Table of Mainboard Components
Label Component
AGP1 Accelerated Graphics Port
ATX1 Power connector
AUDIO1 Front-oriented microphone/line-out port header
BT1 Three volt realtime clock battery
CASFAN1 Auxiliary case cooling fan
CD1 CD-in connector
CNR1* Communications Networking Riser slot
CPUFAN1 Cooling fan for CPU
CPU Socket Socket A for AMD Athlon processor
DDR1~DDR2 Two 184 pin DDR SDRAM sockets
FDD1 Floppy disk drive connector
IDE 1 Primary IDE channel
IDE 2 Secondary IDE channel
JP1 Clear CMOS jumper
JP2 CPU frequency selection jumper
PANEL1 Connector for case front panel switches and LED indicators
PCI1 ~ PCI5 Five 32-bit add-in card slots
SPDIFO1* SPDIF out header
SPK1 Speaker connector
USB3 Front panel USB headers
USBCR1 USB card reader connector
*Optional component
This concludes Chapter 1. The next chapter explains how to install the
mainboard.
