FXO gateway designed to integrate traditional telephone lines with your
IP PBX. The following guide is intended to help you configure the IP400 and the PBX together in
as few steps as possible.

Accessing the IP400

1. Connect the IP400 to your network via the LAN port
2. Log into the PBX
3. Navigate to Destinations=>Extensions
4. Click Auto Discovery
5. Search the page for the IP400 MAC and note the IP address of the IP400

Configuring the IP400

SIP Service

1. In your web browser, enter the IP address for the IP400
2. Login to the IP400
Username: Admin
Password: <nothing>
3. Navigate to Setup=>SIP Service
4. Enter the IP address for the PBX under SIP proxy address
5. For SIP proxy port enter 5060
6. Leave the rest of the settings at their defaults. Minor changes may need to be made in
the future once everything is tested (eg. Sometimes the DTMF method needs to be set to
SIP Info)
7. Click Save
Page 1 of 6
Copyright 2009 © IPitomy Communications, LLC
IP400 Quick Guide
support@ipitomy.com
| 941.306.2200

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IP400 and is the answer not in the manual?

Questions and answers

Related Manuals for IPitomy IP400

Summary of Contents for IPitomy IP400

  • Page 1 IP400 Quick Guide The IP400 is a four port FXO gateway designed to integrate traditional telephone lines with your IP PBX. The following guide is intended to help you configure the IP400 and the PBX together in as few steps as possible.
  • Page 2 Page 2 of 6 Copyright 2009 © IPitomy Communications, LLC...
  • Page 3 1 is for the cable connected to Line 1, etc) **Only enter numbers; no spaces, no hyphens, no dashes, no periods, no parenthesis** 3. Enter a unique User Name for the IP400 4. Enter a unique Password for the IP400 (It is important to note that you should not use the same value for both username and password.
  • Page 4 Rebooting 1. Navigate to Administration=>Reboot 2. Click Restart System Configuring the SIP Provider in the PBX 1. Log into the PBX 2. Navigate to Providers=>SIP Providers 3. Click Add Provider Page 4 of 6 Copyright 2009 © IPitomy Communications, LLC...
  • Page 5 4. Under Name and Username, enter the unique User Name entered earlier in the IP400 Line Settings page 5. Set User Type to Friend 6. Set DTMF Mode to Info 7. Enter dynamic as the Host address 8. Set Register to No 9.
  • Page 6 Reporting=>Monitoring and you will see it is registered, has an IP address, and the status is OK. All you need to do at this point is set your incoming and outgoing routing in regards to the IP400 and you will be making and receiving calls using your analog lines.
