Dear Customer,
Thank you for choosing this quality product from ASKO.
We hope it will meet your expectations and fulfil your needs for many years to
come. Scandinavian design combines clean lines, everyday functionality and
high quality. These are key characteristics of all our products and the reason
they are greatly appreciated throughout the world.
To get the most from your new dishwasher, we recommend that you read the
operating instructions before using the dishwasher. The operating instructions
also include information on how you can help protect the environment.

Operating Instructions

Dishwasher
ASKO D5906

Advertisement

Table of Contents
loading

Related Manuals for Asko D5906

Summary of Contents for Asko D5906

  • Page 1: Operating Instructions

    Dear Customer, Thank you for choosing this quality product from ASKO. We hope it will meet your expectations and fulfil your needs for many years to come. Scandinavian design combines clean lines, everyday functionality and high quality. These are key characteristics of all our products and the reason they are greatly appreciated throughout the world.

  • Page 2: Table Of Contents

    Contents Front panel Troubleshooting Safety instructions Technical information Before washing for the first time Installation Loading the dishwasher Service Using the dishwasher Program chart Settings Your notes Care and cleaning Front panel 1 On/Left-on mode 2 Program selector 3 Program symbol 4 Display 5 Rinse aid indicator 6 TAB (3-in-1/all-in-one detergent)

  • Page 3: Safety Instructions

    Safety instructions General Cleaning Read the operating instructions and keep them in a safe place! When cleaning the edge around the door, use only a slightly damp cloth. Do not spray water around the edge! Moisture can Never use the dishwasher for any purpose other than that make its way into the lock, which contains electrical components.

  • Page 4: Before Washing For The First Time

    Before washing for the first time Do as follows the first time: Program key 1 Unscrew the lid as illustrated. Some dishwashers include program keys in different languages. 2 Place the funnel supplied with the dishwasher in the salt Attach the program key in the desired language to the top of the compartment top-up hole.

  • Page 5: Loading The Dishwasher

    Loading the dishwasher Economic dishwashing NOTE! Run programs only with a full load After topping up, it may take a while before the symbol goes out. Wait to run a program until the dishwasher is full. This way you save energy. Use the Rinse & Hold program to rinse the dishes if there are any unpleasant odours while you wait for the dishwash- Setting the rinse aid dosage er to become fully loaded.

  • Page 6: Upper Basket

    The appearance of the baskets may differ depending on the dishwasher setup. Upper basket Place glasses, cups, bowls, side plates and saucers in the upper basket. All dirty surfaces should face inwards and downwards! Wine glasses are placed on the wine glass shelf and knives are placed in the knife stand on the right (if fitted).

  • Page 7: Using The Dishwasher

    Using the dishwasher Cutlery basket with lid Add detergent Positioning of cutlery basket lid (in upper basket) The cutlery basket lid can be removed and used, for example, as an extra cutlery basket in the upper basket (see below). 1 Prewash detergent compartment 2 Main wash detergent compartment Detergent is added according to water hardness.

  • Page 8: Program Selection

    The display flashes three times with the remaining time to indicate On/Left-on mode that the program has started. Press and hold the On/Left-on mode button until the display lights NOTE! If the machine does not start within 2 minutes of the last button Program selection press, the display returns to showing the last program run.

  • Page 9: Once The Program Has Finished

    Once the program has finished Once the program has finished, “End” appears on the display. At the end of the program, you will hear a short beep. Chapter Settings describes how to change this function. Once the dishwasher has finished, it only uses standby power. Drying For additional drying the door should be opened 35 mm upon completion of the drying cycle.

  • Page 10: Settings

    Settings Do as follows to open the settings menu: First, open the door. Turn off the dishwasher using the On/Left-on mode button (press and hold). Release the button. Press and hold the On/Left-on mode button until the display lights up. Within five seconds, press and hold the Program selector and the Start/Stop button.
  • Page 11 Button press Options Settings Description LCD contrast For adjusting the contrast of the display on the panel. (Low) (Display on the panel) (High) Press Start/Stop to save the setting value and continue to the next setting. Rinse aid Rinse aid dosage setting. (Off) (Low dosage) (High dosage)
  • Page 12 Button press Options Settings Description Adjusting the water softener. Read off the appropriate Water hardness (Soft water) setting from the water hardness table below. °dH °fH °dH °fH 15-19 26-34 20-24 35-43 10-14 25-29 44-52 9-11 15-20 30-39 53-70 12-14 21-25 (Hard water) Press Start/Stop to save the setting value and continue to the next setting.

  • Page 13: Care And Cleaning

    Care and cleaning Coarse filter NOTE! The coarse filter traps larger food particles, which cannot get The dishwasher must not be used without the filter in place! past the drainage pump. Empty the coarse filter as necessary. Diswashing efficiency can be affected if the course filter is in- 1 Lift the coarse filter by the handle.
  • Page 14 Door When cleaning the edge around the door, use only a slightly damp cloth (with a little cleaner if necessary). WARNING! Do not use a spray bottle or the like around the door lock. This is to ensure that water does not penetrate the door catch and come into contact with the electrical components.

  • Page 15: Troubleshooting

    Troubleshooting Display Type of fault Action Overfilling Call the service division. Water outlet fault See "Water remains in the dishwasher" in the table below. Water inlet fault Check that the water tap is on. Check whether dishwasher inlet hose is connected to a pressure limiting valve (some pressure limiting valves may restrict the supply of water to the dishwasher).
  • Page 16 Problem Possible causes Action The dishes have a sticky white/blue film. Rinse aid dosage setting too high. Reduce the amount. See the sections Before washing for the first time and Settings. If you have very soft water, you may want to dilute the rinse aid 50:50 with water.
  • Page 17 Problem Possible causes Action The dishes are not dry enough. The dishwasher is not fully loaded. Fully load the dishwasher. Rinse aid needs topping up or dosage is set Top up with rinse aid or increase the rinse too low. aid dosage.

  • Page 18: Technical Information

    Technical information Technical data Height: 817-872 mm Width: 596 mm Depth: 559 mm Weight: 52 kg Capacity: 14 Place settings Water pressure: 0.03–1.0 MPa 0.3–10 kp/cm 3–100 N/cm Electrical connection: See type plate. Rated power: See type plate. Weight can vary due to different specifications. In accordance with standard, AS/NZS 2007.

  • Page 19: Installation

    Installation 1198 [mm] 30-94 *Remove locking nuts for an installed height of 820-821 mm. Safety instructions Transport protection for the door Connections to electricity, water and drainage must be per- Do not forget to remove the transport protection for the door when formed by a qualified professional.

  • Page 20: Suggested Machine Installations

    Suggested machine installations Adjust the height and slide the dishwasher into place The dishwasher can be installed built-in, completely freestanding or partially built-in. 1 Start by measuring the height from the floor to the bottom A. Built-in edge of the worktop. The dishwasher is intended for installation under a worktop.

  • Page 21: Connection To Water Supply

    7 Make any final adjustments to the feet (the dishwasher may Connection to water supply lean no more than 5 mm) and tighten the lock nuts on the front Use only the supply hose provided with the dishwasher. Do not feet.
  • Page 22 Adjusting the plinth (only when using Set the correct plinth depth as follows toe kick accessory) (Not applicable to all models) The dishwasher is supplied with one or two toe kicks depending on the model. The table shows which toe kick you should use depending on the recess height and plinth depth.

  • Page 23: Service

    Service Read chapter Troubleshooting before contacting the service department. Note down the details on the rating plate positioned on the right inside the dishwasher. Note down the item number (1) and serial number (2). ART. NO. SERIAL NO.

  • Page 24: Program Chart

    Program chart...

  • Page 25: Your Notes

    Your notes...
  • Page 26 Your notes...
  • Page 27 Your notes...

  • Page 28: Quick Guide

    Replenish salt and rinse aid to achieve good washing and drying results. (See page 4.) Refill salt indicator. Refill rinse aid indicator Select a program (See page 8.) Press and hold in Start/Stop, close the door en (08-15) ASKO APPLIANCES AB SOCKERBRUKSGATAN 3, SE-531 40 LIDKÖPING, SWEDEN WWW.ASKO.COM...
