Related Manuals for ProScan 332LA25T
Summary of Contents for ProScan 332LA25T
- Page 1 P R O S C A N So Advanced. Yet So Simple. LCD COLOR TV USER'S MANUAL 32LA25T 37LA25T Part No: I E S 0 6 4 0 6 English...
-
Page 2: Caution
CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the CAUTION: To reduce the risk of electric shock, presence of uninsulated dangerous do not remove cover or back. voltage within the product enclosure No user- serviceable parts inside. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 11. ONLY USE ATTACHMENTS/ACCESSORIES 1. READ THESE INSTRUCTIONS SPECIFIED BY THE MANUFACTURER. 2. KEEP THESE INSTRUCTIONS 12. USE ONLY WITH CART, STAND, TRIPOD, 3. HEED ALL WARNINGS BRACKET, OR TABLE SPECIFIED BY THE 4. FOLLOW ALL INSTRUCTIONS MANUFACTURER, OR SOLD WITH THE APPARATUS. -
Page 4: Cleaning And Maintenance
Dear Proscan Customer To obtain maximum benefit from your set, please read Welcome to the bright and vivid world of Proscan TV set. We hope that you will have many years of this manual before making any adjustments and retain enjoyment from your new select. -
Page 5: Table Of Contents
Table of contents CAUTION....................1 IMPORTANT SAFETY INSTRUCTIONS............2 Cleaning and maintenance..............3 Dear Proscan Customer................3 Table of contents..................4 Safety Precautions................5,6 Installation.....................6 Front panel.....................7 Rear panel....................8 Learning about Remote Control............9,10 Check the accessories................11 Remote Control Instructions............11,12,13 Automatic Channel Settings..............13 Checking memorized channels..............14 Adding favorite channels..............15 Current Program Information............15,16... -
Page 6: Safety Precautions
Safety Precautions WARNING KEEP UNNEEDED SMALL PARTS AND OTHER OBJECTS OUT OF THE REACH OF SMALL CHILDREN. THESE OBJECTS CAN BE ACCIDENTALLY SWALLOWED. ALSO, BE CAREFUL ABOUT PACKAGING MATERIALS AND PLASTIC SHEETS. Set up Do not place the TV set on sloped or unstable surfaces. The TV set may fall off or tip over. -
Page 7: Installation
Safety Precautions When using the TV set Do not bring your hands, face or objects close to the ventilation holes of the TV set. Top of the TV set is usually very hot due to the high temperature of exhaust air being released through the Ventilation holes. -
Page 8: Front Panel
Front panel Familiarizing Yourself with the Main Hardware < Checking the front panel > (The picture of the product may vary depending on the model) VOL+ VOL- MENU SOURCE a) Selecting exterior signal input b) Main menu display and menu selection confirm c) Volume adjusting d) Channel selection e) On/off button... -
Page 9: Rear Panel
Rear panel l Rear panel (The picture of the product may vary depending on the model) 1.Service Cord Terminal 2.PC Audio 3.HDMI Input Terminal 4.VGA 5.Optical Digital Sound Output terminal 6.S-video Input Terminal 7.AV1/2 INPUT 8.COMPONENT1/2 INPUT 9.RF(75 ) 10.Power Input Terminal... -
Page 10: Learning About Remote Control
Learning about Remote Control 1. POWER 2. INPUT Displays a menu of all available input sources. Also used to confirm your choice in the on-screen menu. 3. MUTE AIR/CABLE Press to temporarily switch the sound off 4. VOLUME Press to increase or decrease the volume 5. - Page 11 Learning about Remote Control 16. P.MODE Press to change to a preset picture mode 17. S.MODE Press to change to a preset sound mode AIR/CABLE 18. GUIDE Press to view the DTV program information 19. AIR/CABLE Press to select only DTV channels 20.
-
Page 12: Check The Accessories
Check the accessories Part Names & Pictures 1. Remote Control / Battery (2) 2. Power Cable 3. Video/Audio Extension Cable 4. Coaxial Cable 5. Sound Cable (The picture of the product may vary depending on the model) Remote Control Instructions <... -
Page 13: Inserting The Batteries
Remote Control Instructions < Inserting the batteries into the remote control > “ ” 1.Push the mark at the back of the remote control and pull forward slightly. 2.Insert two AAA 1.5V batteries ensuring the correct polarity (+/-). 3.Close the lid. Inserting the batteries Caution: Use only Alkaline Batteries. -
Page 14: Automatic Channel Settings
Remote Control Instructions Caution - Used batteries should be recycled and kept out of children's reach. - Do NOT use new and old batteries together. Change both batteries at the same time. - When not using the remote control over a long time, remove the batteries from the unit. Use only Alkaline batteries. -
Page 15: Checking Memorized Channels
Checking memorized channels CHANNEL Press the [CHANNEL] buttons. - Pressing the [CHANNEL] buttons will select only the memorized channels sequentially. Selecting DIGITAL channels only AIR/CABLE Pressing [AIR/CABLE] will select only the memorized digital channels sequentially. Antenna Settings 1. Press [MENU]. The Menu will appear. Press [ / ] to move to a <Channel>, then press [OK]. The <Channel>... -
Page 16: Adding Favorite Channels
Adding favorite channels This function is to help users to select their favorite channels as quickly as possible from amongst multiple channels. Press [FAV]. Go to Menu-Favorite channels and press the [FAV] button to check your favorite channels in the list. <Selecting a special channel as a favorite channel>... -
Page 17: Reserving Program
Current Program Information Viewing the air time and information for all channels. (This is only available for digital broadcasting) GUIDE Pressing [GUIDE] displays information for all channels. The basic broadcasting guide default should be <All Guides>. (The Program guide may change without notice by the broadcasting station.) Reserving a Program Removing a Reservation <Before Starting>... -
Page 18: Checking The Strength Of The Digital Signal
Checking the strength of the digital signal This shows the current digital signal strength as a picture. < Before Starting > Keep the digital TV receiving mode as is. 1. Press [MENU].The Menu will appear. 2. Press [ / ] to move to <Channel>, then press [OK].The <Channel> Menu will appear. 3. -
Page 19: Connections And External Input Settings
Connections and External Input Settings 1:Checking Items Before Connecting Please check the list below before connecting the product to other devices. < Check items before connecting. > Check the instruction manual when connecting external devices. External products sometimes have different buttons and locations. 1. - Page 20 Connections and External Input Settings < Useful Tips > If the signal is too weak to be received by the TV, purchase an additional wavelength amplifier for better reception. Setting up an UHF antenna will receive a digital broadcast signal. For apartments and condos, check with related parties or your landlord for UHF receiver availability.
- Page 21 Connections and External Input Settings RCA terminal is used to connect the output device of DVD (480I/480p/576I/576p/720P/1080I) Y/Pb/Pr The rear of TV VIDEO1 S-VIDEO Left/right Camera Video recorder VIDEO2 S Video HDMI HDMI AUDIO...
-
Page 22: Tv/External Input Settings
TV/External Input Settings TV/ External Input Settings -You can change the signal of the TV or of the external device connected to your TV. INPUT Press [INPUT]. The external input list will appear. 2. Press [ / ] to move to an input mode, then press [OK]. Move to the selected external input screen. <... - Page 23 Screen Adjustments 1:Screen Mode Settings P.MODE 1: Press [P.MODE] to recall a pre-set screen type. Press [P.MODE]. Each press of the button changes the picture mode from <Standard>-><Dynamic>-><Mild>-><Manual>. 2: Press [ / ] and move to a menu ,Press [ ][right] button on the remote control to select a screen mode and Press [OK] 2:Screen Custom Mode Settings <...
-
Page 24: Sound Settings
Screen Adjustments 5:Film Mode Settings Set your selection to <ON> to watch your movies titles at the best quality. You will be able to watch with a more realistic movie screen. 1. Press [ / ] to move to <Picture>, then press [OK]. The <Picture> Menu will appear. Press [ / ] to move to <Film Mode>, then press [OK]. - Page 25 Sound Settings 1:Sound Mode Settings Press [ / ] to move to <Sound>, then press [OK].The <Sound> Menu will appear. Press [ / ] to move to <Mode>, then press [OK].The <Mode> Menu will appear. Press [ ] to select a sound mode.Pressing [ ] will change the settings to <Standard>, <Music>, <Movie>, <News>, <Sports>...
-
Page 26: Time Settings
Sound Settings 8:Sound (Analog Broadcasting) Settings Press [MTS]. You can select your favorite settings <Mono>, <Stereo> or <SAP>. Press [ / ] to move to <Multi-Track>, then press [OK].The <Multi-Track> Menu will appear. Press [ / ] to move to <Mono>, <Stereo> or <SAP>, then press [OK]. The selected sound will be set. Press [EXIT] to exit the menu. - Page 27 Time Settings 4:Time Zone Settings Users can select the time zones. <Before Starting > Set the <Clock> to auto. . Refer to page.xx ~xx. Press [ / ] to move to <Time Zone>, then select [OK]. The <Time Zone> Menu will appear. Press [ / ] to move to your local area, then press [OK].
-
Page 28: V-Chip
V-Chip 1:Entering a PIN This option sets up or changes the password for blocking specific channels. Press [MENU]. The Menu will appear. 1.Press [ / ] to move to <Setup>, then press [OK].The <Setup> Menu will appear. 2.Press [ / ] to move to <V-Chip>, then press [OK].The <Password Dialog Box> Menu will appear. When first accessing the V-Chip menu, no password is set up. -
Page 29: V-Chip 27
V-Chip <Useful Tips> Description of the TV (FCC) Rating Codes: TV (FCC) Age Categories TV-MA Mature audiences only. This program may contain mature themes, profane language, graphic violence and explicit sexual content. TV-14 Parents strongly cautioned. This program may contain sophisticated themes, sexual content, strong language and more intense violence. -
Page 30: Caption
V-Chip 4:Canadian English Ratings <Precautions> Enter your password for the <V-Chip> then move to the <Changing PIN> *** is this pre-defined? BETTER: Changing the PIN *** menu, and select <On> from the <On/Off> Menu. Refer to P.xx~xx. Press [ / ] to move to <Can.English Rating>, then press [OK].The <Can.English Rating> Menu will appear. Press [ / / / ] to move to a rating limit, then press [OK]. - Page 31 Captions 1:Captions Settings Press [MENU]. The Menu will appear. Press [ / ] to move to <Caption>, then press [OK] .he <Caption> menu will appear. Press [ / ] to move to <On/Off>, then [OK]. The <On/Off> Menu will appear. Press [ / ] to move to <On>, then press [OK].
-
Page 32: Connecting A Pc
Connecting a PC 1:Checking Items before Connecting to a PC Check the list below before connecting a PC to the TV. <Precautions> Set your resolution and frequency to a resolution supported by the TV. Refer to the instructions when connecting a PC (graphics and sound cards). Do not connect the power unless all connections are connected. - Page 33 Connecting a PC 2:PC Settings This TV sets the resolution and frequency in the PC display menus supported by Microsoft Windows XP Home Edition. 1. Right-Click the mouse on the desktop screen and select Properties (P). The Display Properties window will appear. 2.
-
Page 34: Appendix-Troubleshooting
Connecting a PC 4:Adjusting the Frequency This function will remove or reduce flickering on the screen, unstable boundaries, unnecessary noise or blurring of the screen. Press [ / ] to move to <Frequency>, then press [OK]. The <Frequency> menu will appear. Press [ / ] to change the frequency. Press [EXIT] to exit the menu. <Useful Tips>... - Page 35 Appendix - Troubleshooting <Menu and Remote Control> The Remote Control isn't functioning well. Press [input selection] to select the device to play. Change the batteries. Check the polarity of the batteries. Check the angle of the remote control from the product or if there are any obstacles between the remote control and the product.
- Page 36 Appendix - Troubleshooting Poor quality sound Check if the program is in stereo. Stereo may not work well in areas with bad reception. Try using Mono for these areas. Sound is malfunctioning while using a cable. Check your sound connecting cable. Check if other channels also have no sound I can see images, but there is no sound.
-
Page 37: Etcetera
Etcetera 1:Specifications The External Design and the Product Standards may be changed without notice to ensure optimal product quality. This product is certified level B and can be used for residential and commercial purposes. Level B certifies that the product can be used for all areas. Level A is only for Industrial or commercial purposes;...
