Specification
Models
Dimensions
Weight
Telephone Path
Radio Path
Abort Facility
Expansion
Power Requirement
Current Consumbtion
Hourly test current
Low Battery
Outputs
Start Inputs
Temperature
Humidity
Mounting
Warranty
Regulatory Constraints
Before attempting to install a DualCom, the installer must be aware that the
CS2000 range of DualCom products may only be installed by a professional
installer.
The Ringer Equivalence Number (REN) of the apparatus is 1.0. The sum of
RENs of the individual items connected to one PSTN line should not exceed 4.
APPENDIX 3
CS2000 Stand Alone
(h x w x d) 120 x 182 x 62 mm
450 grams
PSTN technology. CTR21 approved.
GSM
Built In
9 to 16 inputs using CS1050
13.0 - 13.8volts DC, 0.1volt max ripple
75mA quiescent, 150mA operating
800mA for 1/10 second.
10.8-11.0 volts falling, 11.8-12.0v recovery
CS2000, 2 changeover relays (24v 1A contacts)
8 additional outputs using CS1050
Max +15 volt, Min +3.5 volts DC
-20C to +60C transit, -4C to +50C operating
0 - 80% non-condensing
Any orientation
1 years
