Eclipse Security ECL-IP3D50 User Manual page 10

Image Sensor 1/3-inch CMOS
Pixel 1280(H)*960(V)
Day/night Support day/night mode switch
Gain Control Fixed/Auto
White Balance Manual/Auto
BLC On/Off
Manual/Low noise/Low motion blur/Auto
Exposure Mode
It ranges from 1/3 to 1/10000
Video
H.264/H.264H/MJPEG
Compression
Note: Some versions do not support H.264H.
Standard
PAL:
Main stream
(1280*960@25fps),
extra stream
( 704*576@25fps)
Video Frame
Rate
NTSC:
Main stream
(1280*960@30fps),
extra stream
( 704*480@30fps)
H.264: 56Kbps-8192Kbps
Video Bit Rate MJPEG: adjustable and bit rate is adjustable.
Support customized setup.
Support mirror.
Video Flip
Support flip function.
Snapshot Max 1f/s snapshot. File extension name is JPEG.
Privacy Mask Supports max 4 privacy mask zones
Video Setup Support parameter setup such as bright, contrast.
Video
Channel title, time title, motion detect, camera masking.
Information
3.6mm, 6mm, 2.8mm.
Lens
Fixed focus.
Lens Interface M12. Lens is the default accessories
396 (18*22) detection zones; sensitivity level ranges from 0 to 100;
area threshold ranges from 0 to 100.
Motion Detect
Activation event: video storage, image snapshot, log, email function
and etc.
Manual >Video detect>Schedule
Record Priority
Storage
Network storage
Management
Wire Network 1-ch 10/100 Base-T Ethernet
HTTP, TCP/IP, ARP,IGMP, ICMP, RTSP, RTP,UDP, RTCP, SMTP,
Network Protocol
FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP, Bonjour, SNMP
Remote Monitor, system setup, file download, log information, maintenance ,
1/2.8-inch CMOS
1920(H)*1080(V)
PAL:
Main stream
(1920*1080@25fps),
extra stream
( 704*576@25fps)
NTSC:
Main stream
(1920*1080@30fps),
extra stream
( 704*480@30fps)
3.6mm, 6mm. Fixed focus.
1/3-inch CMOS
2048(H)*1536(V)
PAL:
Main stream
(2048*1536@20fps),
extra stream
( 704*576@20fps);
Main stream
(1920*1080@25fps),
extra stream
( 704*576@25fps)
NTSC:
Main stream
(2048*1536@20fps),
extra stream
( 704*480@20fps);
Main stream
(1920*1080@30fps),
extra stream
( 704*480@30fps)
5
